Philips OneBlade QP2520/30 Hybrid Trimmer and Shaver User Manual

1. Informació de seguretat

Advertències importants de seguretat:

• Do not use the device against the direction of hair growth.
• It is recommended to use the shaver on wet skin with shaving foam to avoid irritation and cuts.
• Do not immerse the device in water beyond the recommended resistance or for longer than recommended.
• Do not charge the device near water or for longer than recommended to avoid the risk of electric shock.
• Llegiu sempre l'etiqueta, els advertiments i les instruccions que figuren a l'envàs del producte abans d'utilitzar-lo.

2. Producte acabatview

The Philips OneBlade QP2520/30 is a versatile hybrid trimmer and shaver designed for men's grooming. It features patented OneBlade technology to shave, trim, and edge any beard length, offering high precision and performance. The dual protection system ensures the blade is never too close to the skin, preventing irritation even in sensitive areas. It supports Wet&Dry use, allowing for use on dry or wet skin, with or without foam, and even in the shower.

Què hi ha a la caixa

This image shows the Philips OneBlade device along with its accessories, including the charging cable, blade, and comb attachments, laid out on a white background.

• 1 Philips OneBlade Device
• 1 Original OneBlade
• 3 Stubble Combs (1mm, 3mm, 5mm)
• 1 Extra Replacement Blade
• 1 Storage Cap
• Manual d'usuari

3. Configuració

3.1 Càrrega inicial

Before using your Philips OneBlade for the first time, ensure it is fully charged. The device uses a rechargeable NiMH battery.

1. Connect the charging cable to the OneBlade device.
2. Connecteu el carregador a una presa de corrent.
3. Allow the device to charge for approximately 8 hours for a full charge. A full charge provides up to 45 minutes of continuous use.

This image shows a hand connecting the charging cable to the bottom of the Philips OneBlade device.

3.2 Attaching/Detaching Blades and Combs

The OneBlade features a click-on system for easy attachment and detachment of blades and comb guides.

1. To attach a blade: Align the blade with the handle and push until it clicks into place.
2. To attach a comb guide: Slide the desired comb (1mm, 3mm, or 5mm) over the blade until it securely locks.
3. To detach a comb guide: Gently pull the comb guide away from the blade.
4. To detach a blade: Press the release button (if present) or gently pull the blade away from the handle.

This image illustrates how to attach a comb guide to the Philips OneBlade blade. The comb slides over the blade for trimming.

This image shows a hand detaching the blade from the Philips OneBlade device, demonstrating the easy removal process.

4. Instruccions de funcionament

The Philips OneBlade is designed for trimming, edging, and shaving facial hair. Its unique technology allows for efficient and comfortable grooming.

4.1 Retall

Use one of the three stubble combs (1mm, 3mm, or 5mm) to achieve your desired beard length.

1. Attach the desired comb guide to the blade.
2. Enceneu el dispositiu.
3. Move the OneBlade against the direction of hair growth, holding it flat against your skin.
4. The comb guides ensure an even trim.

This image shows a man using the Philips OneBlade with a 1mm comb attachment to trim his beard, achieving a short stubble look.

This image shows a man using the Philips OneBlade with a 3mm comb attachment to trim his beard, maintaining a medium stubble length.

This image shows a man using the Philips OneBlade with a 5mm comb attachment to trim his beard, achieving a longer stubble or short beard look.

4.2 Bordes

Create perfect edges and sharp lines with the dual-sided blade.

1. Traieu les guies de la pinta.
2. Hold the OneBlade with the blade flat against your skin.
3. Use the tip of the blade to create precise lines and edges. The dual-sided blade allows you to move in any direction.

This image shows a man using the Philips OneBlade to create sharp lines and edges on his beard, demonstrating the precision of the blade.

4.3 Afaitar-se

For a clean shave, use the OneBlade without any comb guides.

1. Ensure no comb guide is attached.
2. Hold the OneBlade flat against your skin and move it in long strokes against the direction of hair growth.
3. The dual protection system helps prevent nicks and cuts.
4. Can be used Wet&Dry: on dry skin, with shaving foam, or in the shower.

This image shows a man using the Philips OneBlade to shave his face, highlighting the close and comfortable shave it provides.

4.4 Vídeo oficial del producte

5. Manteniment

5.1 Neteja

Una neteja regular garanteix un rendiment i una higiene òptims.

1. Després de cada ús, apagueu el dispositiu.
2. Remove the blade from the handle.
3. Rinse the blade and the device under running water to remove hair and debris.
4. Shake off excess water and allow both the blade and device to air dry completely before storing or reattaching.

This image shows the Philips OneBlade being rinsed under running water, demonstrating its waterproof design and ease of cleaning.

5.2 Recanvi de fulla

For optimal performance, replace the OneBlade blade every 4 months, or sooner if you notice reduced performance or discomfort.

1. Apagueu el dispositiu.
2. Remove the old blade by gently pulling it away from the handle.
3. Attach a new blade by aligning it with the handle and pushing until it clicks into place.

This image shows a hand replacing the blade on the Philips OneBlade device, illustrating the simple process of detaching the old blade and attaching a new one.

6. Solució De Problemes

7. Especificacions

• Número de model: QP2520/30
• Marca: Philips
• Dimensions del producte: 25.4 x 5.08 x 6.86 cm; 70 grams
• Font d'alimentació: Funciona amb bateria
• Tipus de bateria: NiMH Rechargeable Battery
• Temps d'ús: 45 minutes (after 8 hours charge)
• Material de la fulla: Acer inoxidable
• Tipus de capçal: Paper d'alumini
• Característica especial: Rechargeable, Wet & Dry use
• Color: Lime Green, Anthracite Grey
• País d'origen: Indonèsia

8. Garantia i assistència

For detailed warranty information and customer support, please refer to the official Philips website or the warranty card included in your product packaging.

You can also visit the Philips store on Amazon for additional product information and support:

Philips Official Store
