HECASA Flip 3-in-1 Windshield Instruction Manual

1. Introducció

This manual provides detailed instructions for the installation, operation, and maintenance of your HECASA Flip 3-in-1 Windshield. Designed for Polaris General 1000 and General 4 1000 models, this windshield offers versatile protection and airflow control with its open, ventilated, and closed positions. Please read this manual thoroughly before installation and use to ensure proper function and safety.

Figure 1: HECASA Flip 3-in-1 Windshield in use, demonstrating its protective qualities.

2. Informació de seguretat

• Utilitzeu sempre l'equip de seguretat adequat, inclosa la protecció ocular, durant la instal·lació.
• Ensure the vehicle is parked on a level surface with the engine off and parking brake engaged before beginning installation.
• Do not operate the vehicle with the windshield improperly installed or damaged.
• Regularly inspect all mounting hardware for tightness and signs of wear.
• This windshield is not compatible with Rockford Fosgate stereo systems or Ride Command. Attempting installation with these systems may cause damage or improper fit.

3. Compatibilitat

This HECASA Flip 3-in-1 Windshield (Model CB-2616) is specifically designed for the following vehicle models:

• 2016 and newer Polaris General 1000
• 2017 and newer Polaris General 4 1000

Nota important: This windshield is NO compatible with vehicles equipped with a Rockford Fosgate stereo system or Ride Command. Please verify your vehicle's configuration before proceeding with installation.

Figure 2: Compatibility details for Polaris General models.

4. Contingut del paquet

Before beginning installation, unpack all components and verify that all items listed below are present and undamaged. If any parts are missing or damaged, do not proceed with installation and contact customer support.

• 1 x Flip 3-in-1 Windshield (Clear Plastic Panel)
• Mounting Hardware Kit (screws, hoops, brackets, gas struts)
• Ràpid del temps
• Manual d'instruccions (aquest document)

Figure 3: Complete package contents of the windshield kit.

5. Configuració i instal·lació

Professional installation is recommended for this product. The following steps provide a general guide for screw and hoop installation. Refer to the included detailed instructions for specific diagrams and torque specifications.

Eines necessàries (no incloses):

• Conjunt de claus estàndard
• Socket wrench set (including a 2-foot extension if your vehicle has Ride Command)
• Drill and appropriate drill bits (if modification is required for T-bracket)
• Mall de goma
• Ganivet o tisores

Passos d'instal·lació:

1. Preparar el vehicle: Park your Polaris General on a flat, stable surface. Turn off the engine and engage the parking brake.
2. Remove Sound Bar (if applicable): If your vehicle has a sound bar, remove it to access the mounting points. It is generally not necessary to remove the visor. Important: Do not reinstall the sound bar until the windshield hinges are fully installed and secured.
3. Assemble Windshield Frame: Attach the hinges and gas struts to the windshield frame according to the detailed diagrams provided in the separate instruction sheet.


Figure 4: Assembled windshield frame.

4. Mount Windshield to Vehicle: Position the assembled windshield frame onto the vehicle's roll cage. Secure the frame using the provided screws and hoops. Ensure all bolts are tightened securely.
5. Install T-Bracket: Install the T-bracket under the dash. If the T-bracket slips after tightening, it may be necessary to drill a small hole through the vehicle's frame and secure the bracket with an additional bolt to prevent movement.
6. Connect Gas Struts: Attach the gas struts to the mounting clamps on the vehicle frame. Ensure the ball joints are securely seated.

Figure 5: Close-up of a gas strut mounting clamp.
7. Install Weather Stripping: Carefully install the weather stripping around the edges of the windshield. A rubber mallet can assist in seating the weatherstrip firmly. Cut out the track around the hinges, but leave the circular parts intact for proper sealing.
8. Comprovacions finals: Verify that all hardware is tight and the windshield operates smoothly through its three positions. Reinstall the sound bar if it was removed.

Note for Ride Command Users: If your Polaris General is equipped with Ride Command, you may require a 2-foot extension for your socket wrench to properly tighten bolts under the dash for the window handle mechanism.

6. Instruccions de funcionament

The HECASA Flip 3-in-1 Windshield offers three distinct operating positions to adapt to various driving conditions and weather:

• Posició tancada: Provides maximum protection from wind, rain, snow, and debris. The windshield is fully upright and secured.
• Ventilated Position: Allows for airflow into the cabin while still offering significant protection. This position is ideal for reducing heat buildup and preventing fogging. The windshield is partially open, typically held by the stretch bracket.
• Posició oberta: The windshield is fully flipped up and secured, providing maximum airflow and an open-air driving experience.

Adjusting the Windshield:

1. To change the windshield position, locate the release mechanism or handle.
2. Carefully disengage the current locking mechanism.
3. Adjust the windshield to the desired position (closed, ventilated, or open). The integrated gas struts and stretch bracket assist in smooth movement and holding the position.


Figure 6: The stretch bracket facilitates adjustment between positions.

4. Ensure the windshield is securely latched or locked in the new position before operating the vehicle.

Nota: Some users have reported that the pull handle to close the windshield can be stiff. Ensure the mechanism is clean and properly aligned for smoother operation.

7. Manteniment

Proper maintenance will extend the life and clarity of your HECASA windshield.

Neteja:

• The windshield is made from high-quality plastic designed to be scratch-resistant. However, improper cleaning can still cause damage.
• Always rinse the windshield thoroughly with clean water to remove loose dirt and debris before wiping.
• Use a soft, clean microfiber cloth and a mild soap solution or a specialized plastic cleaner.
• Wipe gently in one direction, avoiding circular motions that can create swirl marks.
• Do not use abrasive cleaners, brushes, or paper towels, as these can scratch the plastic surface.
• Avoid cleaning the windshield in direct sunlight or when the surface is hot.

Figure 7: Material properties of the HECASA windshield.

Atenció general:

• Periodically check all mounting hardware, screws, and bolts for tightness. Retighten as necessary to prevent rattling or loosening during operation.
• Inspect the weather stripping for any signs of wear, cracking, or detachment. Replace if damaged to maintain a proper seal.
• Lubricate hinges and moving parts with a silicone-based lubricant if they become stiff or noisy.

8. Solució De Problemes

9. Especificacions

10. Garantia i Suport

Informació de la garantia: Specific warranty details for the HECASA Flip 3-in-1 Windshield are not provided in this manual. Please refer to the manufacturer's official website or contact HECASA customer support directly for the most current warranty policy and registration information.

Atenció al client: For technical assistance, missing parts, or any questions regarding your HECASA product, please contact HECASA customer support through their official channels. Have your product model number (CB-2616) and purchase information ready when contacting support.
