1. Introducció
Thank you for choosing the OUKITEL P1000 Plus Portable Power Station. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your device. Please read this manual thoroughly before using the product and keep it for future reference.
The OUKITEL P1000 Plus is a versatile portable power station equipped with a 1024Wh LiFePO4 battery and an 1800W (3600W peak) output. It is designed to provide reliable power for various applications, including camping, RV travel, outdoor adventures, and as an emergency backup power source for your home.
2. Instruccions de seguretat
Per garantir un funcionament segur, seguiu sempre aquestes precaucions:
- No desmunteu, repareu ni modifiqueu la unitat. Un muntatge incorrecte pot provocar un incendi o una descàrrega elèctrica.
- No col·loqueu la unitat a prop del foc ni l'exposeu a la calor. Mantingueu-la allunyada de la llum solar directa.
- Do not charge, use, or store the unit in a bathroom or in an area exposed to water or high humidity.
- Use only the provided charger and cables. Using unauthorized accessories may cause fire, explosion, or injury.
- No utilitzeu la unitat si està danyada o si ha caigut.
- Mantenir fora de l'abast dels nens i mascotes.
- Assegureu-vos de ventilar correctament durant l'ús i la càrrega per evitar el sobreescalfament.
- No introduïu objectes estranys als ports ni obertures.
- En cas d'incendi, utilitzeu un extintor de pols seca.
3. Producte acabatview
3.1. Components i ports
The OUKITEL P1000 Plus features a robust design with multiple output ports to power various devices. Refer to the diagram below for a visual guide to the unit's components.
Descripció de la imatge: Un detallat view of the OUKITEL P1000 Plus portable power station's front panel, highlighting its various output ports. Labels indicate 1x Cigarette Lighter Socket, 2x DC Ports, USB-A x2, USB-C x2, LED Light, and 4x AC Outlets. The central display shows battery status and power information.
- Preses de corrent altern (x4): Provides 1800W (3600W peak) pure sine wave AC power for household appliances.
- Ports USB-A (x2): For charging smartphones, tablets, and other USB-A powered devices.
- Port USB-C PD de 100 W (x1): High-speed charging for laptops and other USB-C PD compatible devices.
- Port USB-C PD de 20 W (x1): Standard USB-C charging for various devices.
- Sortides de CC de 36 W (x2): Per a dispositius alimentats per corrent continu.
- Presa d'encenedor de cigarrets de CC de 120 W (x1): For car appliances and other 12V devices.
- Llum LED: Multi-function LED light with 3 modes (steady, SOS, flashing) for illumination.
- Pantalla LCD: Shows real-time battery status, input/output power, and other operational information.
4. Configuració
4.1. Desembalatge
Carefully remove the OUKITEL P1000 Plus and all accessories from the packaging. Retain the original packaging for potential returns or future transportation.
4.2. Càrrec inicial
Before first use, fully charge the power station. Connect the provided AC charging cable to the unit's AC input port and then to a wall outlet. The LCD display will indicate the charging status. A full charge from 0% to 100% takes approximately 70 minutes using AC charging. For faster charging, combine AC and solar input (up to 1700W total) to achieve a full charge in about 45 minutes.
Descripció de la imatge: Two images demonstrating charging methods. The top image shows the OUKITEL P1000 Plus connected to a wall outlet for AC charging, indicating 0-80% in 45 minutes. The bottom image shows the power station connected to a solar panel on a beach, indicating solar charging to 100% in 130 minutes (with max 500W input). A combined AC + Solar charging (1700W) is also mentioned, achieving 0-100% in 45 minutes.
4.3. Connexió a l'aplicació (opcional)
Download the "Wonderfree" app from your smartphone's app store. Follow the in-app instructions to connect your OUKITEL P1000 Plus via Bluetooth or Wi-Fi. The app allows you to monitor battery status, control charging modes, and adjust functions remotely.
Descripció de la imatge: A man sitting on a sofa, smiling and looking at his smartphone, which displays the "Wonderfree" app interface showing the OUKITEL P1000 Plus's battery status and power information. The power station is visible on the floor next to him, with a Wi-Fi signal icon indicating connectivity.
5. Instruccions de funcionament
5.1. Encendre/apagar
Premeu i manteniu premut el botó d'engegada principal durant uns segons per encendre o apagar la unitat. La pantalla LCD s'il·luminarà en activar-la.
5.2. Ús de sortides de CA
Press the AC power button to activate the AC outlets. Plug your devices into the AC ports. Ensure the total power consumption of your devices does not exceed 1800W (or 3600W peak for short bursts). The unit provides a pure sine wave output, suitable for sensitive electronics.
5.3. Ús de sortides de CC i USB
Press the DC power button to activate the DC and USB ports. Plug your devices into the appropriate USB-A, USB-C, DC, or cigarette lighter ports. The unit will automatically detect and provide the optimal charging current for connected devices.
5.4. Funcionalitat del SAI
The OUKITEL P1000 Plus features an Uninterruptible Power Supply (UPS) function with a 10ms switching speed. To use this, connect the power station to a wall outlet via the AC input, and then connect your critical devices (e.g., PC, router, security cameras) to the power station's AC outputs. In case of a power outage, the unit will automatically switch to battery power, providing seamless operation for your connected devices.
