Producte acabatview
The Oursson Vitality Slow Juicer is designed to extract juice from fruits and vegetables using a cold press mastication technology. This method helps preserve vitamins and enzymes, resulting in more nutritious and flavorful juices. The juicer features a wide feeding chute, a powerful 240W motor, and a 1-liter juice container.
Image: The Oursson Vitality Slow Juicer surrounded by fresh produce and several glasses of freshly extracted juice, demonstrating its purpose and output.
Instruccions importants de seguretat
- Llegiu totes les instruccions abans d'utilitzar l'aparell.
- Assegureu-vos que l'aparell estigui correctament muntat abans de fer-lo funcionar.
- No submergiu la base del motor en aigua o altres líquids.
- Mantingueu les mans i els estris fora de la boca d'alimentació durant el funcionament per evitar lesions.
- Unplug the juicer from the power outlet before cleaning or disassembling.
- Aquest aparell només és per a ús domèstic.
Components
The Oursson Vitality Slow Juicer package includes the following components:
- Main Juicer Unit (240W)
- Juice Reservoir Cap
- Auger (Screwing mechanism)
- 3-Level Filter
- Copa de sucs
- Empenjador
- Raspall de neteja
- Juice Container (1 Liter)
- Envàs de polpa
- Manual d'usuari
Muntatge i muntatge
Follow these steps to correctly assemble your Oursson Vitality Slow Juicer before first use:
Imatge: Una explosió view diagram illustrating the assembly process of the juicer, with numbered steps.
- Pas 1: Align the cup with the main body.
- Pas 2: Place the filter into the cup.
- Pas 3: Place the auger into the filter.
- Pas 4: Align and pivot the feeding chute onto the assembled cup and auger.
- Pas 5: Use the pusher to guide fruits towards the cold press mechanism.
Ensure all parts are securely locked into place before plugging in the appliance.
Instruccions de funcionament
Preparació dels ingredients
The Oursson Vitality Slow Juicer features a wide 75 mm feeding chute, allowing you to process large fruits and vegetables with minimal pre-cutting. For best results, ensure fruits and vegetables are washed. Remove large seeds or hard pits from fruits like peaches or plums. For fibrous vegetables like celery, it is recommended to cut them into smaller pieces to prevent clogging.
Procés de suc
- Ensure the juicer is properly assembled and the juice and pulp containers are in place.
- Connecteu l'aparell a una presa de corrent adequada.
- Turn on the juicer. The slow mastication process operates at 50-60 RPM, minimizing oxidation and preserving nutrients.
- Gradually feed fruits and vegetables into the wide chute. Use the pusher only when necessary to gently guide ingredients. Do not force ingredients into the chute.
- The juice will be collected in the juice container, and the pulp will be expelled into the pulp container.
- The juicer is designed for high efficiency, extracting up to 30% more juice compared to centrifugal juicers.
Image: An illustration demonstrating the typical juice yield for different produce types, such as carrots (90-95%), apples (70-75%), oranges (85-95%), pears (78-83%), and tomatoes (70-80%).
Sistema antigoteig
The juicer is equipped with an anti-drip design. This feature prevents juice from dripping after extraction, keeping your countertop clean. It also allows for mixing different fruit or vegetable juices within the juicer before dispensing.
Imatge: Un primer pla view of the juicer's spout, highlighting the "Drip Free Design" and its benefits for preventing oxidation and allowing juice mixing.
Funcionament silenciós
The Oursson Vitality Slow Juicer operates at a low noise level of less than 60 dB, making it suitable for use at any time without disturbing others.
Image: A visual comparison illustrating the quiet operation of the Oursson slow juicer (left, with a sleeping baby) versus a louder centrifugal juicer (right), emphasizing its low noise level.
Manteniment i Neteja
Regular cleaning ensures the longevity and optimal performance of your juicer. The Oursson Vitality Slow Juicer is designed for easy disassembly and cleaning.
Passos de neteja
- Desconnecteu l'alimentació: Always unplug the juicer from the power outlet before disassembling or cleaning.
- Desmuntar: Follow the assembly steps in reverse to carefully take apart the removable components (pusher, feeding chute, auger, filter, cup, juice/pulp containers).
- Esbandida: Rinse all removable parts under running water immediately after use to prevent pulp from drying and sticking.
- Neteja del raspall: Use the provided cleaning brush to remove any stubborn pulp residue from the filter and other components.
- Apte per a rentavaixelles: Most removable parts are dishwasher safe. Refer to the user manual for specific dishwasher compatibility of each component.
- Base de neteja: Wipe the main motor base with a damp tela. No submergiu mai la base del motor a l'aigua.
- Assecar i emmagatzemar: Ensure all parts are completely dry before reassembling and storing the juicer.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| L'aparell no s'encén. | Not properly plugged in; components not correctly assembled; power outage. | Check power connection. Ensure all parts are securely locked. Verify power supply. |
| Difficulty in assembling or disassembling the unit. | Parts are not aligned correctly; residue build-up preventing smooth movement. | Ensure all parts are clean and free of dried pulp. Refer to the assembly instructions and align components precisely. Apply gentle pressure; do not force. |
| Low juice yield or excessive pulp in juice. | Filter is clogged; ingredients are too soft or overripe; feeding too quickly. | Clean the filter thoroughly. Ensure ingredients are fresh. Feed ingredients slowly and steadily. |
| Sieve/Filter breakage. | Processing excessively hard ingredients (e.g., whole nuts, large seeds); impact damage; wear and tear over time. | Avoid juicing extremely hard items. Always remove large pits and seeds. If the sieve is broken, it will need replacement. Contact customer support for spare parts availability. |
| El motor s'atura durant el funcionament. | Overload protection activated due to too much pressure or hard ingredients. | Turn off and unplug the juicer. Remove any jammed ingredients. Wait 15-20 minutes for the motor to cool down before restarting. |
Especificacions
| Característica | Detall |
|---|---|
| Marca | Oursson |
| Número de model | JM6001-DC |
| Color | Bordeus |
| Dimensions del producte (L x A x A) | 6 x 25 x 5 cm (2.36 x 9.84 x 1.97 polzades) |
| Capacity (Juice Container) | 1 litres |
| Poder | 240 watts |
| Voltage | 230 Volts |
| Material | Polycarbonate (PC), Stainless Steel, Plastic |
| Funció d'apagat automàtic | No |
| Nivell de soroll | 60 decibels |
| Temps de funcionament | 1 minute (continuous operation recommended, then rest) |
| Pes de l'article | 5.2 quilos (11.46 lliures) |
| Usos recomanats | Apple, various fruits and vegetables |
| Instruccions de cura | Apte per a rentavaixelles (peces extraïbles) |
Garantia i Suport
Garantia del producte
This Oursson Vitality Slow Juicer comes with a Garantia de qualitat de 24 mesos from the date of purchase. Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects under normal household use.
Disponibilitat de peces de recanvi
Information regarding the availability of spare parts for this model is currently unavailable. For any issues requiring replacement parts, please contact customer support.
Atenció al client
For technical assistance, warranty claims, or any questions regarding your Oursson Vitality Slow Juicer, please contact Oursson customer support. Refer to the contact information provided in your original product packaging or visit the official Oursson weblloc per obtenir detalls de suport.
