Introducció
Thank you for choosing the Vortex POWERHUB20 20000mAh Portable Power Bank. This robust and high-performance external battery is designed to meet all your on-the-go charging needs. With an impressive 20000mAh capacity, it can recharge your devices multiple times. Equipped with LED battery percentage indicators and an ON/OFF button, you have full control over your device's power. This power bank allows you to charge up to 3 devices simultaneously via its USB and Type-C ports. Compact and portable, the POWERHUB20 is the perfect accessory to stay powered while traveling.
Característiques del producte
- High Capacity 20000 mAh: Recharges smartphones or tablets up to 5 times.
- Càrrega simultània: Features 2 USB ports and 1 Type-C port (input/output) for charging up to 3 devices concurrently.
- Recàrrega ràpida: Supports charging via Type-C & Micro-USB ports. A USB-Type C cable is included.
- Pantalla LED integrada: Monitors battery level with clear LED indicators. Includes an ON/OFF button for power control.
- Disseny robust: Compact ABS casing (14.8 × 7 × 2.8 cm), making it easy to transport.
Contingut del paquet
- Vortex POWERHUB20 20000mAh Portable Power Bank
- Cable de càrrega USB tipus C
- Manual d'usuari (aquest document)
Producte acabatview
Imatge 1: Davant view of the Vortex POWERHUB20 power bank, highlighting its 20000mAh capacity and showing various devices it can charge.
Imatge 2: En angle view of the Vortex POWERHUB20 power bank, illustrating the various input and output ports and the LED battery level indicators.
The POWERHUB20 features a sleek black design with multiple ports for versatile charging. On one side, you will find two USB-A output ports, a Micro-USB input port, and a USB-C port that functions as both input and output. A series of LED lights indicate the remaining battery charge.
- OUT1/OUT2: USB-A Output Ports (DC 5V 2A)
- EN: Micro-USB Input Port (DC 5V 2A)
- DINS FORA: Type-C Input/Output Port (DC 5V 2A)
- Indicadors LED: Display battery charge level
- Botó ON/OFF: Activates/deactivates the power bank
Configuració
- Càrrec inicial: Before first use, fully charge the POWERHUB20 power bank. Connect the included USB-Type C cable to the power bank's Type-C input/output port or a Micro-USB cable (not included) to the Micro-USB input port. Connect the other end to a USB wall adapter (not included) or a computer's USB port.
- Càrrega del monitor: The LED indicators will light up to show the charging progress. All LEDs will be solid when fully charged.
Instruccions de funcionament
Carregant el Power Bank
- Connect the power bank to a power source using either the Micro-USB input port or the Type-C input/output port.
- The LED indicators will flash to show the charging status. When all LEDs are solid, the power bank is fully charged.
Càrrega de dispositius externs
- Connect your device's charging cable to one of the power bank's USB-A output ports (OUT1/OUT2) or the Type-C input/output port.
- Connecteu l’altre extrem del cable al dispositiu.
- Press the ON/OFF button on the power bank to begin charging. The LED indicators will illuminate to show the remaining power.
- Pots carregar fins a tres dispositius simultàniament.
- Once your device is fully charged, disconnect it from the power bank. The power bank will automatically turn off after a period of inactivity.
Guia d'indicadors LED
- 4 LEDs Solid: 75-100% de càrrega restant
- 3 LEDs Solid: 50-75% de càrrega restant
- 2 LEDs Solid: 25-50% de càrrega restant
- 1 LED Solid: 0-25% charge remaining (recharge soon)
- LEDs intermitents: Indicates the power bank is currently charging.
Manteniment
- Neteja: Feu servir un drap suau i sec per netejar el banc d'energia. No utilitzeu productes químics agressius ni materials abrasius.
- Emmagatzematge: Guardeu el banc d'energia en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
- Durada de la bateria: Per allargar la durada de la bateria, carregueu completament el banc d'energia almenys un cop cada tres mesos si no l'utilitzeu regularment.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El banc d'energia no es carrega | Cable not connected properly; faulty cable/adapter; power bank fully discharged. | Ensure cables are securely connected. Try a different cable or wall adapter. Allow a few minutes for the power bank to respond if completely drained. |
| El dispositiu no es carrega des del banc d'energia | Power bank is off; power bank is out of charge; faulty cable; device incompatibility. | Press the ON/OFF button. Check LED indicators for remaining charge. Try a different charging cable. Ensure your device is compatible with 5V 2A charging. |
| Càrrega lenta | Using a low-power adapter/cable; device drawing high current; multiple devices charging. | Use a 5V 2A (or higher) wall adapter for faster charging of the power bank. Ensure your device's cable is not damaged. Charging multiple devices simultaneously may reduce individual charging speed. |
Especificacions
| Model: | POWERHUB20 |
| Capacitat de la bateria: | 20000 mAh (Milliampabans de l'hora) |
| Tipus de bateria: | Polímer de liti |
| Material de l'habitatge: | ABS |
| Entrada micro-USB: | DC 5V 2A |
| Entrada/sortida tipus C: | DC 5V 2A |
| Sortida USB-A (x2): | DC 5V 2A |
| Dimensions: | 14.8 × 7 × 2.8 cm (approximate) |
| Ús recomanat: | Smartphones, Tablets, other USB-powered devices |
| Origen: | Xina |
Informació de seguretat
- No exposeu el banc d'energia extern a temperatures extremes (superiors a 45 °C o inferiors a 0 °C), a la llum solar directa ni al foc.
- No exposar a l'aigua ni a una humitat elevada.
- Do not disassemble, crush, puncture, or short-circuit the power bank.
- Mantenir fora de l'abast dels nens.
- Feu servir només cables originals o certificats per carregar el banc d'alimentació i els vostres dispositius.
- If the power bank swells, emits an odor, or becomes excessively hot, discontinue use immediately.
- Elimineu el producte de manera responsable d'acord amb la normativa local. No el llenceu amb les escombraries domèstiques.
Garantia i Suport
Vortex products are designed and manufactured to the highest quality standards. For warranty information and customer support, please refer to the documentation provided at the time of purchase or visit the official Vortex weblloc.