Descripció de la imatge: A split image demonstrating the UPS function. The top panel shows a man working on a computer with the power station connected to the wall and powering the computer, indicating "Alimentazione elettrica" (Electrical power) with a green checkmark. The bottom panel shows the same scene during a power outage ("Interruzione di corrente") with a red cross, but the computer remains powered by the power station, illustrating uninterrupted power supply.
5.5. Funcionament de la llum LED
Press the LED light button to cycle through its three modes: steady illumination, SOS signal, and flashing. This feature is useful for outdoor activities or emergency situations.
6. Manteniment
Proper maintenance ensures the longevity and optimal performance of your OUKITEL P1000 Plus.
- Emmagatzematge: Store the unit in a cool, dry place away from direct sunlight and extreme temperatures. For long-term storage, charge the unit to 50-80% every 3-6 months to preserve battery health.
- Neteja: Feu servir un drap sec i suau per netejar l'exterior de la unitat. No utilitzeu productes químics agressius ni materials abrasius.
- Salut de la bateria: The LiFePO4 battery is designed for up to 4000 charge cycles, providing a lifespan of up to 10 years. Avoid fully discharging the battery frequently to maximize its lifespan.
- Ventilació: Assegureu-vos que les obertures de ventilació estiguin netes de pols i deixalles per evitar el sobreescalfament.
7. Solució De Problemes
Si teniu problemes amb el vostre OUKITEL P1000 Plus, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| La unitat no s'encén | Battery is completely discharged; Power button not pressed long enough. | Charge the unit using the AC adapter; Press and hold the power button for 3-5 seconds. |
| La sortida de CA no funciona | AC output not activated; Overload protection triggered; Device power consumption too high. | Press the AC power button; Reduce the number of connected devices or use lower-power devices; Restart the unit. |
| La unitat no es carrega | Charging cable not properly connected; Charger malfunction; Extreme temperature. | Ensure all charging cables are securely connected; Try a different charging method (e.g., solar if AC fails); Charge within recommended temperature range (0-40°C). |
| Problemes de connexió de l'aplicació | Bluetooth/Wi-Fi off; App not updated; Unit too far from phone. | Ensure Bluetooth/Wi-Fi is enabled on your phone and the unit; Update the "Wonderfree" app; Move closer to the unit. |
If the problem persists, please contact OUKITEL customer support.
8. Especificacions
| Característica | Detall |
|---|---|
| Model | P1000 Plus |
| Tipus de bateria | LiFePO4 (fosfat de ferro de liti) |
| Capacitat | 1024 Wh |
| Potència de sortida de CA. | 1800W (Pure Sine Wave), 3600W Peak |
| Càrrega d'entrada de CA | 1200W (0-80% in 45 min, 0-100% in 70 min) |
| Càrrega d'entrada solar | Max 500W (0-100% in approx. 2.3 hours with 500W panels) |
| Combined Charging (AC + Solar) | Up to 1700W (0-100% in 45 min) |
| Sortida USB-A | 2 ports |
| Sortida USB-C | 1x PD 100W, 1x PD 20W |
| Sortida de corrent continu | 2x 36W ports, 1x 120W Cigarette Lighter Socket |
| Temps de canvi del SAI | 10 ms |
| Vida útil | Up to 4000 cycles (to 70% capacity), approx. 10 years |
| Dimensions | 34.6 × 22.8 × 23.8 cm (13.6 × 9.0 × 9.4 polzades) |
| Pes | 12 kg (26.5 lliures) |
| Modes de llum LED | 3 (Steady, SOS, Flashing) |
9. Contingut del paquet
The following items are included in your OUKITEL P1000 Plus package:
Descripció de la imatge: An image showing the OUKITEL P1000 Plus power station alongside its accessories: an AC charging cable, a solar charging cable, a Bluetooth pairing pin, a card, and a user manual. The text lists these items as "Contenuto della confezione" (Package Contents).
- 1x Estació d'alimentació portàtil OUKITEL P1000 Plus
- 1 cable de càrrega de CA
- 1x Cable de càrrega solar
- 1x Bluetooth Pairing Pin
- 1x Warranty Card / Information Card
- 1 x manual d'usuari
10. Garantia i Suport
OUKITEL provides a 2-year warranty for the P1000 Plus Portable Power Station. This warranty covers manufacturing defects and workmanship under normal use. Please retain your proof of purchase for warranty claims.
For technical support, warranty claims, or any questions regarding your product, please contact OUKITEL customer service through their official website or the contact information provided in the warranty card.
OUKITEL offers 24/7 assistance and has over 100 expert specialists to assist you.
Descripció de la imatge: An image titled "SERVIZIO CLIENTI PREMIUM CON AFFIDABILITÀ" (Premium Customer Service with Reliability) showing three turquoise information boxes: "24/7 Servizio di Assistenza" (24/7 Assistance Service), "5 ANNI Garanzia di Qualità" (5 YEARS Quality Warranty), and "Oltre 100 Specialisti Esperti" (Over 100 Expert Specialists). Note: The warranty period stated in the text (2 years) takes precedence over the image text (5 years) for accuracy based on product feature bullets.
Nota important: For shipping regulations, please keep the original packaging until the return period expires, as it is required for returns of the portable solar generator.
