Seco-Larm PR-K1K1-AQ Proximity Keyfobs User Manual

1. Introducció

The Seco-Larm PR-K1K1-AQ Proximity Keyfobs are designed for use with compatible Seco-Larm access control readers. These keyfobs provide a convenient and secure method for gaining access to controlled areas. Each keyfob operates at a frequency of 125kHz and contains a unique identification code, allowing for seamless integration into existing Seco-Larm access control systems.

This manual provides essential information regarding the setup, operation, maintenance, and specifications of your PR-K1K1-AQ keyfobs.

Image 1.1: Seco-Larm PR-K1K1-AQ Proximity Keyfobs. This image displays two black, rectangular keyfobs with rounded corners, designed for attachment to a keychain. They feature a small, circular indentation on one side.

2. Configuració

The PR-K1K1-AQ keyfobs are passive devices and do not require batteries or internal setup. Their primary setup involves enrolling them into a compatible Seco-Larm access control reader or system.

1. Comprovació de compatibilitat: Ensure your access control reader or system is compatible with 125kHz EM125 proximity keyfobs. The PR-K1K1-AQ keyfobs are designed for use with all Seco-Larm proximity readers.
2. Procés d'inscripció: Refer to the specific instruction manual for your Seco-Larm access control reader or system for detailed steps on how to enroll new keyfobs. This process typically involves placing the keyfob near the reader while the system is in programming mode.
3. Prova: After enrollment, test the keyfob by presenting it to the reader to confirm it grants access as expected.

Each keyfob is pre-programmed with a unique identification number that the access control system uses to grant or deny access.

3. Instruccions de funcionament

Using the Seco-Larm PR-K1K1-AQ keyfob is straightforward once it has been enrolled into your access control system.

1. Present the Keyfob: Hold the keyfob within close proximity (typically 1-3 inches or 2.5-7.5 cm) of the compatible Seco-Larm proximity reader.
2. Wait for Indication: The reader will typically provide a visual (e.g., LED light change) or audible (e.g., beep) indication to confirm that the keyfob has been read successfully.
3. Access Granted/Denied: If the keyfob is recognized and authorized by the system, access will be granted (e.g., door unlocks). If not, access will be denied.

Ensure there are no metallic objects or other RFID devices directly between the keyfob and the reader, as this may interfere with the reading process.

4. Manteniment

The PR-K1K1-AQ keyfobs are designed for durability and require minimal maintenance.

• Neteja: Wipe the keyfob with a soft, dry cloth if it becomes dirty. Avoid using harsh chemicals or abrasive cleaners.
• Condicions ambientals: Avoid exposing the keyfob to extreme temperatures, direct sunlight for prolonged periods, or corrosive liquids.
• Danys físics: While durable, avoid dropping the keyfob from significant heights or subjecting it to excessive force, which could damage its internal components.
• Sense piles: These keyfobs are passive and do not contain batteries, so no battery replacement is ever needed.

5. Solució De Problemes

If you encounter issues with your PR-K1K1-AQ keyfob, consider the following:

• Keyfob Not Granting Access:
  • Ensure the keyfob is properly enrolled in the access control system.
  • Verify that the keyfob is presented correctly and within the reading range of the proximity reader.
  • Check the status of the access control reader and system for any error indicators or power issues.
  • Confirm that the keyfob has not been deactivated or removed from the system's authorized credentials.
• Intermittent Reading:
  • Remove any metallic objects (e.g., other keys, metal cards) that might be interfering with the keyfob's signal when presented to the reader.
  • Ensure the keyfob is not damaged.
• Lost Keyfob: If a keyfob is lost or stolen, immediately remove its unique ID from your access control system to prevent unauthorized access. Refer to your access control system's manual for instructions on how to delete credentials.

6. Especificacions

7. Garantia i Suport

For information regarding the warranty of your Seco-Larm PR-K1K1-AQ Proximity Keyfobs, please refer to the warranty documentation included with your purchase or visit the official Seco-Larm weblloc. Els termes i condicions de la garantia poden variar.

For technical support, product inquiries, or further assistance, please contact Seco-Larm customer service through their official channels. Always provide your product model number (PR-K1K1-AQ) when seeking support.
