Manual d'usuari del despertador JALL Wake Up Light Sunrise

Introducció

Gràcies per la compraasing the JALL Wake Up Light Sunrise Alarm Clock. This device is designed to enhance your waking and sleeping experience with its advanced features, including sunrise simulation, dual alarms, FM radio, and various light and sound modes. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your device.

Figura 1: Frontal view of the JALL Wake Up Light Sunrise Alarm Clock.

Contingut del paquet

• JALL Wake Up Light Sunrise Alarm Clock (Model K8)
• Adaptador de corrent (amb cable elèctric)
• Manual d'usuari
• CR2032 Battery (pre-installed for memory backup)

Producte acabatview

Figura 2: posterior view of the JALL Wake Up Light, highlighting the USB charging port, DC 5V input, and battery compartment.

The JALL Wake Up Light features a full-screen LED display, intuitive button controls on the top and sides, and various ports on the back for power and charging. The wood grain finish provides a modern aesthetic.

Configuració

1. Desembalar: Traieu amb cura el despertador i tots els accessoris de l'embalatge.
2. Connexió d'alimentació: Connect the provided power adapter to the DC 5V input port on the back of the alarm clock. Plug the adapter into a standard electrical outlet.
3. Còpia de seguretat de la bateria: The device comes with a pre-installed CR2032 battery. This battery serves as a memory backup for time and alarm settings in case of a power outage. No action is required unless the battery needs replacement.
4. Encesa inicial: The display will light up once connected to power.
5. Configuració de l'hora:
   • Press the "Time Setting" button (usually indicated by a clock icon).
   • Use the "+" or "-" buttons to adjust the hour.
   • Press the "Time Setting" button again to confirm the hour and move to minute adjustment.
   • Use the "+" or "-" buttons to adjust the minutes.
   • Press the "Time Setting" button one more time to confirm and exit.
   • You may also be prompted to select 12-hour or 24-hour format.

Instruccions de funcionament

Simulació de la sortida del sol

The sunrise simulation feature gradually brightens the light from 10% to 100% over a set period (10-60 minutes) before your alarm time, mimicking a natural sunrise to gently wake you up.

Figure 3: Sunrise simulation in action, gradually brightening the room.

• To activate, set an alarm (see Dual Alarms section).
• During alarm setup, you can select the duration of the sunrise simulation (e.g., 10, 20, 30, 45, 60 minutes).

Full Screen LED Display Panel

The alarm clock features a full-screen LED display for clear time visibility. The display brightness can be adjusted or turned off completely.

• Press the "Display Brightness" button (often indicated by a sun icon) to cycle through 3 levels of brightness or turn the display off.

15 Colorful Lights & Dimmable

The device offers 15 lighting modes, including 8 solid colors (Pink, Green, Blue, Indigo, Purple, Grey, Red, Orange) and 7 mood lights, allowing you to customize the ambiance.

Figura 4: Examples of the 15 colorful light modes.

• Press the "Light" button (often indicated by a light bulb icon) to turn on the light.
• Continue pressing the "Light" button to cycle through the different color modes.
• Use the "Brightness +/-" buttons to adjust the intensity of the light.

Dual Alarms & Unlimited Snooze

The alarm clock supports two independent alarms, allowing for different wake-up times. The snooze function provides an additional 9 minutes of sleep.

Figure 5: Dual alarms for personalized wake-up times.

• Configuració d'alarmes:
  • Press the "Alarm 1" or "Alarm 2" button (indicated by alarm clock icons).
  • Use "+" or "-" to set the hour, then press the alarm button again to set minutes.
  • Select the alarm sound (from 8 built-in sounds or FM radio).
  • Ajusteu el volum de l'alarma.
  • Choose the alarm frequency: Every-Day, Weekday (Mon-Fri), or Weekend (Sat-Sun).
  • Confirm settings by pressing the alarm button one last time.
• Funció de posposar: When the alarm sounds, press the "Snooze" button (usually a large button on top) to get an additional 9 minutes of sleep. This can be repeated unlimited times.
• Desactivació de l'alarma: To turn off the alarm for the day, press any button other than "Snooze". To disable an alarm permanently, press and hold the corresponding alarm button until the alarm icon disappears from the display.

8 Sleep Aid Sounds & FM Radio

The device includes 8 soothing sounds (Cricket, Campfire, Birds, Frogs, Seagulls, River, Rain, Wind Chimes, White Noise, Pink Noise, etc.) to aid sleep, and an FM radio for entertainment or news.

Figure 6: Selection of natural sounds and FM radio functionality.

• Ràdio FM:
  • Press the "Radio" button to turn on the FM radio.
  • Hold the "FM Radio" button for 2 seconds to automatically scan and save all available stations (76 - 108 MHz).
  • Use the "+" or "-" buttons to manually tune or cycle through saved stations.
  • Ajusteu el volum amb els botons de volum dedicats.
• Sleep Aid Sounds:
  • Press the "Sound" button (often indicated by a music note icon) to play sleep aid sounds.
  • Press again to cycle through the 8 built-in sounds.
  • Ajusteu el volum amb els botons de volum dedicats.
  • To set a sleep timer for sounds, refer to the specific instructions in your detailed manual (not provided in this summary).

Night Light & Bedside Lamp

The JALL Wake Up Light can also function as a versatile bedside lamp or night light, providing soft and warm illumination for various activities.

Figure 7: Versatile use as a reading light, sleep aid, or night light.

• Press the "Light" button to turn on the lamp.
• Use the "Brightness +/-" buttons to adjust the light intensity to your preference.

Manteniment

• Neteja: Netegeu el dispositiu amb un drap suau i sec. No utilitzeu productes de neteja abrasius ni dissolvents.
• Emmagatzematge: Si l'emmagatzemeu durant un període prolongat, desconnecteu-lo de la xarxa elèctrica i guardeu-lo en un lloc fresc i sec.
• Substitució de la bateria: The CR2032 battery is for memory backup. If settings are lost after a power outage, the battery may need replacement. Open the battery compartment on the back and replace with a new CR2032 battery, observing polarity.
• Eviteu l'aigua: This device is not waterproof. Keep away from water and high humidity.

Resolució de problemes

Especificacions

Garantia i Suport

For warranty information and customer support, please refer to the official JALL weblloc web o contacteu directament amb el servei d'atenció al client. Conserveu el rebut de compra per a reclamacions de garantia.
