Introducció
Welcome to the user manual for your new Doro Live L11 mobile phone. This 4G mobile phone is designed with ease of use and excellent sound quality, making it ideal for seniors. It features contrast-strong, separate buttons, a large 2.4-inch landscape screen, and a particularly loud and clear sound to simplify daily calls and text messages. The Doro Live L11 also includes a 2MP camera with flash for capturing and sharing photos, a soft-touch surface for a secure grip, HD voice support, hearing aid compatibility (HAC), a built-in flashlight, splash-proof design, and an emergency call button with GPS position sharing for enhanced safety.
Figure 1: Doro Live L11 mobile phone with its charging dock, showing both the front and back of the device.
Contingut del paquet
Marqueu la casella per als elements següents:
- Doro Live L11 Mobile Phone
- Base de càrrega
- Cable USB-C
- Manual d'usuari (aquest document)
Configuració
1. Inserció de la targeta SIM i la bateria
- Traieu amb cura la tapa posterior del telèfon.
- Insert your SIM card into the designated slot. Ensure it is correctly oriented as indicated by the diagram near the slot.
- Insert the battery, aligning the gold contacts with the phone's terminals.
- Torneu a col·locar la coberta posterior, prement fermament fins que encaixi al seu lloc.
2. Carregant el telèfon
- Connect the USB-C cable to the charging dock.
- Plug the other end of the USB-C cable into a compatible USB power adapter (not included) and then into a wall outlet.
- Col·loca el telèfon Doro Live L11 a la base de càrrega. Assegura't que estigui correctament col·locat i que l'indicador de càrrega aparegui a la pantalla.
- Allow the phone to charge fully before first use. A full charge typically takes approximately 2-3 hours.
Figure 2: The Doro Live L11 phone in red, highlighting its simple interface and 4G connectivity.
Instruccions de funcionament
1. Encès / apagat
- To power on: Press and hold the red power button (usually located on the top right of the keypad) until the screen lights up.
- To power off: Press and hold the red power button, then follow the on-screen prompts to confirm power off.
2. Fer i rebre trucades
- To make a call: Dial the number using the keypad and press the green call button.
- To receive a call: Press the green call button when the phone rings.
- To end a call: Press the red end call button.
3. Enviament i recepció de SMS
- Navegueu fins al menú "Missatges".
- Seleccioneu "Nou missatge" i introduïu el número del destinatari o seleccioneu-lo dels contactes.
- Escriviu el vostre missatge amb el teclat.
- Press the send option (usually indicated by an envelope icon or a soft key).
4. Ús de la càmera
- Access the "Camera" application from the main menu.
- Enquadra la teva foto utilitzant la pantalla com a viewcercador.
- Press the designated camera button (or OK button) to take a photo.
5. Emergency Help Button with GPS
- The Doro Live L11 features a dedicated help button (often on the back or side of the phone).
- In an emergency, press and hold this button.
- The phone will automatically send an SMS alert with your GPS position to pre-set trusted contacts, followed by calls to these contacts until one answers.
- Ensure your emergency contacts are set up in the phone's settings for this feature to function correctly.
Figure 3: Key features of the Doro Live L11, including the help button with GPS, hearing aid compatibility, camera, flashlight, and splash-proof rating (IP54).
Manteniment
1. Neteja del telèfon
- Feu servir un drap suau i sense borrissol per netejar la pantalla i la carcassa del telèfon.
- Do not use harsh chemicals, cleaning sprays, or abrasive materials.
- The phone is splash-proof (IP54 rated), but it is not waterproof. Avoid submerging it in water.
2. Cura de la bateria
- Per maximitzar la durada de la bateria, eviteu exposar el telèfon a temperatures extremes.
- Charge the phone regularly using the provided charging dock and USB-C cable.
- Si no feu servir el telèfon durant un període prolongat, carregueu-lo al 50% aproximadament abans de guardar-lo.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El telèfon no s'encén | Bateria baixa; Bateria no inserida correctament | Charge the phone; Re-insert the battery |
| No puc fer/rebre trucades | No network signal; SIM card issue | Move to an area with better signal; Check SIM card insertion |
| Mala qualitat del so | Volume too low; Obstruction in speaker/microphone | Increase volume; Clean speaker/microphone openings |
| Emergency button not working | Emergency contacts not set up; GPS signal weak | Set up emergency contacts in settings; Ensure clear view of sky for GPS |
Especificacions
| Característica | Detall |
|---|---|
| Nom del model | Doro Live L11 |
| Número de model | 8742 |
| Mida de la pantalla | 2.4 polzades |
| Tipus de visualització | LCD |
| Resolució | 240 x 320 píxels |
| Càmera | 2 MP with Flash |
| Tecnologia cel·lular | 4G |
| Capacitat de la bateria | 1150 mAh |
| Emmagatzematge intern | 64 MB Flash Memory, 50 MB Digital Storage |
| RAM | 64 MB |
| Característiques especials | Built-In GPS, Hearing Aid Compatibility (HAC), Flashlight, Splash-proof (IP54) |
| Components inclosos | Cable USB, base de càrrega |
Informació de la garantia
Doro products are covered by a limited warranty. Please refer to the warranty card included in your product packaging or visit the official Doro weblloc web per obtenir informació detallada sobre els termes i condicions de la garantia específics de la vostra regió. Conserveu el rebut de compra com a comprovant de compra per a reclamacions de garantia.
Suport
For further assistance, technical support, or to find answers to frequently asked questions, please visit the official Doro support website or contact Doro customer service. Contact details can typically be found on the Doro weblloc o a l'embalatge del producte.
Assistència en línia: www.doro.com/support
