Xiaomi Truclean W10 Ultra Wet Dry Vacuum EU - Instruction Manual

1. Producte acabatview

The Xiaomi Truclean W10 Ultra is a versatile wet and dry vacuum cleaner designed for efficient floor cleaning. It features an all-in-one station for charging and drying, a high-temperature cleaning mode, intelligent stain detection, and a self-cleaning roller brush system.

Image 1.1: The main unit of the Xiaomi Truclean W10 Ultra Wet Dry Vacuum.

Image 1.2: The vacuum cleaner positioned on its all-in-one charging and drying station.

2. Instruccions de configuració

2.1 Desembalatge

Traieu amb cura tots els components de l'embalatge. Verifiqueu que totes les peces que figuren a la llista d'embalatge siguin presents i no estiguin danyades. Conserveu l'embalatge per a futurs transports o emmagatzematge.

2.2 Muntatge

1. Enganxeu el mànec: Insert the handle into the main body of the vacuum cleaner until it clicks securely into place. Ensure it is firmly attached.
2. Position the All-in-One Station: Place the all-in-one station on a flat, stable surface near a power outlet.

2.3 Initial Charging and Water Filling

1. Ompliu el dipòsit d'aigua neta: Remove the clean water tank from the main unit. Fill it with clean tap water up to the 'MAX' line. For hot water cleaning, ensure the water temperature is appropriate (up to 75°C). Reinstall the tank.
2. Carregueu la bateria: Place the assembled vacuum cleaner onto the all-in-one station. Connect the power adapter to the station and plug it into a wall outlet. The LED display on the vacuum will indicate charging status. Fully charge the device before first use.

3. Instruccions de funcionament

3.1 Encès/Apagat

Press and hold the power button on the handle to turn the vacuum cleaner on or off. The LED display will illuminate upon power-on.

3.2 Selecció dels modes de neteja

The vacuum offers multiple cleaning modes. Press the mode selection button on the handle to cycle through available modes:

• Mode automàtic: Automatically adjusts suction power and water flow based on detected dirt levels.
• High-Temperature Mode: Activates the 75°C hot water cleaning for enhanced stain removal and bacterial elimination.
• Mode d'aspiració: For dry vacuuming only.

3.3 Operació de neteja

1. Comença a netejar: Tilt the vacuum cleaner back to activate the roller brush and begin cleaning.
2. Maniobra: The vacuum features an automatic forward assist, making it easy to push and turn. Guide the vacuum over the desired cleaning area.
3. Intelligent Stain Detection: The device will detect stains in real-time and adjust cleaning power accordingly.
4. Seguiment: The 3.2-inch LED digital display provides real-time information on battery level, cleaning mode, and status.

Image 3.1: The vacuum's intelligent stain detection system in action.

4. Manteniment

4.1 Buidar el dipòsit d'aigua bruta

After each use, or when the dirty water tank is full, remove it from the main unit. Open the lid and dispose of the dirty water. Rinse the tank thoroughly with clean water and allow it to air dry before reinstallation.

4.2 Self-Cleaning and Drying Cycle

Place the vacuum cleaner back on the all-in-one station. Press the self-clean button on the station or the vacuum (refer to the display for prompts). The vacuum will initiate a self-cleaning cycle for the roller brush, followed by a 55°C hot air drying process to prevent odors and mold growth.

Image 4.1: The roller brush undergoing its automatic self-cleaning process.

4.3 Neteja del filtre

The filter should be cleaned regularly, typically after every 3-5 uses, or when suction power decreases. Remove the filter from the dirty water tank. Rinse it under running water until clean. Allow it to air dry completely for at least 24 hours before reinserting. Do not use the vacuum without a dry filter.

4.4 Cleaning the All-in-One Station

Periodically wipe down the charging contacts and the base of the station with a damp cloth to remove any dirt or debris. Ensure the station is unplugged before cleaning.

5. Solució De Problemes

Si teniu problemes, consulteu la taula següent per veure els problemes i les solucions més habituals.

6. Especificacions

Key technical specifications for the Xiaomi Truclean W10 Ultra Wet Dry Vacuum:

• Nom del model: Truclean W10 Ultra
• Número de model: B0BBRNWH1V
• Dimensions (L x A x A): 27L x 27W x 110H cm (111 x 27 x 27 cm)
• Pes: 5.3 quilos
• Tipus de bateria: Ió de liti
• Capacitat de la bateria: 3680 mAh
• Temps d'execució: Fins a 35 minuts
• Voltage: 28 Volts
• Potència (Watts): 220 watts
• Capacitat del dipòsit d'aigua neta: 3 litres
• Característiques especials: 3.2" LED Digital Display, Intelligent Stain Detection, 75°C Hot Water Cleaning Mode, 55°C Hot Air Drying Station, Self-Cleaning Roller Brush.
• Tipus de filtre: Foam, Fabric
• Superfície recomanada: Catifa, sòl dur
• Mètode de control: Control del touchpad

7. Garantia i Suport

7.1 Garantia del fabricant

This product is covered by a 2-year manufacturer's warranty. Please retain your proof of purchase for warranty claims. The warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.

7.2 Atenció al client

For technical assistance, troubleshooting beyond this manual, or warranty service, please contact Xiaomi customer support. Contact details can typically be found on the official Xiaomi weblloc web o a l'embalatge del producte.

• Assistència en línia: Visit the official Xiaomi support weblloc.
• Suport telefònic: Refer to your regional Xiaomi contact numbers.
