Richmat HJH55 Remote Control User Manual

Introducció

This manual provides detailed instructions for the Richmat HJH55 wireless remote control, specifically for Remote B, designed for adjustable bed bases. It covers setup, operation, and troubleshooting to ensure proper functionality with compatible adjustable bed systems.

This remote control is compatible with various adjustable bed brands including MLILY, MATTRESS FIRM, CLASSIC BRANDS, and INNOVA. Always verify compatibility with your specific control box device.

Producte acabatview

The Richmat HJH55 Remote Control (Remote B) features a backlit design and a range of buttons for controlling your adjustable bed's functions.

Figura 1: Frontal view of the Richmat HJH55 Remote Control (Remote B). This image displays the layout of all buttons, including TV, Anti-Snore, ZG, Head Up/Down, Foot Up/Down, M1, M2, M3, 10 Min, 20 Min, Head, Flat, Foot, Timer/All Off, Light, and Mode.

Figure 2: Comparison image showing Remote A and Remote B. Remote B, the subject of this manual, is distinguished by the "Anti-Snore" button, "M3" button, and "Flat" button, as opposed to Remote A's "Lounge" and different button configurations.

Figura 3: Detallada view of Remote B, emphasizing the "Anti-Snore", "M3", and "Flat" buttons, which are key identifiers for this specific remote model.

Funcions del botó:

• TV: Adjusts the bed to a TV viewposició d'ingrés.
• ANTI SNORE: Adjusts the head section to a position designed to reduce snoring.
• ZG (Zero Gravity): Moves the bed to a zero-gravity position, elevating both head and foot sections.
• HEAD UP/DOWN Arrows: Adjusts the head section of the bed up or down.
• FOOT UP/DOWN Arrows: Adjusts the foot section of the bed up or down.
• M1, M2, M3: Memory preset buttons to save and recall preferred bed positions.
• 10 MIN / 20 MIN: Timer functions for massage or other timed operations (if supported by bed base).
• CAP: Returns the head section to a flat position.
• PIS: Returns the entire bed to a flat position.
• PEU: Returns the foot section to a flat position.
• TIMER / ALL OFF: Activates/deactivates timer or turns off all functions.
• Botó de llum: Activates/deactivates under-bed lighting (if supported by bed base).
• Mode: Cycles through different massage modes (if supported by bed base).

Configuració

1. Instal·lació de la bateria:

The Richmat HJH55 remote control requires two (2) AAA batteries (not included).

1. Localitzeu el compartiment de la bateria a la part posterior del comandament a distància.
2. Slide the battery compartment cover downwards to open.


Figura 4: Esquena view of the remote control, showing the battery compartment cover.

3. Introduïu dues piles AAA, assegurant-vos de la polaritat correcta (+ i -) tal com s'indica a l'interior del compartiment.


Figura 5: Esquena view del comandament a distància amb el compartiment de les piles obert, que mostra l'orientació correcta per a la inserció de piles AAA.

4. Feu lliscar la tapa del compartiment de la bateria fins que faci clic de manera segura.

2. Instruccions d'aparellament:

The remote control does not come pre-paired with your adjustable bed base. You must pair it according to the instructions provided by your bed base's manufacturer. The general pairing process for Richmat systems often involves the following steps:

Figure 6: Illustration of the remote control and a compatible Richmat control box, emphasizing the connection required for pairing.

1. Ensure your adjustable bed base is plugged into a working power outlet.
2. Locate the control box under your bed base. It typically has a "Learn" or "Pair" button.

Figure 7: Close-up of the Richmat control box label, confirming Model: HJH55 and FCC ID: 2AJJGHJRF. This label helps verify compatibility.
3. Press and hold the "Learn" or "Pair" button on the control box for a few seconds until an indicator light (usually blue or green) starts flashing.
4. Within 10 seconds of the light flashing, press and hold the "Head Up" and "Foot Up" buttons simultaneously on your Richmat HJH55 remote control.
5. Hold the buttons until the indicator light on the control box stops flashing and becomes solid, or until the bed base responds. This indicates successful pairing.
6. Test all remote functions to ensure proper operation.

Note: Specific pairing procedures may vary slightly by bed base model and manufacturer. Refer to your adjustable bed base's original user manual for precise pairing instructions if these steps do not work.

Instruccions de funcionament

Once paired, the remote control allows you to adjust your bed base to various positions and utilize additional features.

• Adjusting Head and Foot: Utilitza el CAP AMUNT/BAIX i FOOT UP/DOWN arrow buttons to independently raise or lower the head and foot sections of your bed.
• Posicions preestablertes:
  • Premeu TV to move the bed to a comfortable TV viewposició d'ingrés.
  • Premeu ANTI RONC to slightly elevate the head section, which may help reduce snoring.
  • Premeu ZG for the Zero Gravity position, which elevates both the head and foot to promote circulation and reduce pressure.
• Memory Presets (M1, M2, M3):
  1. Adjust the bed to your desired position.
  2. Press and hold the desired memory button (M1, M2, o M3) until the bed briefly moves or a confirmation light/sound occurs. This saves the current position.
  3. Per recuperar una posició desada, només cal prémer el botó de memòria corresponent.
• Posició plana: Premeu el botó PIS button to quickly return the entire bed base to a completely flat position.
• Individual Section Flat: Utilitza el CAP button to flatten only the head section, and the PEU button to flatten only the foot section.
• Funcions del temporitzador: El 10 MIN i 20 MIN buttons may activate timed massage or other features if your bed base supports them. Consult your bed base manual for details.
• Control de la llum: Premeu el botó Botó de llum (flashlight icon) to turn on or off any integrated under-bed lighting.
• Control de mode: El MODE button may cycle through different massage modes or other functions.
• Timer / All Off: This button can activate a general timer or turn off all active functions.

Manteniment

Substitució de la bateria:

Replace batteries when the remote's response becomes sluggish or if the backlight dims. Follow the battery installation steps outlined in the "Setup" section.

• Always use new AAA batteries.
• No barregeu piles velles i noves, o diferents tipus de piles.
• Traieu les piles si no heu d'utilitzar el comandament a distància durant un període prolongat per evitar fuites.
• Eliminar les bateries usades de manera responsable d'acord amb la normativa local.

Resolució de problemes

If troubleshooting steps do not resolve the issue, please contact the manufacturer of your adjustable bed base for further assistance.

Especificacions

• Model: HJH55 (Remote B)
• Marca: Generic (Compatible with Richmat systems)
• Font d'alimentació: 2 piles AAA (no incloses)
• Color: Negre
• Característica especial: Botons retroil·luminats
• Dispositius compatibles: MLILY, MATTRESS FIRM, CLASSIC BRANDS, INNOVA adjustable bed bases (verify control box compatibility)
• Identificador FCC: 2AJJGHJRF (as seen on compatible control box)

Garantia i Suport

This product is a replacement remote control. Warranty coverage, if any, is typically provided by the seller or the original manufacturer of the remote. For specific warranty information or technical support related to the remote control, please refer to the seller's policy or contact the manufacturer directly.

For issues related to your adjustable bed base, including pairing difficulties not resolved by these instructions, please contact the manufacturer of your bed base (e.g., MLILY, MATTRESS FIRM, CLASSIC BRANDS, INNOVA).
