Informació important de seguretat
Si us plau, llegiu i enteneu totes les instruccions abans del muntatge i l'ús. Si no seguiu aquestes instruccions, podeu patir lesions o danys al producte.
- Always follow assembly instructions carefully to prevent instability.
- Be cautious of sharp edges when handling metal frame components.
- No supereu el límit màxim de pes de 226.8 kg (500 lliures).
- Ensure all bolts are securely tightened before use. Periodically check and re-tighten all connections.
- Mantingueu les peces petites allunyades dels nens durant el muntatge.
Contingut del paquet
Verify that all components are present before beginning assembly. If any parts are missing or damaged, please contact DUMEE customer support.
- Seccions de capçal i peu de llit
- Carrils laterals
- Llistons d'acer
- Cames de suport
- Paquet de ferramenta (cargols, volanderes, femelles, clau Allen)
- Manual d'instruccions de muntatge
Muntatge i muntatge
Assembly typically requires two people and approximately 1-2 hours. Follow the numbered steps provided in the included instruction leaflet. Ensure all parts are correctly oriented before tightening.
- Desempaquetar i identificar les peces: Lay out all components on a clean, soft surface to prevent scratches. Match each part to the corresponding label in the instruction manual.
- Assemblea inicial: Begin by attaching the side rails to the headboard and footboard. Insert bolts loosely at this stage.
- Instal·leu les potes de suport: Attach any central support legs to the frame. Ensure they are aligned vertically.
- Col·locar llistons: Position the steel slats across the frame. Secure them according to the instructions.
- Ajustament final: Once all parts are assembled and aligned, systematically tighten all bolts using the provided Allen wrench. Do not overtighten.
Instruccions de funcionament
The DUMEE Twin Bed Frame is designed to support a twin-sized mattress directly on its steel slats, eliminating the need for a box spring.
- Col·locació del matalàs: Place your twin-sized mattress directly onto the steel slat support system. Ensure the mattress is centered and fully supported.
- Capacitat de pes: The bed frame has a maximum weight recommendation of 226.8 kg (500 lbs), including the mattress and occupants. Do not exceed this limit.
- Under-bed Storage: The frame provides approximately 10.63 inches of clearance for under-bed storage. Utilize this space for storage boxes or other items to maximize room efficiency.
Manteniment
Regular maintenance ensures the longevity and stability of your bed frame.
- Neteja: Wipe the metal frame with a dry cloth to remove dust and debris. Avoid abrasive cleaners or harsh chemicals that may damage the powder-coated finish.
- Estanquitat del cargol: Periodically (e.g., every 3-6 months) check all assembly bolts and re-tighten them as necessary. Loose bolts can lead to instability and noise.
- Anti-Noise Plugs: The frame is designed with anti-noise plastic plugs. Ensure these remain securely in place to minimize squeaking.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El marc del llit grinyola | Loose bolts; metal-on-metal friction; missing anti-noise plugs. | Re-tighten all bolts. Ensure anti-noise plastic plugs are correctly installed. |
| Les peces no s'alineen durant el muntatge | Incorrect part orientation; bolts tightened too early. | Loosen all bolts, re-check part labels and orientation, then reassemble. Ensure bolts are only finger-tight until final step. |
| Peces faltes o danyades | Error d'embalatge; danys durant l'enviament. | Do not proceed with assembly. Contact DUMEE customer support immediately for replacement parts. |
| El marc sembla inestable | Loose connections; improper assembly. | Ensure all bolts are fully tightened. Verify that all components are assembled according to the instructions. |
Especificacions
| Característica | Detall |
|---|---|
| Número de model | 634 |
| Mida | Bessona |
| Material | Acer metàl·lic |
| Color | Blanc amb textura |
| Tipus d'acabat | Recobert de pols |
| Estil | Vintage |
| Dimensions del producte (aprox.) | Width: 39.37 inches, Length: 77.56 inches, Headboard Height: 40.43 inches, Footboard Height: 22.43 inches |
| Liquidació sota el llit | 10.63 polzades |
| Recomanació de pes màxim | 226.8 kg (500 lliures) |
| Característica especial | Squeak Resistant, No Box Spring Needed |
| Components inclosos | Llistó |
Garantia i Suport
DUMEE provides a 12 mesos de garantia for this product from the date of purchase. This warranty covers manufacturing defects under normal use.
For any questions regarding product assembly, missing parts, or warranty claims, please contact DUMEE customer service. Refer to your purchase documentation or the DUMEE official weblloc web per obtenir la informació de contacte més actualitzada.
Manufacturer Contact Information: shenzhen, guangdong 518110, CN
