1. Introducció
Thank you for choosing the FlexSolar 100W Portable Solar Panel. This manual provides essential information for the safe and efficient operation of your solar panel. Please read it thoroughly before use and retain it for future reference.
This portable solar panel is designed to provide clean, renewable energy for charging various electronic devices and power stations, making it ideal for outdoor activities, camping, and emergency backup power.
2. Informació de seguretat
- Do not attempt to disassemble, repair, or modify the solar panel.
- Avoid exposing the solar panel to fire, heat sources, or corrosive substances.
- Assegureu-vos que totes les connexions siguin segures abans de fer-les servir.
- Do not immerse the junction box in water, as it is not waterproof. The solar panel itself is IP65 rated for water and dust resistance.
- Handle the panel with care to prevent physical damage.
- Mantenir fora de l'abast dels nens.
3. Contingut del paquet
Verifiqueu que tots els elements siguin presents al vostre paquet:
- 1 x FlexSolar 100W Portable Solar Panel
- 1 x 118" (3M) DC Cable
- 1 x 10-in-1 Interchangeable DC Connectors
- 1 x 11.8" (0.3M) DC5521 Cable for Alligator Clip
- 1 x Manual d'usuari (Aquest document)
Image: FlexSolar 100W Portable Solar Panel with its accessories, including the DC cable, 10-in-1 DC connectors, and alligator clip cable.
4. Producte acabatview
The FlexSolar 100W Portable Solar Panel features a foldable design for easy transport and storage. It includes multiple output ports for versatile charging.
Image: The FlexSolar 100W Portable Solar Panel connected to a portable power station, demonstrating its primary use case.
Característiques principals:
- Alta eficiència de conversió: Converts up to 24% of solar energy into free power.
- Multi-functional Outputs: Includes USB-A, QC3.0 USB-A, PD 60W USB-C, and DC ports.
- Àmplia compatibilitat: Compatible with various power stations (e.g., Jackery, Bluetti, Anker) and devices (laptops, iPads, phones).
- Disseny portàtil i plegable: Equipped with adjustable kickstands and a TPE rubber handle for easy setup and transport.
- Durador i resistent a la intempèrie: IP65 waterproof and dustproof (panel only, junction box is not waterproof).
- Smart IC Chip Technology: Automatically detects connected devices for optimized charging.
Imatge: Una imatge detallada view of the solar panel's output ports, including USB-C, QC3.0 USB-A, and standard USB-A, shown charging a tablet and smartphone.
5. Configuració
- Desplegueu el panell solar: Carefully unfold the FlexSolar 100W panel completely.
- Position the Panel: Deploy the adjustable kickstands on the back of the panel. Angle the panel directly towards the sun to maximize solar exposure. For optimal performance, ensure no shadows fall on the panel surface.
- Connexió de dispositius:
- For power stations: Use the provided DC cable and the appropriate 10-in-1 DC connector to connect the solar panel to your power station's DC input port.
- For USB devices (phones, tablets, power banks): Connect your device's USB cable directly to the USB-A, QC3.0 USB-A, or USB-C (PD 60W) ports on the solar panel's junction box.
- For 12V batteries: Use the provided DC5521 cable with alligator clips to connect to your battery terminals. Ensure correct polarity (red to positive, black to negative).
- Verifica la càrrega: Once connected, the LED indicator on the junction box will illuminate, indicating that charging is active. Monitor your device's charging status.
Image: The FlexSolar 100W Portable Solar Panel unfolded and supported by its integrated kickstands, ready for solar charging.
Image: A person carrying the folded FlexSolar 100W Portable Solar Panel by its handle, demonstrating its portability.
6. Instruccions de funcionament
For optimal charging performance, ensure the solar panel receives direct sunlight. The charging efficiency will vary depending on weather conditions, sunlight intensity, and the angle of the panel.
Consells de càrrega:
- Llum solar directa: Position the panel to face the sun directly. Adjust its angle periodically throughout the day as the sun moves.
- Eviteu les ombres: Even partial shading can significantly reduce the panel's output. Ensure no trees, buildings, or other objects cast shadows on the panel.
- Superfície neta: Keep the solar panel surface clean from dust, dirt, and debris. A clean panel ensures maximum light absorption.
- Temperatura: While the panel is designed to operate in various temperatures, extreme heat can slightly reduce efficiency. Ensure adequate ventilation around the panel.
Image: The FlexSolar 100W Portable Solar Panel deployed outdoors, capturing sunlight for charging.
Demostració de vídeo:
Video: A demonstration of the FlexSolar panel charging a portable DVD player and a power bank. This video illustrates the panel's functionality in real-world conditions, including charging under partially cloudy skies.
7. Manteniment
- Neteja: Regularly wipe the solar panel surface with a soft, damp cloth to remove dust, dirt, or debris. Do not use harsh chemicals or abrasive materials.
- Emmagatzematge: Quan no l'utilitzeu, plegueu el panell solar i guardeu-lo en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
- Inspecció: Periodically inspect the cables and connectors for any signs of wear or damage. Replace any damaged components immediately.
- Exposició a l'aigua: While the panel is IP65 rated, avoid prolonged exposure to heavy rain or submersion. Ensure the junction box remains dry.
8. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| No charging output / Low charging speed |
|
|
| Indicador LED no encès |
|
|
9. Especificacions
| Característica | Detall |
|---|---|
| Número de model | LXX-C100CA |
| Potència de sortida | 100 W (màx.) |
| Eficiència de conversió | Fins al 24% |
| Ports de sortida |
|
| Material | Monocrystalline, PET Lamination |
| Classificació impermeable | IP65 (Panel only, junction box not waterproof) |
| Mides plegades | 27.1 x 24.1 x 1.4 polzades (68.8 x 61.2 x 3.5 cm) |
| Dimensions desplegades | 48.7 x 24.1 x 0.2 polzades (123.7 x 61.2 x 0.5 cm) |
| Pes | 11.2 lliures (5.1 kg) |
| Dispositius compatibles | Power stations, laptops, iPads, smartphones, power banks, 12V batteries |
Image: Diagram showing the unfolded and folded dimensions of the FlexSolar 100W Portable Solar Panel.
10. Garantia i Suport
FlexSolar products come with a standard warranty. Please refer to the warranty card included in your package or visit the official FlexSolar weblloc web per obtenir informació detallada sobre els termes i condicions de la garantia.
Atenció al client:
If you encounter any issues or have questions regarding your FlexSolar 100W Portable Solar Panel, please contact our customer support team. We are committed to providing prompt and helpful assistance.
Contact information can typically be found on the product packaging, the included user manual, or the official FlexSolar website. Please have your model number (LXX-C100CA) and purchase details ready when contacting support.
