CHROX H96 MAX M7 Android 13.0 TV Box User Manual

Introducció

This manual provides comprehensive instructions for the setup, operation, and maintenance of your CHROX H96 MAX M7 Android 13.0 TV Box. Please read this manual carefully before using the device to ensure proper functionality and safety. The CHROX H96 MAX M7 is a versatile multimedia device designed to transform your television into a smart entertainment hub, supporting 8K/4K video playback, dual-band Wi-Fi, and Bluetooth connectivity.

Informació de seguretat

Si us plau, observeu les següents precaucions de seguretat per evitar danys al dispositiu o lesions personals:

• Handle the device with care to avoid drops and impacts.
• Assegureu-vos que el producte estigui ben muntat abans d'utilitzar-lo.
• No exposeu el dispositiu a l'aigua, la humitat ni a temperatures extremes.
• Utilitzeu només l'adaptador d'alimentació subministrat.
• No intenteu desmuntar ni reparar el dispositiu vosaltres mateixos. Poseu-vos en contacte amb personal de servei qualificat.
• Mantingueu el dispositiu lluny de fonts de calor i de la llum solar directa.

Image: Multilingual warning label emphasizing careful handling and secure assembly.

Contingut del paquet

Verifiqueu que tots els elements siguin presents al paquet:

• 1 x CHROX H96 MAX M7 TV Box
• 1 x comandament a distància
• 1 cable HD (HDMI)
• 1 x adaptador de corrent
• 1 x Manual d'usuari (aquest document)

Image: All components included in the CHROX H96 MAX M7 package.

Producte acabatview

The CHROX H96 MAX M7 TV Box features a compact design with various ports for connectivity. Familiarize yourself with the device's layout:

Image: The CHROX H96 MAX M7 TV Box and its accompanying remote control.

Ports i interfícies:

• USB 3.0: 1 port for high-speed data transfer.
• USB 2.0: 1 port for standard connectivity.
• HDMI 2.0a: For connecting to your TV or display, supporting 4K@60Hz output.
• Port AV: For older televisions or audio output.
• Lector de targetes Micro SD: Per ampliar l'emmagatzematge.
• Entrada d'alimentació de CC de 5 V/2.5 A: Per connectar l'adaptador de corrent.
• LAN Ethernet: 10/1000M standard RJ-45 port for wired network connection.
• SPDIF: Per a la sortida d'àudio digital.

Guia de configuració

1. Connexió al televisor

1. Connect one end of the provided HD Cable (HDMI) to the HDMI port on the CHROX TV Box.
2. Connect the other end of the HDMI cable to an available HDMI input port on your television or display. Note the HDMI input number (e.g., HDMI 1, HDMI 2) for later selection.

2. Encendre el dispositiu

1. Connect the power adapter to the DC 5V/2.5A input port on the CHROX TV Box.
2. Connecteu l'adaptador de corrent a una presa de corrent.
3. The device will automatically power on, or you may need to press the power button on the remote control.

3. Initial Setup and Network Configuration

1. Turn on your television and select the correct HDMI input source using your TV's remote control.
2. Follow the on-screen prompts for initial setup, which typically include selecting your language, time zone, and connecting to a network.
3. For Wi-Fi connection: Select your Wi-Fi network from the list, enter the password, and confirm.
4. For wired Ethernet connection: If an Ethernet cable is connected, the device should automatically detect the network.

Image: The CHROX H96 MAX M7 TV Box connected to a television, demonstrating its use as a TV box.

Instruccions de funcionament

Navegant per la interfície

Use the provided remote control to navigate the Android 13.0 interface. The directional buttons allow you to move between icons and menus, while the "OK" button confirms selections. The "Back" button returns to the previous screen, and the "Home" button takes you to the main screen.

Using as a TV Box

Once connected to your TV and powered on, the device functions as a smart TV box. You can access pre-installed applications, download new apps from the Google Play Store, browse the internet, and stream content. The green indicator light on the device signifies that the TV Box function is active and operating normally.

Image: The CHROX H96 MAX M7 TV Box connected to a computer monitor, showcasing its ability to output sound through the device and connect to various displays.

S'utilitza com a altaveu Bluetooth

The CHROX H96 MAX M7 can also function as a standalone Bluetooth speaker. To activate this mode:

1. Ensure the device is connected to a power supply.
2. Press the power/on-off key on the remote control to enter AUX-in mode. The blue indicator light will illuminate, indicating it has entered Bluetooth pairing mode.
3. On your mobile phone or other Bluetooth-enabled device, search for "H96 MAX" or a similar device name in the Bluetooth settings.
4. Select the device to pair. Once paired, you can play music from your mobile device through the CHROX H96 MAX M7 speaker.

Image: The CHROX H96 MAX M7 operating as a Bluetooth speaker, receiving audio from a smartphone.

Image: The CHROX H96 MAX M7's Bluetooth 5.1 capability, allowing music playback from mobile devices within a 0-10 meter range.

Reproducció multimèdia

The device supports a wide range of media formats and resolutions, including 8K and 4K video playback with H.265 decoding for efficient streaming. You can play media from connected USB drives, Micro SD cards, or network sources.

Image: Key features of the H96 Max M7, including Android 13, 8K video support, Rockchip RK3528 processor, Bluetooth 5.1, and dual-band Wi-Fi.

Manteniment

To ensure the longevity and optimal performance of your CHROX H96 MAX M7 TV Box, follow these maintenance guidelines:

• Neteja: Feu servir un drap suau i sec per netejar l'exterior del dispositiu. No utilitzeu netejadors líquids ni aerosols.
• Ventilació: Assegureu-vos que el dispositiu estigui col·locat en una zona ben ventilada per evitar el sobreescalfament. No bloquegeu cap obertura de ventilació.
• Emmagatzematge: Quan no l'utilitzeu durant períodes prolongats, guardeu el dispositiu en un lloc fresc i sec, allunyat de la llum solar directa.
• Actualitzacions de programari: Periodically check for and install system updates to ensure the latest features and security patches.

Resolució de problemes

If you encounter issues with your CHROX H96 MAX M7 TV Box, refer to the following common problems and solutions:

Especificacions

Detailed technical specifications for the CHROX H96 MAX M7 Android 13.0 TV Box:

Garantia i Suport

For warranty information and technical support, please refer to the contact details provided by your retailer or visit the official CHROX support weblloc web. Conserveu el rebut de compra com a comprovant de compra per a qualsevol reclamació de garantia.
