TrustFire MC12 Headlamp Manual d'usuari

Introducció

The TrustFire MC12 is a versatile and powerful LED headlamp designed for various outdoor and indoor activities. It features multiple light modes, a magnetic tail cap, and a detachable pocket clip, making it adaptable for use as a headlamp, handheld flashlight, or work light. Its robust, waterproof design ensures reliable performance in diverse conditions.

Image: The TrustFire MC12 headlamp shown with its headband, magnetic charging cable, and pocket clip.

Contingut del paquet

• TrustFire MC12 Headlamp
• Diadema
• Rechargeable Battery (16340)
• Cable de càrrega USB magnètic
• Clip de butxaca
• Manual d'usuari
• Juntes tòriques de recanvi

Image: All items included in the TrustFire MC12 package, including the headlamp, battery, charging cable, headband, and manual.

Configuració

1. Instal·lació de la bateria

1. Unscrew the tail cap of the headlamp.
2. Remove the protective plastic disc from the battery's positive terminal (if present).
3. Insert the included 16340 rechargeable battery with the positive (+) end facing towards the head of the lamp.
4. Torneu a enroscar la tapa de la cua fermament per garantir un contacte adequat i una resistència a l'aigua.

2. Carregant la bateria

The MC12 uses a magnetic USB charging cable for convenient recharging.

1. Connect the USB end of the charging cable to a USB power source (e.g., computer, wall adapter).
2. Attach the magnetic end of the cable to the charging port on the tail cap of the headlamp.
3. The indicator light on the charging cable will show the charging status:
   • Vermell: Càrrega en curs.
   • Verd: Càrrega completa.
   • Alternating Red-Green (if not connected to lamp): Cable is ready.
4. Desconnecteu el cable un cop finalitzada la càrrega.

Important: The charging cable should only be connected to power during the charging process. Disconnect it when not in use to prevent potential short circuits if the magnetic end comes into contact with metal objects.

3. Fixació de la diadema

To use the MC12 as a headlamp:

1. Feu lliscar el capçalamp into the silicone mount on the headband.
2. Adjust the elastic straps for a comfortable and secure fit on your head.

Image: The TrustFire MC12 headlamp attached to its adjustable headband, ready for use.

Instruccions de funcionament

Encès/Apagat

• Encendre: Press and hold the side switch for approximately 0.5 seconds.
• Apagar: Press and hold the side switch for approximately 0.5 seconds.

Changing Brightness Modes

Quan el capamp is on, short press the side switch to cycle through the brightness modes:

Moonlight → Low → Medium → High

Image: Visual representation of the five lighting modes: High, Medium, Low, Moonlight, and Strobe.

Special Modes (Strobe)

• To Activate Strobe: Double-click the side switch rapidly from any mode (on or off).
• To Exit Strobe: Short press the side switch to return to the previously used brightness mode.

Indicador de nivell de bateria

Quan el capamp is off, short press the side switch to check the battery level. The indicator light on the switch will illuminate:

• Verd: Battery is full (70-100%).
• groc: Battery is medium (30-70%).
• Vermell: Battery is low (less than 30%).
• Vermell intermitent: Battery is critically low (less than 10%), recharge immediately.

Ús versàtil

The MC12 is designed for multiple applications:

• Capamp: Use with the included headband for hands-free illumination during camping, jogging, hiking, or repair work. The lamp head can be rotated 180 degrees to direct light precisely where needed.


  Image: A person running outdoors at dusk, demonstrating the 180-degree adjustable head of the MC12 headlamp.

• Handheld Flashlight: Detach from the headband and use as a compact, powerful flashlight.
• Magnetic Work Light: The flat magnetic tail cap allows the headlamp to be securely attached to ferrous metal surfaces, providing hands-free lighting for tasks like vehicle maintenance or workshop activities.


  Image: A mechanic working under a car hood, with the MC12 headlamp magnetically attached to the hood for hands-free illumination.

• Clip-on Light: Use the removable pocket clip to attach the light to clothing, backpacks, or baseball caps for convenient carrying and directional lighting.


  Image: A person with the MC12 headlamp clipped to their jacket pocket, demonstrating its use as a portable clip-on light.

Manteniment

• Neteja: Netegeu el capamp amb un suau, damp tela. No utilitzeu netejadors abrasius ni dissolvents.
• juntes tòriques: Periodically inspect the O-rings for wear and tear. Lubricate them with silicone grease to maintain water resistance. Replace if damaged.
• Cura de la bateria:
  • Carregueu la bateria regularment, sobretot si no la feu servir durant períodes prolongats, per allargar-ne la vida útil.
  • Guardeu el capamp with a partially charged battery in a cool, dry place if storing for a long time.
  • If the battery is critically low (flashing red indicator), recharge it as soon as possible.
• Resistència a l'aigua: The MC12 is IPX8 waterproof, meaning it can be submerged up to 2 meters for 30 minutes. Ensure the tail cap is tightly screwed on before exposing it to water.


  Image: Two individuals outdoors in snowy and rainy conditions, demonstrating the IPX8 waterproof capability of the TrustFire MC12 headlamp.

Resolució de problemes

Especificacions

Performance Data (Approximate)

• Mode alt: 1000 Lumens / 65 minutes runtime / 105m beam distance
• Mode mitjà: 200 Lumens / 160 minutes runtime / 46m beam distance
• Mode baix: 60 Lumens / 520 minutes runtime / 25m beam distance
• Mode clar de lluna: 3 Lumens / 160 hours runtime / 1.5m beam distance

Garantia i Suport

TrustFire products typically come with a warranty. Please refer to the warranty card included in your package or visit the official TrustFire weblloc per obtenir informació detallada sobre la garantia i els termes.

For technical support, product inquiries, or warranty claims, please contact TrustFire customer service through their official channels or the retailer where you purchased the product.

Informació sobre reciclatge: Please dispose of batteries and electronic components responsibly according to local regulations. Do not dispose of batteries in household waste.

Eliminació de L trencat o danyatamps: Handle with care and dispose of according to local hazardous waste guidelines.
