Novzix S1 Android Compatible Smart Tracker Tag Manual d'usuari

1. Introducció

The Novzix S1 Smart Tracker Tag is designed to help you locate your belongings using the Google Find My Device network. This 2026 model offers stable performance and integrates seamlessly with Android devices running Android 9 and above. Its compact and durable design, featuring water and dust resistance, makes it suitable for various daily scenarios.

Novzix S1 Smart Tracker Tag attached to various items like keys, wallets, backpacks, and suitcases, demonstrating its versatility.

Figure 1: Versatile Use Cases for the Novzix S1 Smart Tracker Tag

2. Contingut del paquet

Si us plau, comproveu el paquet per veure si hi ha els elements següents:

Novzix S1 Tracker Tag (bateria inclosa)
Clauer
Manual d'instruccions (aquest document)
Extra replacement battery

Image showing the Novzix S1 Tracker Tag, a keychain, an instruction manual, and an extra battery, laid out as package contents.

Figure 2: Novzix S1 Smart Tracker Tag Contingut del paquet

3. Instruccions de configuració

To begin using your Novzix S1 Smart Tracker Tag, follow these steps to connect it with your Android device via the Google Find My Device app.

Comprovació de compatibilitat: Ensure your Android device is running Android 9 or above. Some devices may require system updates for optimal compatibility.
Descarrega l'aplicació: Download and install the "Google Find My Device" app from the Google Play Store on your Android smartphone or tablet.
Activa el Bluetooth: Assegureu-vos que el Bluetooth estigui activat al vostre dispositiu Android.
Activa el rastrejador: The Novzix S1 Tracker Tag comes with a pre-installed battery. If it's not already active, press the button on the tracker to wake it up.
Open Find My Device App: Launch the Google Find My Device app. You may need to sign in with your Google account.
Afegeix un dispositiu nou: Follow the in-app instructions to add a new device. The app should detect your Novzix S1 Tracker Tag a prop.
Maridatge: Select your Novzix S1 Tracker Tag from the list of available devices and follow the prompts to complete the pairing process.
Name Your Tracker: Once paired, you can name your tracker (e.g., "Keys," "Wallet," "Backpack") within the app for easy identification.

Nota: The setup process requires a few steps and a short configuration time. Clear instructions are provided within the Google Find My Device app.

A Novzix S1 Smart Tracker Tag next to a smartphone displaying the Google Find My Device app interface, showing a map and a 'Playing sound' option.

Figure 3: Integrating with Google Find My Device App

4. Instruccions de funcionament

The Novzix S1 Smart Tracker Tag utilizes the Google Find My Device network to help you locate your items.

4.1. Global Tracking

Leveraging over a billion Android devices worldwide, the Google Find My Device network allows for crowdsourced tracking. This means you can locate your items globally, even if they are far from your own device. The app provides location updates every 3-30 minutes.

Figure 4: Global Tracking via Google Find My Device

4.2. Find Nearby

When your item is within Bluetooth range, you can use the "Play Sound" feature in the Google Find My Device app to make your tracker emit an audible alert, helping you pinpoint its exact location. The app may also provide visual cues indicating proximity.

A hand holding a smartphone displaying the Google Find My Device app, showing a green pulsating circle to indicate proximity to 'Elisa's keys', which are hidden behind a sofa cushion.

Figure 5: Using the "Play Sound" Feature to Locate Nearby Items

4.3. Loss Prevention Alerts

The Novzix S1 can alert you if you leave an item behind or if it moves away from your designated safe zone. This feature helps prevent loss by notifying you promptly.

A smartphone screen showing a 'Mark as lost' option and a notification that 'SmartTrack 01' has moved away, with keys and a tracker tag on a table in the foreground.

Figure 6: Loss Prevention Notification Example

5. Manteniment i substitució de la bateria

The Novzix S1 Smart Tracker Tag is designed for low power consumption, providing approximately one year of battery life. It uses a replaceable battery.

5.1. Battery Type and Replacement

The tracker uses CR2 batteries. An extra replacement battery is included in your package. To replace the battery:

Obriu amb cura el rastrejador casing. Refer to the diagram below for component identification.
Traieu la bateria CR2 antiga.
Insert the new CR2 battery, ensuring correct polarity.
Tanca el rastrejador casing de manera segura.

Explotat view diagram of the Novzix S1 Smart Tracker Tag showing its components: plastic face cover, PCB board, CR2 battery, plastic back cover, and plastic button.

Figure 7: Internal Components and Battery Location

5.2. Durabilitat

The Novzix S1 is constructed with high-quality materials, offering water and dust resistance. This design allows it to withstand various environmental conditions, including rain and outdoor use.

6. Solució De Problemes

If you encounter issues with your Novzix S1 Smart Tracker Tag, consulteu els següents problemes i solucions habituals:

Problema	Causa possible	Solució
El rastrejador no es connecta al telèfon.	Bluetooth is off; app not installed; tracker battery low; device not compatible.	Ensure Bluetooth is on. Install "Google Find My Device" app. Check battery level and replace if necessary. Verify Android 9+ compatibility.
Cannot hear the tracker's sound.	Tracker is out of Bluetooth range; sound volume too low; obstruction.	Move closer to the tracker. Ensure the sound feature is activated in the app. Check for physical obstructions.
Location updates are inaccurate or slow.	Limited network coverage; tracker is in an area with few Android devices.	Location updates depend on the density of the Google Find My Device network. Updates occur every 3-30 minutes.
La bateria s'esgota ràpidament.	Frequent use of sound feature; old battery.	Reduce frequent "Play Sound" activations. Replace battery with a new CR2 battery.

7. Especificacions

Número de model	S1
Marca	Novzix
Dispositius compatibles	Android phones (Android 9 and above), Google Pixel, Samsung Phone
Tecnologia de connectivitat	NFC, Wireless (Bluetooth)
Tipus de bateria	CR2 (3 batteries required, 1 pre-installed, 1 spare included)
Durada estimada de la bateria	Fins a 1 any
Material	Plàstic
Pes de l'article	2.39 unces
Dimensions	3.46 x 2.8 x 1.42 polzades (dimensions del paquet)
Resistència a l'aigua/pols	Yes (designed to withstand rain and outdoor conditions)

8. Informació de seguretat

Mantingueu el dispositiu i els seus accessoris fora de l'abast dels nens petits i de les mascotes.
No intenteu desmuntar, modificar o reparar el dispositiu vosaltres mateixos.
Avoid exposing the device to extreme temperatures, direct sunlight, or open flames.
Elimineu les piles d'acord amb la normativa local. No incinereu les piles.
If the device is damaged or malfunctions, discontinue use and contact support.

9. Garantia i Suport

For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official Novzix weblloc.

Novzix S1
