1. Introducció
This manual provides essential information for the safe and efficient use of your Bosch PIJ631HC1E Induction Hob. Please read these instructions carefully before installation and operation, and retain them for future reference. This appliance is designed for domestic use only.
2. Informació de seguretat
Observe the following safety precautions to prevent personal injury or damage to the appliance:
- Seguretat elèctrica: Ensure the appliance is correctly earthed and connected to a suitable power supply. Do not use adapters or extension cords.
- Risc de cremades: The hob surface becomes hot during operation. Do not touch hot surfaces. Always use oven mitts.
- Sobreescalfament: Never leave cooking unattended. Overheated fats and oils can ignite.
- Objectes estrangers: Do not place metallic objects such as knives, forks, spoons, or lids on the hob surface as they can become hot.
- Nens i persones vulnerables: Aquest aparell el poden utilitzar nens a partir de 8 anys i persones amb capacitats físiques, sensorials o mentals reduïdes o amb manca d'experiència i coneixements si han rebut supervisió o instruccions sobre l'ús de l'aparell d'una manera segura i entenen els perills que comporta. .
- Marcapassos: Persons with pacemakers should consult their doctor before using an induction hob.
- Neteja: Desconnecteu l'aparell de la xarxa elèctrica abans de netejar-lo.
3. Configuració i instal·lació
Proper installation is crucial for the safe and efficient operation of your induction hob. Installation should be performed by a qualified technician.
3.1 Dimensions del producte
The Bosch PIJ631HC1E Induction Hob measures 52.5 cm (depth) x 59.2 cm (width) x 5.1 cm (height).
3.2 Installation Niche Requirements
An installation niche of 5.1 cm (height) x 56 cm (width) x 49-50 cm (depth) is required. Ensure adequate ventilation space around the appliance.
3.3 Connexió elèctrica
The hob operates at 230 Volts and has a maximum power consumption of 7400 watts. It features a maximum power limit to 7.4 kW to prevent tripping circuit breakers in households with limited set power.
4. Instruccions de funcionament
Your Bosch PIJ631HC1E Induction Hob is designed for intuitive cooking with advanced features.
4.1 DirectSelect Controls
The DirectSelect electronics provide easy and direct access to all settings and 17 power levels with a single touch. Simply select the desired cooking zone and adjust the power level.
4.2 Zones de Cocció
The hob features three induction cooking zones:
- One 28 cm zone
- Two 21 cm zones
- One 15 cm zone
Ensure that cookware is suitable for induction hobs and covers the cooking zone adequately for optimal performance.
4.3 PerfectFry Plus Function
The PerfectFry Plus function helps maintain the oil temperature throughout the cooking process, preventing food from burning and promoting healthier cooking results. The display will show the current temperature setting.
4.4 Home Connect Integration
Connect your induction hob to the Home Connect app to control the hob and a compatible cooker hood simultaneously. The app offers additional functions and allows for remote diagnostics in case of a malfunction, potentially speeding up service.
4.5 Funcions addicionals
The hob includes several convenient features:
- PowerMove: Allows for quick changes in power levels by moving cookware.
- Inici automàtic: Detects cookware and activates the corresponding zone.
- Sprint Function: Provides a temporary power boost for rapid heating.
- Funció de memòria: Recalls previous cooking settings.
- Funció de mantenir la calor: Manté els aliments a la temperatura de servei.
- Funció de neteja: Locks the control panel for easy cleaning without changing settings.
- Bloqueig per a nens: Evita el funcionament accidental.
- Indicador de calor residual: Shows which zones are still hot after use.
- Apagat automàtic: Enhances safety by turning off the hob after a period of inactivity.
- Cooking Time Programming: Set specific cooking durations for each zone.
- Cronòmetre: A convenient timer function.
5. Manteniment i Neteja
Una neteja i un manteniment regulars garantiran la longevitat i el rendiment òptim de la placa de cuina.
- Neteja diària: After each use, wipe the hob surface with a soft cloth and a mild detergent. Rinse with clean water and dry thoroughly.
- Taques obstinades: For burnt-on food or stubborn stains, use a specialized ceramic hob scraper or cleaner. Follow the product instructions carefully.
- Eviteu els abrasius: No utilitzeu netejadors abrasius, fregalls ni productes químics agressius, ja que poden ratllar o danyar la superfície del vidre.
- Tauler de control: Netegeu el tauler de control amb anunciamp cloth. Ensure it is dry before operating the hob.
- Inspecció: Periodically check the hob for any signs of damage or wear. If any issues are found, contact customer service.
6. Solució De Problemes
If you encounter issues with your hob, refer to the following common solutions before contacting service.
- Hob Not Turning On: Check if the appliance is properly connected to the power supply. Ensure the child lock is not activated.
- No Heat from Cooking Zone: Verify that the cookware is suitable for induction and correctly positioned on the zone.
- Codis d'error: If an error code appears on the display, consult the full appliance manual or contact Bosch customer service for specific guidance.
- Sorolls inusuals: A faint humming or buzzing sound is normal during induction cooking, especially at higher power levels. This is due to the electromagnetic field.
- Hob Shuts Off Unexpectedly: This could be due to overheating (e.g., if a pan boils dry) or an automatic safety shut-off. Allow the hob to cool down before attempting to restart.
7. Especificacions
| Marca | BOSCH |
| Número de model | PIJ631HC1E |
| Dimensions del producte (P x A x A) | 52.5 x 59.2 x 5.1 cm |
| Pes de l'article | 10.7 quilos |
| Material | Vidre |
| Material de la superfície de l'escalfador | Vidre |
| Potència/Wattage | 7400 watts |
| Voltage | 230 Volts |
| Elements de calefacció | 3 |
| Tipus de cremador | Inducció |
| Característiques especials | Adjustable Temperature, Beveled Edge, Programmable, Safety Lock |
8. Informació de la garantia
Your Bosch PIJ631HC1E Induction Hob comes with a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms, conditions, and duration. Keep your proof of purchase for any warranty claims.
9. Atenció al client
For further assistance, technical support, or to schedule a service appointment, please contact Bosch customer service. You can find contact details on the official Bosch weblloc web o a la documentació que s'inclou amb l'aparell.
Online resources and FAQs may also be available on the Bosch weblloc: www.bosch-home.com
