Craftsman Programmable Digital Tire Gauge User Manual

1. Introducció

The Craftsman Programmable Digital Tire Gauge is designed to provide accurate and convenient tire pressure readings. Maintaining correct tire pressure is crucial for vehicle safety, fuel efficiency, and tire longevity. This manual provides instructions for the proper use and care of your digital tire gauge.

2. Components del producte

Your Craftsman Programmable Digital Tire Gauge includes the following key components:

• Pantalla digital: Large, backlit screen for clear pressure readings.
• Broquet: Straight-push design for easy application to tire valve stems.
• Air Bleed Button: Allows for precise pressure adjustment.
• Botó de configuració: Used for programming target tire pressures.
• Botons amunt / avall: For navigating menus and adjusting settings.
• Llanterna LED: Integrated light for visibility in low-light conditions.
• Compartiment de la bateria: Houses the included batteries.

Image 1: Craftsman Programmable Digital Tire Gauge in use. The gauge is held against a tire valve stem, displaying a current pressure of 28.5 PSI and a target pressure of 32 PSI on its backlit screen. The user's hand is visible, and the tire and wheel are in the background.

3. Configuració

3.1. Instal·lació de la bateria

The Craftsman Digital Tire Gauge comes with batteries included. If replacement is needed:

1. Localitzeu la tapa del compartiment de la bateria a la part posterior del dispositiu.
2. Traieu la coberta.
3. Introduïu piles noves, assegurant la polaritat correcta (+/-).
4. Col·loqueu la coberta del compartiment de la bateria amb seguretat.

3.2. Initial Power On and Unit Selection

The gauge automatically powers on when pressure is detected. To select your preferred unit of measurement (PSI, BAR, kPa):

1. With the gauge off, press and hold the SET botó durant aproximadament 3 segons.
2. The display will show the current unit. Use the Up or Avall buttons to cycle through available units.
3. Premeu el botó SET botó de nou per confirmar la vostra selecció.

3.3. Programming Target Tire Pressure

You can program target tire pressures for your vehicle's front and rear tires:

1. Premeu el botó SET button once to enter programming mode. A tire icon will appear.
2. Utilitza el Up or Avall buttons to adjust the target pressure for the front tires.
3. Premeu SET again to switch to the rear tire setting.
4. Utilitza el Up or Avall buttons to adjust the target pressure for the rear tires.
5. Premeu SET one more time to save the settings and exit programming mode.

4. Instruccions de funcionament

4.1. Comprovació de la pressió dels pneumàtics

For accurate readings, check tire pressure when tires are cold (driven less than a mile). Refer to your vehicle's owner's manual or the sticker on the driver's side door jamb for recommended tire pressures.

1. Traieu el tap de la vàlvula del pneumàtic.
2. Firmly press the gauge's nozzle straight onto the tire valve stem. Ensure a tight seal to prevent air leakage.
3. The gauge will automatically power on and display the current tire pressure. A beep will sound when the reading is locked.
4. Remove the gauge from the valve stem. The reading will remain on the display for a few seconds before automatically shutting off.
5. Substituïu la tapa de la vàlvula.

4.2. Adjusting Tire Pressure (Air Bleed Function)

If your tire pressure is too high, you can use the Air Bleed function to release air:

1. With the gauge nozzle pressed onto the valve stem and displaying pressure, locate the Air Bleed button (often on the side or back of the gauge).
2. Press and hold the Air Bleed button to release air. The display will show the pressure decreasing in real-time.
3. Release the button when the desired pressure is reached. If a target pressure was programmed, the gauge may beep when the target is met.
4. Traieu el manòmetre i torneu a col·locar la tapa de la vàlvula.

4.3. Ús de la llanterna LED

The integrated LED flashlight can be activated for use in low-light conditions:

• Press the flashlight button (often marked with a light bulb icon) to turn the LED on.
• Press the button again to turn the LED off.

5. Manteniment

5.1. Neteja

Wipe the gauge with a soft, dry cloth. Do not use abrasive cleaners or immerse the device in water.

5.2. Emmagatzematge

Store the tire gauge in a cool, dry place, away from direct sunlight and extreme temperatures. If storing for extended periods, it is recommended to remove the batteries to prevent leakage.

6. Solució De Problemes

7. Especificacions

• Marca: Artesà
• Model: Programmable Digital Tire Gauge
• Dimensions (L x A x A): 5.9 x 1.6 x 1.5 polzades
• Pes: 0.17 lliures
• Components inclosos: Bateries
• Unitats de mesura: PSI, BAR, kPa (selectable)
• Visualització: Backlit Digital LED
• Característiques: Programmable target pressure, Air Bleed function, LED flashlight, Automatic shut-off.

8. Garantia i assistència

8.1. Informació de la garantia

Craftsman products are known for their quality and durability. For specific warranty details regarding your Programmable Digital Tire Gauge, please refer to the warranty card included with your purchase or visit the official Craftsman weblloc web. Conserveu el rebut de compra com a comprovant de compra per a qualsevol reclamació de garantia.

8.2. Atenció al client

If you encounter any issues or have questions not covered in this manual, please contact Craftsman Customer Support. You can typically find contact information on the product packaging or the official Craftsman weblloc:

Weblloc: www.craftsman.com

(Note: Specific contact numbers or email addresses may vary by region and are subject to change. Please check the official weblloc web per obtenir la informació més actualitzada.)
