AZDOME M300S Dash Cam User Manual

1. Introducció

Welcome to the AZDOME M300S Dash Cam user manual. This guide provides detailed instructions for setting up, operating, maintaining, and troubleshooting your new dash camera. Please read this manual thoroughly before use to ensure optimal performance and longevity of your device.

1.1 Producte acabatview

The AZDOME M300S is a high-performance dual dash camera system designed to record both front and rear views of your vehicle in stunning 4K and 1080P resolution respectively. It features built-in 5.8G WiFi for seamless app connectivity, GPS for accurate route tracking, voice control for hands-free operation, G-Sensor for emergency recording, and 24-hour parking monitoring capabilities.

Figure 1.1: AZDOME M300S Dash Cam with phone showing app interface and included 64GB SD card.

2. Què hi ha a la caixa

Verifiqueu que tots els elements que s'enumeren a continuació siguin presents al vostre paquet:

• Càmera de salpicadero 4K (unitat frontal)
• Càmera posterior
• Type-C USB Power Cable (3.5m/12ft)
• Carregador de cotxe
• 64GB SD Card (pre-installed)
• Crowbar (Pry Tool)
• Clips de cable (5 peces)
• Adhesius electrostàtics (2 peces)
• Cinta de doble cara
• Manual d'usuari

Figure 2.1: Diagram showing all components included in the AZDOME M300S Dash Cam package.

3. Guia de configuració

3.1 Preparació per a la instal·lació

1. Neteja el parabrisa: Ensure the installation area on your windshield is clean and dry. Use the provided electrostatic stickers for optimal adhesion and easy removal.
2. Inseriu la targeta SD: The 64GB Micro SD card is pre-installed. If replacing, ensure it's a Class 10 or higher U3 speed card, up to 256GB.

Figure 3.1: Close-up of the AZDOME M300S dash cam unit.

3.2 Instal·lació de la càmera frontal

1. Attach the adhesive mount to the front dash cam.
2. Apply an electrostatic sticker to the desired location on your windshield, ideally behind the rearview mirror for minimal obstruction.
3. Firmly press the dash cam with its adhesive mount onto the electrostatic sticker.

3.3 Instal·lació de la càmera posterior

1. Connect the rear camera cable to the main front unit's AV port.
2. Mount the rear camera on your rear windshield using its adhesive mount. Ensure the lens has a clear view.
3. Route the rear camera cable neatly along the vehicle's headliner and A-pillars using the provided cable clips and pry tool.

Figure 3.2: Recommended cable routing for the AZDOME M300S dash cam.

3.4 Connexió d'alimentació

1. Plug the Type-C USB power cable into the main dash cam unit.
2. Inseriu el carregador del cotxe a la presa de l'encenedor del vostre vehicle.
3. Route the power cable neatly using the provided cable clips and pry tool.

4. Instruccions de funcionament

4.1 Engegada i configuració inicials

1. Un cop connectada a l'alimentació, la càmera del salpicader s'encén automàticament i comença a gravar.
2. Download the "AZDOME" app from your smartphone's app store (available on iOS and Android).
3. Connect your smartphone to the dash cam's built-in 5.8G WiFi network (SSID and password usually found on the device or manual).
4. Use the app to format the Micro SD card before first use.
5. Adjust settings such as video resolution (4K front + 1080P rear recommended), loop recording duration, G-Sensor sensitivity, and parking monitor mode via the app.

Figure 4.1: AZDOME M300S Dash Cam connected to smartphone via 5G WiFi.

4.2 ordres de control per veu

The AZDOME M300S supports smart voice control for hands-free operation:

• "Fes una foto" - Captures a still image.
• "Bloqueja el vídeo" - Locks the current recording to prevent overwriting.
• "Activa el Wi-Fi" - Activates the WiFi hotspot.
• "Turn off WiFi" - Deactivates the WiFi hotspot.
• "Turn off recording" - Stops current recording.
• "Open Recording" - Starts recording.

Figure 4.2: Driver interacting with the AZDOME M300S dash cam using voice commands.

4.3 Funcionalitat del GPS

The built-in GPS module accurately records your driving route and speed. This data can be viewed and analyzed using the AZDOME GPS Player software on your computer or within the AZDOME app.

Figure 4.3: AZDOME M300S dash cam's GPS tracking feature.

5. Característiques clau

5.1 4K Front + 1080P Rear Recording

Capture crystal-clear footage of both the road ahead and behind your vehicle. The front camera records in 4K (3840x2160P) and the rear in Full HD 1080P.

Figure 5.1: Visual comparison of 4K front and 1080P rear video quality.

5.2 Supervisió nocturna

Equipped with an F1.8 aperture lens and WDR (Wide Dynamic Range) technology, the dash cam provides enhanced clarity and detail in low-light conditions, ensuring clear recordings even at night.

Figure 5.2: Comparison of night vision clarity with and without WDR technology.

5.3 Monitor d'aparcament les 24 hores

The dash cam offers two parking monitoring modes:

• Mode d'estacionament de detecció de col·lisions: The G-Sensor detects impacts and automatically records a 1-minute emergency video.
• Mode d'estacionament temporal: Requires a 3-lead hardwire kit (sold separately, search ASIN: B0BGHQN5RP). Records continuously at 1fps, compressing 24 hours of footage into a short video.

Figure 5.3: 24-Hour Parking Monitor features.

5.4 Sensor G i gravació en bucle

The built-in G-Sensor detects sudden movements or impacts and automatically locks the current video segment to prevent it from being overwritten. Loop recording ensures continuous recording by overwriting the oldest unlocked footage quan la targeta SD està plena.

Figure 5.4: G-Sensor activated emergency recording and continuous loop recording.

6. Manteniment

6.1 Cura de la targeta SD

• Regularly format the Micro SD card (at least once a month) to prevent data corruption and ensure smooth operation.
• Use only high-quality, reputable brand Micro SD cards (Class 10, U3 recommended).
• Avoid removing or inserting the SD card while the device is powered on to prevent damage.

6.2 Neteja

• Feu servir un drap suau i sec per netejar la lent i el cos de la càmera.
• Do not use chemical cleaners or solvents, as they may damage the device.

6.3 actualitzacions de microprogramari

• Check the AZDOME official weblloc web o aplicació periòdicament per obtenir actualitzacions de firmware.
• Follow the provided instructions carefully when performing firmware updates to avoid bricking the device.

7. Solució De Problemes

7.1 Problemes comuns i solucions

If you encounter issues not listed here or solutions do not resolve the problem, please contact AZDOME customer support.

8. Especificacions

9. Garantia i Suport

AZDOME M300S comes with a 12-month assurance and 24/7 technical support. For any problems or inquiries regarding after-sales service, please contact us via email. Our R&D team aims to respond within 24 working hours.

For further assistance, visit the official AZDOME Store: AZDOME Store
