FLAMA G1600 Contact Grill User Manual

Instruccions importants de seguretat

Please read all instructions carefully before using the FLAMA G1600 Contact Grill. Keep this manual for future reference. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• No toqueu superfícies calentes. Utilitzeu nanses o poms.
• Per protegir-vos dels perills elèctrics, no submergeu el cable, els endolls o l’aparell en aigua o en altres líquids.
• És necessària una supervisió estreta quan qualsevol aparell és utilitzat per o a prop dels nens.
• Desendolleu la presa de corrent quan no utilitzeu i abans de netejar. Deixeu refredar abans de posar o treure peces i abans de netejar l'aparell.
• No feu servir cap aparell amb un cable o un endoll danyats, o després que l'aparell funcioni malament o s'hagi fet malbé de cap manera.
• L'ús d'accessoris no recomanats pel fabricant de l'aparell pot causar lesions.
• No utilitzar a l'aire lliure.
• No deixeu que el cable pengi de la vora de la taula o del taulell, ni toqui superfícies calentes.
• No col·loqueu-lo sobre o prop d'un cremador de gas o elèctric calent, ni en un forn calent.
• Cal extremar la precaució quan es mou un aparell que contingui oli calent o altres líquids calents.
• Connecteu sempre primer l'endoll a l'aparell i després el cable a la presa de corrent. Per desconnectar-lo, gireu qualsevol control a la posició "off" i, a continuació, retireu l'endoll de la presa de corrent.
• No utilitzeu l'aparell per a un altre ús que el previst.

Producte acabatview

The FLAMA G1600 Contact Grill is designed for versatile cooking, offering three distinct positions and five temperature settings. Its non-stick grill plates ensure easy cooking and cleaning.

Imatge 1: FLAMA G1600 Contact Grill. This image displays the grill in its closed position, highlighting its compact and modern design. The grey finish is visible, along with the handle and control knob.

Característiques principals:

• 3 Cooking Positions: Closed for contact grilling, partially open for top browning, and fully open for flat grilling.
• 5 Configuracions de temperatura: Adjustable heat control for various food types.
• Non-stick Grill Plates: 10-1/2 x 7 inch plates for easy food release and cleaning.
• Integrated Grease Drip Tray: Collects excess fat for healthier cooking and easier cleanup.
• Disseny elegant: Modern and compact, suitable for countertop use.

Configuració

1. Desembalatge: Carefully remove the grill and all accessories from the packaging. Retain packaging for storage or disposal.
2. Col·locació: Place the grill on a stable, heat-resistant, and dry surface. Ensure there is adequate space around the grill for ventilation.
3. Neteja inicial: Abans del primer ús, netegeu les plaques de la graella amb aiguaamp drap o esponja. Assequeu-ho bé. La safata de degoteig també s'ha de rentar amb aigua tèbia i sabó i assecar-la.
4. Connexió d'alimentació: Ensure the temperature control knob is set to "OFF". Plug the power cord into a grounded electrical outlet.

Instruccions de funcionament

Preescalfament de la graella:

1. Tanqueu la tapa de la graella.
2. Turn the temperature control knob to your desired setting (1-5). The indicator light will illuminate, signaling that the grill is heating.
3. Allow the grill to preheat for approximately 5-10 minutes, or until the indicator light turns off, indicating the set temperature has been reached.

Posicions de cocció:

• Closed Position (Contact Grill): Ideal for grilling sandwiches, paninis, burgers, and thinner cuts of meat or vegetables. Place food on the bottom plate and close the lid. The floating hinge adjusts to the thickness of the food.
• Partially Open Position (Top Browning/Grilling): Lift the top plate and lock it into a hovering position above the food. Useful for melting cheese or browning the top of dishes without direct contact.
• Fully Open Position (Flat Grill/Griddle): Open the grill completely so both plates lie flat, side-by-side. This creates a larger cooking surface, suitable for cooking multiple items simultaneously, like pancakes, eggs, or larger quantities of meat and vegetables.

Consells per a la graella:

• Lightly brush food with oil or cooking spray to prevent sticking, even with non-stick plates.
• Avoid overcrowding the grill to ensure even cooking.
• Use wooden or heat-resistant plastic utensils to avoid damaging the non-stick coating.
• Always ensure the grease drip tray is correctly inserted before cooking.

Manteniment i Neteja

Regular cleaning ensures optimal performance and extends the life of your FLAMA G1600 Contact Grill.

1. Refredament: Desendolleu sempre la graella de la presa de corrent i deixeu-la refredar completament abans de netejar-la.
2. Treure la safata de degoteig: Carefully remove the grease drip tray and empty its contents. Wash the tray with warm, soapy water.
3. Neteja les plaques de graella:
   • For light residue, wipe the plates with a damp drap o tovallola de paper.
   • For stubborn food residue, use a plastic scraper to gently remove it. You may also dampen a paper towel with a small amount of cooking oil to loosen residue, then wipe clean.
   • The grill plates are non-removable. Do not immerse the entire appliance in water.
4. Neteja exterior: Netegeu l'exterior de la graella amb anunciamp drap. No utilitzeu productes de neteja abrasius ni fregalls, ja que poden danyar l'acabat.
5. Assecat: Assegureu-vos que totes les peces estiguin completament seques abans de guardar-les o utilitzar-les el següent cop.

Resolució de problemes

Especificacions

• Model: G1600
• Marca: FLAMA
• Grill Plate Dimensions: 10-1/2 x 7 inches (approx. 26.7 x 17.8 cm)
• Característica especial: Recobriment antiadherent
• Color: Gris
• UPC: 633388016006
• Fabricant: Flama
• Origen: Fabricat a Portugal

Informació de la garantia

FLAMA products are manufactured to high-quality standards. This product is covered by a limited warranty against defects in materials and workmanship from the date of purchase. Please refer to the warranty card included with your product for specific terms and conditions, including duration and coverage details. Keep your proof of purchase for warranty claims.

Nota: Els termes de la garantia poden variar segons la regió.

Atenció al client

For technical assistance, troubleshooting, or to inquire about replacement parts, please contact FLAMA customer support. Refer to the contact information provided on the product packaging or the official FLAMA weblloc.

Recursos en línia: Visit the official FLAMA weblloc web per a preguntes freqüents, registre de productes i materials de suport addicionals.
