Generic USB FC2A-KC2 PLC Programming Cable User Manual

1. Introducció

This manual provides instructions for the installation, operation, and maintenance of the Generic USB FC2A-KC2 PLC Programming Cable. This cable facilitates communication between a computer's USB port and IDEC Micro3 or Square D Programmable Logic Controllers (PLCs) for programming, monitoring, and debugging purposes.

2. Informació de seguretat

• Seguretat elèctrica: Always ensure that the PLC and computer are properly grounded. Disconnect power before connecting or disconnecting the cable to the PLC if specified by the PLC manufacturer's guidelines.
• Manipulació: Do not bend, twist, or pull the cable excessively. Avoid exposing the cable to extreme temperatures, moisture, or corrosive environments.
• Ús previst: This cable is designed for programming IDEC Micro3 and Square D PLCs. Do not use it for purposes other than its intended function.
• Modificacions: Do not attempt to modify or repair the cable. Unauthorized modifications can lead to damage, malfunction, or safety hazards.

3. Contingut del paquet

Verifiqueu que tots els elements siguin presents al paquet:

• 1 x Generic USB FC2A-KC2 PLC Programming Cable

Image 1: The Generic USB FC2A-KC2 PLC Programming Cable. This image shows a black USB cable with a standard USB-A connector on one end and a larger, rectangular multi-pin connector on the other end, designed for connecting to compatible PLCs.

4. Requisits del sistema

To use this programming cable, ensure your system meets the following requirements:

• Sistema operatiu: Windows 2000/XP/Vista/7/8/10 (32-bit and 64-bit versions).
• Port USB: An available USB 1.1 or 2.0 port.
• Programari de programació: Compatible PLC programming software for IDEC Micro3 or Square D PLCs (e.g., WindLDR for IDEC, or relevant software for Square D).
• Programari del controlador: USB driver for the FC2A-KC2 cable. This is typically provided on a mini-CD or available for download from the manufacturer's weblloc.

5. Instruccions de configuració

5.1. Instal·lació del controlador

1. Insert Driver Media: If a driver CD is provided, insert it into your computer's CD/DVD drive. If not, download the appropriate USB driver from the manufacturer's support weblloc.
2. Executa l'instal·lador: Locate and run the driver setup executable (e.g., `setup.exe`).
3. Seguiu les indicacions: Follow the on-screen instructions to complete the driver installation. You may need to restart your computer after installation.
4. Verifica la instal·lació: After restarting, connect the USB end of the programming cable to an available USB port on your computer. Open Device Manager (right-click 'My Computer' or 'This PC' > 'Manage' > 'Device Manager'). Look under 'Ports (COM & LPT)' for a new COM port entry, typically labeled 'USB Serial Port' or similar. Note the assigned COM port number.

5.2. Connexió del cable

1. Connexió al PC: Plug the USB-A connector of the programming cable into an available USB port on your computer.
2. Connect to PLC: Connect the multi-pin connector of the programming cable to the designated programming port on your IDEC Micro3 or Square D PLC. Ensure a secure connection.

5.3. Configuració del programari

1. Open PLC Software: Launch your PLC programming software (e.g., WindLDR).
2. Configure Communication Settings: Navigate to the communication settings or options within the software.
3. Seleccioneu el port COM: Choose the COM port number identified in Device Manager during driver installation.
4. Set Baud Rate/Parity: Configure other communication parameters (e.g., baud rate, data bits, parity, stop bits) to match the settings of your specific PLC. Refer to your PLC's documentation for these settings.
5. Prova de connexió: Use the software's 'Test Communication' or 'Connect' function to verify the link between your computer and the PLC.

6. Instruccions de funcionament

Once the cable is connected and configured, you can perform various operations:

• Uploading Programs: Transfer the program from the PLC to your computer for backup or modification.
• Downloading Programs: Transfer a new or modified program from your computer to the PLC. Ensure the PLC is in programming mode if required.
• Monitoring PLC Status: View the real-time status of PLC inputs, outputs, internal relays, and data registers.
• Depuració: Use the software's debugging tools to troubleshoot PLC logic and program execution.
• Actualitzacions de firmware: If supported by your PLC and software, the cable can be used for firmware updates.

Always refer to your specific PLC programming software's user manual for detailed instructions on these operations.

7. Manteniment

Proper care ensures the longevity and reliable performance of your programming cable:

• Neteja: Keep the cable and connectors clean. Use a soft, dry cloth to wipe away dust or debris. Do not use liquid cleaners directly on the connectors.
• Emmagatzematge: Store the cable in a cool, dry place away from direct sunlight and extreme temperatures. Avoid tightly coiling the cable to prevent internal wire damage.
• Inspecció: Periodically inspect the cable for any signs of damage, such as frayed insulation, bent pins, or cracked connectors. Replace the cable if any damage is observed.

8. Solució De Problemes

Si teniu problemes, tingueu en compte els passos següents per resoldre'ls:

9. Especificacions

• Model: FC2A-KC2
• Connector Type (PC Side): USB-A Mascle
• Connector Type (PLC Side): Proprietary multi-pin connector for IDEC Micro3 / Square D PLCs
• Tipus de cable: Cable de programació USB
• Ús interior/exterior: Interior, Exterior
• Fabricant: PLC Cables, Inc
• UPC: 791109157589

10. Garantia i Suport

For technical support, warranty information, or to report issues with your Generic USB FC2A-KC2 PLC Programming Cable, please contact the seller or manufacturer directly. Refer to your purchase documentation for specific contact details and warranty terms.
