2017 Porsche Macan Owner's Manual

1. Introducció

This owner's manual provides essential information for the safe and efficient operation, care, and maintenance of your 2017 Porsche Macan. Please read this manual thoroughly to familiarize yourself with your vehicle's features, controls, and safety systems. Keep this manual in your vehicle for future reference.

The information contained herein was accurate at the time of printing. Porsche reserves the right to make changes in design and specifications without notice and without incurring any obligation.

Figura 1.1: Cover of the original 2017 Porsche Macan Owner's Manual. This image displays the front cover of the physical manual, typically featuring the Porsche logo and vehicle model name.

2. Initial Setup and Controls

Before driving your Macan, it is important to understand the basic setup procedures and familiarize yourself with the primary controls.

2.1 Key and Locking System

• Unlocking/Locking: Press the unlock or lock button on the remote control key. The vehicle will confirm with a flash of the turn signals.
• Keyless Entry (Porsche Entry & Drive): If equipped, simply touch the door handle to unlock or lock the vehicle with the key in your proximity.
• Clau d'emergència: A mechanical key is integrated into the remote control for manual unlocking in case of battery failure.

2.2 Ajust del seient

Adjust your seat for optimal comfort and safety before starting your journey. Most Macan models feature electric seat adjustments.

• Endavant/Enrere: Use the horizontal switch located on the side of the seat.
• Alçada: Use the vertical switch to raise or lower the seat.
• Angle del respatller: Adjust the backrest using the angled switch.
• Suport lumbar: If equipped, use the dedicated buttons to adjust lumbar support.

3. Operating Your Porsche Macan

This section covers the essential steps for driving and utilizing the various systems in your Macan.

3.1 Arrencada i aturada del motor

1. Ensure the gear selector is in 'P' (Park) or 'N' (Neutral).
2. Premeu el pedal de fre amb fermesa.
3. Insert the key into the ignition lock on the left side of the steering column or, with Porsche Entry & Drive, press the start/stop button.
4. Turn the key to the start position or press the button until the engine starts.
5. To stop the engine, turn the key to the 'OFF' position or press the start/stop button.

3.2 Porsche Communication Management (PCM)

The PCM system controls navigation, audio, telephone, and other vehicle settings. Refer to the separate PCM manual for detailed instructions.

• Navegació: Input destinations, view maps, and receive turn-by-turn directions.
• Àudio: Select radio stations, play media from various sources (USB, Bluetooth, CD/DVD).
• Telèfon: Connect your mobile phone via Bluetooth for hands-free calling.
• Configuració del vehicle: Customize various vehicle functions, such as lighting, locking, and display settings.

4. Manteniment i cura

Regular maintenance is crucial for the longevity, safety, and performance of your Porsche Macan. Adhere to the recommended service intervals.

4.1 Intervals de servei

Your Macan requires regular service checks at authorized Porsche dealerships. Consult your service schedule booklet for specific intervals based on mileage or time, whichever comes first.

4.2 Comprovació de fluids

• Oli de motor: Check oil level regularly using the digital display in the instrument cluster. Add approved oil if necessary.
• Refrigerant: Ensure coolant level is between MIN and MAX marks when the engine is cold.
• Líquid de frens: Check level periodically. If low, have it inspected by a Porsche service center immediately.
• Líquid rentaparabrises: Keep reservoir filled for clear visibility.

4.3 Cura dels pneumàtics

• Pressió dels pneumàtics: Check tire pressure weekly, especially before long journeys, using the recommended pressures found on the door jamb sticker.
• Banda de rodament del pneumàtic: Inspect for wear and damage. Replace tires when tread depth reaches the minimum legal limit.

5. Resolució de problemes comuns

This section addresses common issues you might encounter and provides basic solutions. For complex problems, contact an authorized Porsche service center.

6. Especificacions tècniques

Key technical data for the 2017 Porsche Macan. Note that specifications may vary based on specific model variants and optional equipment.

• Opcions de motor: V6 Turbocharged (various displacements and power outputs depending on model: Macan, Macan S, Macan GTS, Macan Turbo).
• Transmissió: 7-speed Porsche Doppelkupplung (PDK) automatic.
• Tipus de conducció: All-wheel drive (Porsche Traction Management - PTM).
• Tipus de combustible: Premium Unleaded Gasoline.
• Capacitat del dipòsit de combustible: Approximately 17.2 - 19.8 gallons (65 - 75 liters), depending on model.
• Dimensions (aproximades):
  • Longitud: 184.3 polzades (4681 mm)
  • Width: 76.1 inches (1923 mm) (without mirrors)
  • Alçada: 63.9 polzades (1624 mm)
  • Wheelbase: 110.5 inches (2807 mm)
• Pes lliure: Varies by model, typically 3,900 - 4,300 lbs (1770 - 1950 kg).
• Mides dels pneumàtics: Varies by wheel option, e.g., Front: 235/60 R18, Rear: 255/55 R18 (base model).

For precise specifications for your specific vehicle, refer to the vehicle's documentation or contact an authorized Porsche dealer.

7. Informació de la garantia

Your 2017 Porsche Macan is covered by a comprehensive limited warranty. Details regarding coverage, duration, and exclusions are provided in a separate warranty booklet supplied with your vehicle.

Key aspects typically include:

• Garantia limitada del vehicle nou: Covers defects in materials or workmanship for a specified period/mileage.
• Limited Warranty Against Corrosion Perforation: Covers body panels against rust-through.
• Garantia del sistema de control d'emissions: Specific coverage for emissions-related components.

Always refer to your official Porsche Warranty and Maintenance Handbook for the most accurate and up-to-date information regarding your vehicle's warranty coverage.

8. Atenció al client

For further assistance, technical support, or service inquiries, please contact your authorized Porsche dealer or Porsche Customer Service.

• Authorized Porsche Dealer: Your primary point of contact for service, parts, and vehicle-specific questions. Locate your nearest dealer via the official Porsche weblloc.
• Porsche Customer Service: For general inquiries or to provide feedback. Contact information can typically be found on the official Porsche website or in your vehicle's documentation.
• Recursos en línia: Visit the official Porsche website for additional information, digital manuals, and support resources.

When contacting support, please have your Vehicle Identification Number (VIN) readily available.
