1. Producte acabatview
The Glocusent 106 LED Camping Lantern is a versatile and durable lighting solution designed for outdoor activities, emergencies, and general use. It features a powerful 5000mAh rechargeable battery, multiple brightness levels, and various light modes, all within a compact and rugged design.
Image: The Glocusent 106 LED Camping Lantern in its compact form.
2. Contingut del paquet
Si us plau, comproveu el contingut del paquet en desempaquetar-lo:
- 1 x Glocusent Campllanterna
- 1 x cable de càrrega
- 1 x Manual d'usuari (aquest document)
3. Especificacions
| Característica | Detall |
|---|---|
| Tipus de font de llum | Díode emissor de llum (LED) |
| Marca | Glocusent |
| Font d'alimentació | Alimentat per bateria de 5000 mAh |
| Material | Plàstic |
| Sortida lluminosa màxima | 1200 lúmens |
| Nivell de resistència a l'aigua | Impermeable IP68 |
| Durada de la bateria | Fins a 80 hores (a la brillantor més baixa) |
| Voltage | 5 volts DC |
| Nombre de fonts de llum | 106 LED |
| Dimensions de l'article (L x A x A) | 2.2 cm de llargada x 2.2 cm d'amplada x 5.6 cm d'alçada |
| Pes de l'article | 246 g (8.6 unces) |
| Certificacions | CE, FCC, PSE, RoHS, C-TICK |
4. Configuració
4.1 Càrrega inicial
Before first use, fully charge your Glocusent Camping Lantern. Use the provided USB-C charging cable to connect the lantern to a compatible USB power source (e.g., wall adapter, power bank, computer USB port).
- The charging port is located on the top of the lantern.
- Battery indicator lights will show charging progress.
- A full charge can take approximately 3.5 hours.
Image: The lantern connected to a charging cable, illustrating its 5000mAh battery and up to 80 hours of lighting time.
5. Instruccions de funcionament
5.1 Engegada/Apagada i Ajust de la Brillantor
Press the power button located on the top of the lantern to turn it on. Subsequent presses will cycle through 5 brightness levels. Hold the button to turn off the lantern.
Image: A person holding the lantern, demonstrating its small size and adjustable brightness levels from 20LM to 220LM.
5.2 modes de llum
The lantern offers three distinct light color temperatures and an SOS mode:
- Llum càlida de 3000K: Ideal for use in thick fog or for a cozy ambiance.
- 4000K Combined Light: Suitable for walking or hiking.
- Llum blanca freda de 6000K: Best for repairing tasks or illuminating larger areas like a tent or camplloc.
- Mode SOS: Activates a flashing signal for emergency situations.
To switch between light modes, press the mode button (usually indicated by a light bulb icon) on the top of the lantern.
Image: The lantern displaying its three color temperatures: 3000K Warm Light, 4000K Combined Light, and 6000K Cool White Light.
5.3 Super Bright Mode
The "Super Bright" mode provides 1200LM illumination for 3 minutes, designed for situations requiring maximum light output over a larger area. This mode is activated by a specific button press (refer to the device's button layout on the device for exact activation, typically a quick double-press or a dedicated button).
Image: Close-up of the lantern highlighting its 106 LEDs and 360° illumination, capable of reaching up to 1200 lumens.
5.4 Usage and Portability
El fanal està dissenyat per a un ús versàtil:
- Portàtil: Its compact size and lightweight design make it easy to carry.
- Stand Firm: Place it on any flat surface for stable illumination.
- Hangable: Utilize the integrated top handle or bottom hook to hang it inside tents, on branches, or other suitable fixtures.
Image: The lantern shown next to a backpack, illustrating its compact dimensions (5.6" x 2.2" x 2.2") and light weight (8.6 oz / 245.5g).
Image: Demonstrations of the lantern being used handheld, standing on a table, and hanging from a tent ceiling.
6. Manteniment
6.1 Neteja
Netegeu la llanterna amb un suau, damp cloth. Do not use harsh chemicals or abrasive cleaners, as these may damage the surface or internal components.
6.2 Water and Drop Resistance
The Glocusent Camping Lantern features an IP68 waterproof rating, meaning it can withstand immersion in water up to 1.5 meters for 30 minutes. Its reinforced housing is also designed to be drop-proof from heights of up to 40 inches. While durable, avoid unnecessary exposure to extreme conditions to prolong product life.
Image: The lantern being splashed with water, illustrating its IP68 waterproof and drop-proof capabilities, along with SOS and Super Bright modes.
6.3 Cura de la bateria
To maintain optimal battery health, recharge the lantern at least once every three months, even if not in use. Store in a cool, dry place away from direct sunlight and extreme temperatures.
7. Solució De Problemes
- Lantern does not turn on:
- Ensure the battery is charged. Connect the lantern to a power source using the USB-C cable.
- Premeu i manteniu premut el botó d'engegada durant uns segons per assegurar-vos que no es prem només ràpidament.
- La sortida de llum és tènue:
- Comproveu el nivell de la bateria i recarregueu-la si cal.
- Cycle through the brightness levels to ensure it's not set to the lowest setting.
- Charging is slow or not working:
- Ensure the USB-C cable is securely connected to both the lantern and the power source.
- Proveu un cable USB-C o un adaptador d'alimentació diferent.
- Verifiqueu que la font d'alimentació funciona correctament.
- SOS mode not activating:
- Refer to the device's button layout for the specific activation sequence for SOS mode. It might be a long press or a specific combination.
8. Vídeo oficial del producte
Video: An official product video from Glocusent demonstrating the LED Camping Lantern for Emergency use. This video highlights key features and functionality.
9. Garantia i Suport
9.1 Informació de la garantia
This Glocusent product comes with a 24 mesos de garantia des de la data de compra. Aquesta garantia cobreix els defectes de fabricació i els problemes derivats de l'ús normal. Si us plau, conserveu el comprovant de compra per a reclamacions de garantia.
9.2 Atenció al client
For any questions, concerns, or support needs, Glocusent offers 24/7 online services. Please refer to the contact information provided with your product packaging or visit the official Glocusent weblloc d'assistència.
