1. Producte acabatview
These VLAND LED Projector Headlights are designed as a direct replacement for the factory headlamps on specific vehicle models. They feature LED lighting with an amber sequential turn signal and a dual beam lens system.
Compatibilitat:
- Toyota 86: 2012-2020 (Base Coupe 2-Door, GT Coupe 2-Door, TRD Special Edition Coupe 2-Door)
- Subaru BRZ: 2013-2019
- Scion FR-S: 2013-2016 (Base Coupe 2-Door)
The package includes a driver side headlight, a passenger side headlight, a harness for the general version, and this instruction manual.
Image: VLAND LED Projector Headlights installed on compatible vehicle models.
2. Configuració i instal·lació
Installation of these headlights is designed to be a direct replacement for your vehicle's original headlamps, requiring no vehicle modifications. The wiring and connections are made to match stock lights for a plug-and-play experience.
Passos d'instal·lació:
- Preparació: Ensure the vehicle is turned off and the battery is disconnected before beginning installation.
- Removal of OEM Headlights: Carefully remove the existing factory headlights. This typically involves unbolting the headlight assembly and disconnecting the wiring harness.
- Subaru BRZ Specific Note: For Subaru BRZ models, re-use the mounting brackets from your factory headlights when installing the VLAND LED headlights.
- Connexió del cablejat: Connect the provided wiring harness to the vehicle's electrical system. Ensure all connections are secure. For Scion FR-S owners, some users have found it beneficial to use T-taps to connect to the fog light harness if the 6-pin harness on the VLAND lights is not used.
- Muntatge: Secure the new VLAND LED Projector Headlights into position using the appropriate mounting points.
- Ajust: The headlights feature H/L (horizontal/left & right) and Up/Down adjustment screws for beam alignment. Adjust as necessary after installation. The Up/Down adjusting motor socket may need to be unplugged for low configuration models.
- Prova: Reconnect the battery and test all headlight functions (low beam, high beam, running lights, turn signals) before finalizing the installation.
If you encounter any difficulties during installation, please contact VLAND customer support for online assistance.
Imatge: Part posterior view of the headlight assembly detailing wiring connections and adjustment points.
Imatge: Detallada view of wiring options for Deluxe and General Edition models, and the Up/Down adjustment motor.
3. Instruccions de funcionament
The VLAND LED Projector Headlights offer enhanced lighting features for your vehicle.
Key Lighting Functions:
- Running Lights (DRL): The fiber optic LED bars provide a bright, neon-like glow for daytime visibility.
- Dual Beam Lens: The projector lens provides both low and high beam functionality. Note that D2H HID or D2S LED bulbs for the low beam are no inclòs i s'han de comprar per separat.
- Amber Sequential Turn Signal: The integrated amber LEDs function as a sequential turn signal, illuminating in a dynamic pattern to indicate turns. These can be configured to run as switchback or solid signals based on user preference.
Image: Visual representation of the headlight's various operational modes: off, running light, sequential turn signal, and dual beam.
Imatge: Primer pla view demonstrating the sequential amber turn signal indicator.
4. Manteniment
To ensure the longevity and optimal performance of your VLAND LED Projector Headlights, follow these maintenance guidelines:
- Neteja regular: Keep the headlight lenses clean from dirt, dust, and debris using a soft cloth and mild automotive cleaning solution. Avoid abrasive cleaners.
- Gestió de la humitat: The headlights are designed to be weatherproof (IP67), shockproof, and dust-proof. However, condensation can occasionally occur due to temperature changes.
Addressing Headlight Condensation:
Condensation inside headlight assemblies can happen when warm, moist air enters the housing and cools, causing water vapor to condense. This is often a natural occurrence and does not necessarily indicate a defect.
- Aplicació de calor: Applying gentle heat to the assemblies, such as with a hairdryer on a low setting or parking the vehicle in direct sunlight, can help evaporate the moisture. Ensure headlight bulbs and dust caps are removed if using sunlight.
- Circulació d'aire: Ensure the headlight vents are not blocked to allow proper air circulation, which helps prevent moisture buildup.
- Avoid High-Pressure Washes: While the lights are waterproof, excessive high-pressure washing directly at the seals can sometimes force water in.
Image: Demonstrates the IP67 waterproof, dust-proof, and shock-proof capabilities of the headlights.
Image: Explanation of common causes for moisture inside headlight assemblies.
Image: Methods for clearing condensation from headlight assemblies.
5. Solució De Problemes
If you encounter issues with your VLAND LED Projector Headlights, refer to the following common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| Headlights (running lights/high beams) do not work, but sequential signals function. | Incorrect wiring or connection issues specific to running lights/high beams. | Verify all wiring connections for the running lights and high beams. Ensure the correct harness is used and properly seated. For FR-S models, confirm fog light harness taps are correctly made if applicable. If issues persist, contact VLAND support. |
| Condensation inside the headlight lens. | Temperature fluctuations, high humidity, or blocked ventilation. | Refer to the 'Maintenance' section for detailed steps on how to clear moisture. Ensure vents are clear. |
| Turn signals are not sequential or do not function correctly. | Improper wiring for the turn signal circuit or incorrect configuration. | Check the turn signal wiring connections. Ensure the switchback/solid signal configuration is set as desired. |
If troubleshooting steps do not resolve the issue, please contact VLAND customer support.
6. Especificacions
| Característica | Detall |
|---|---|
| Número de model | YAA-86-0297-H |
| Marca | VLAND |
| Tipus de font de llum | LED |
| Usos específics del producte | Llums de capçalera |
| Voltage | 12 volts |
| Wattage | 35 watts |
| Posició de peces d'automòbil | Davant |
| Material de la lent | Policarbonat |
| Característiques especials | Amber Switchback Turn Signal, Easy Installation, Plug and Play, Weatherproof, Shockproof, Dustproof |
| Bulb Style (Low Beam) | D2H HID / D2S LED (No inclòs) |
| OEM Equivalent Part Numbers | SU003-08035, SU003-06979, SU003-07946, SU003-08036, SU003-06980, SU003-07947, 84002CA122, 84002CA120, 84002CA121, 84002CA132, 84002CA130, 84002CA131, SU003-05149, SU003-04630, SU003-05150, SU003-04631, SU003-05139, SU003-02501, SU003-05140, SU003-02502, SU2503147, SU2502147, SC2503104, SC2502104 |
| Nombre d'articles | 2 (Parell) |
| Dimensions del paquet | 59.4 x 57 x 25.2 cm |
| Pes de l'article | 7.78 kg |
7. Garantia i Suport
Informació de la garantia:
These VLAND LED Projector Headlights come with a manufacturer warranty for 12 mesos des de la data de compra. Si us plau, conserveu el comprovant de compra per a reclamacions de garantia.
Atenció al client:
For any questions, installation assistance, or warranty claims, please contact VLAND customer support. When reporting an issue, please provide the product label, and if applicable, video and picture proof that clearly shows the defect.
Informació de contacte del fabricant:
C/O 5 Paget Rd, Brampton, Ontario, Canada, L6T 5S2
Online support is available for installation inquiries.
