uxcell 24V DC 1800N Electric Lifting Magnet Electromagnet Solenoid Lift Holding

1. Introducció

This manual provides essential information for the safe and effective use of the uxcell 24V DC 1800N Electric Lifting Magnet. This device is designed for various industrial and experimental applications requiring strong, controlled magnetic holding force.

Figure 1: The uxcell 24V DC 1800N Electric Lifting Magnet. This image shows the main body of the electromagnet, which is cylindrical and made of metal, with a central magnetic surface.

2. Informació de seguretat

ADVERTIMENT:

• This electromagnet generates a powerful magnetic field. Keep away from sensitive electronic devices, magnetic storage media, and medical implants (e.g., pacemakers).
• Ensure proper electrical connections to avoid short circuits or damage to the unit. Only use with a 24V DC power supply.
• The holding force can decrease due to prolonged operation, lower voltage, or improper contact with the object being held. Always ensure the actual force is sufficient for the application. It is recommended that the actual force is less than 80% of the rated holding force.
• Avoid direct contact with the electromagnet when powered, as it may generate heat.
• Avís de la Proposició 65: Aquest producte pot contenir substàncies químiques que l'estat de Califòrnia sap que causen càncer i defectes congènits o altres danys reproductius.

Figure 2: Warning label regarding plastic bags. To avoid danger of suffocation, keep this plastic bag away from babies and children. Do not use this bag in cribs, beds, carriages, or playpens. This bag is not a toy.

3. Contingut del paquet

Verifiqueu que tots els elements estiguin presents i no estiguin danyats en obrir el paquet:

• 1 x uxcell 24V DC 1800N Electric Lifting Magnet

4. Especificacions

Figura 3: Primer pla view of the electromagnet's label, indicating "Electromagnet", "Model: WF-P100/40", "Voltage: DC 24V", and "Suction: 1800N".

5. Configuració

1. Muntatge: The electromagnet features an M8 threaded hole for secure mounting. Ensure the mounting surface is stable and capable of supporting the electromagnet and any load it will hold.
2. Connexió elèctrica: Connect the two lead wires to a stable 24V DC power source. Polarity typically does not matter for an electromagnet, but ensure a secure connection to prevent arcing or short circuits.

Figura 4: A baix view of the electromagnet, showing the central M8 threaded mounting hole and the two lead wires extending from the side.

Figure 5: Close-up of the electromagnet's lead wires, showing the stripped ends ready for electrical connection.

6. Instruccions de funcionament

The electromagnet operates by applying 24V DC power to its leads. When power is applied, the electromagnet will generate a magnetic field, allowing it to hold ferromagnetic objects. To release the object, simply cut off the power supply.

• Encès: Apply 24V DC to the lead wires. The electromagnet will become active.
• Holding Objects: Position the electromagnet's active surface against the ferromagnetic object to be held. Ensure full contact for maximum holding force.
• Apagar: Disconnect the 24V DC power supply to deactivate the electromagnet and release the held object.

Important Considerations for Holding Force:

• The actual holding force can be less than the rated 1350N (or peak 1800N) due to factors such as:
• Surface Condition: Rough or uneven surfaces on the object being held will reduce contact area and thus holding force.
• Gruix del material: Thinner ferromagnetic materials may not allow for full magnetic flux, reducing holding force.
• Espai d'aire: Any gap between the electromagnet and the object (e.g., paint, rust, debris) will significantly reduce force.
• Voltage Fluctuació: Lower than 24V DC input voltage will result in reduced magnetic strength.
• Temperatura: Prolonged operation can cause the electromagnet to heat up, which may slightly reduce its magnetic performance.
• Always test the holding force in your specific application to ensure it meets safety and operational requirements.

Figure 6: The electromagnet shown with its key specifications, 24V DC and 1800N, highlighted.

7. Manteniment

The uxcell Electric Lifting Magnet is designed for durability and requires minimal maintenance.

• Neteja: Keep the magnetic surface clean and free of debris, rust, or paint to ensure optimal contact and holding force. Use a dry, soft cloth for cleaning. Do not use abrasive cleaners or solvents.
• Inspecció: Periodically inspect the lead wires for any signs of damage, fraying, or exposed conductors. Ensure all connections remain secure.
• Emmagatzematge: Store the electromagnet in a dry environment, away from excessive heat or moisture, and away from sensitive electronic devices.

8. Solució De Problemes

9. Aplicacions

The uxcell 24V DC 1800N Electric Lifting Magnet is suitable for a variety of applications requiring controlled magnetic holding or lifting, including but not limited to:

• Assembly lines
• Sorting machines
• Braços mecànics
• Experimental facilities
• Door holding mechanisms
• Automation projects

10. Garantia i Suport

For warranty information or technical support, please refer to the purchase documentation or contact uxcell customer service directly. Keep your purchase receipt as proof of purchase.

Informació de contacte:

• Visit the official uxcell store on Amazon: uxcell Store
• Consulteu les dades de contacte que s'inclouen amb l'embalatge del producte.
