chartustriable 70-inch 10-Drawer Dresser with Charging Station Instruction Manual

Introducció

Thank you for choosing the chartustriable 70-inch 10-Drawer Dresser with Charging Station. This manual provides essential information for the safe assembly, operation, and maintenance of your new furniture. Please read it thoroughly before beginning assembly and retain it for future reference.

Característiques principals:

• Emmagatzematge espaiós: Features 10 drawers, including 4 deep drawers (9.8 inches) and 6 standard drawers (5.4 inches), providing ampespai per a diversos elements.
• Estació de càrrega integrada: Equipped with 2 AC outlets, 1 USB port, and 1 fast-charging USB port for convenient device charging.
• Disseny versàtil: Can function as a long dresser, TV stand (accommodates TVs up to 80 inches), or a vanity dresser.
• Construcció sòlida: Made from engineered wood with a stable base and anti-toppling devices for enhanced safety and durability.
• Dimensions: 70"W x 15.7"D x 36"H.

Informació important de seguretat

Please read and understand all safety warnings and instructions before assembling and using this product. Failure to follow these instructions may result in serious injury or property damage.

• Dispositiu antibolcada: Always install the included anti-toppling device to prevent the dresser from tipping over. This is crucial for safety, especially in households with children.
• Límits de pes: Do not exceed the recommended weight limits for the dresser top or individual drawers. Overloading can compromise stability and cause damage.
• Muntatge: Assemble the dresser on a soft, clean surface to prevent scratches. Ensure all fasteners are securely tightened before use. Periodically check and re-tighten fasteners as needed.
• Seguretat elèctrica: The integrated charging station is designed for indoor use only. Do not expose it to moisture. Ensure the power cord is not pinched or damaged during assembly or use.
• Col·locació: Place the dresser on a level surface. Avoid placing heavy objects on top that could cause instability.

Contingut del paquet

Verifiqueu que tots els components i el maquinari estiguin presents abans de començar el muntatge. Si falta alguna peça o hi ha alguna peça danyada, poseu-vos en contacte amb el servei d'atenció al client.

Note: Specific part numbers and quantities are detailed in the assembly video.

Instruccions de muntatge

Assembly requires careful attention to detail. It is recommended to have at least two people for assembly. A power drill (low torque setting) and a screwdriver will be helpful.

Guia de vídeo de muntatge:

General Assembly Steps (Refer to video for detailed visuals):

1. Preparació dels components: Unpack all parts and lay them out on a soft, clean surface. Identify each part using the labels provided in the video.
2. Assemble Drawer Slides: Attach the drawer slides to the side panels of the dresser frame using the specified screws (e.g., M3.5*12 screws). Ensure they are aligned correctly.
3. Construct Side Frames: Connect the vertical side panels (e.g., parts 5, 6, 7, 8) using cam locks and dowels.
4. Attach Horizontal Supports: Secure the horizontal support bars (e.g., parts 9, 10) between the vertical side frames using cam locks and dowels.
5. Install Top Panels: Carefully place and secure the top panels (e.g., parts 1, 2) onto the assembled frame using cam locks and screws.
6. Muntar calaixos: For each drawer, attach the side panels to the front and back panels using screws and dowels. Slide the bottom panel into the grooves.
7. Instal·leu les nanses dels calaixos: Attach the handles to the front of each drawer.
8. Estació de càrrega integrada: Insert the charging station into the pre-cut opening on the top panel and secure it with screws. Route the power cord as instructed.
9. Inserir calaixos: Carefully slide each assembled drawer into its designated slot on the dresser frame.
10. Instal·leu el dispositiu antibolcada: Securely attach the anti-toppling device to the back of the dresser and to a wall stud, following the instructions provided with the device.

Instruccions de funcionament

Ús de l'estació de càrrega:

• Plug the dresser's main power cord into a standard wall outlet.
• Use the 2 AC outlets for devices requiring standard power.
• Utilize the 1 USB port and 1 fast-charging USB port for charging compatible electronic devices such as smartphones, tablets, or smartwatches.
• Ensure devices are compatible with the charging station's output specifications (e.g., 5V/2A for USB ports, 20W for fast charging).

Ús del calaix:

• Open and close drawers gently using the handles.
• Avoid slamming drawers to prevent damage to the slides and contents.
• Distribute weight evenly within drawers to maintain balance and smooth operation.

Manteniment

• Neteja: Netegeu les superfícies amb un suau, damp drap. Eviteu productes químics agressius o netejadors abrasius que puguin danyar l'acabat.
• Pols: Regularly dust the dresser with a dry, soft cloth.
• Comprovació de maquinari: Periodically inspect all screws, cam locks, and other fasteners. Tighten any loose hardware to ensure stability and safety.
• Diapositives del calaix: If drawers become stiff, a small amount of silicone-based lubricant can be applied to the drawer slides.
• Eviteu la llum solar directa: L'exposició prolongada a la llum solar directa pot causar decoloració o esvaïment de l'acabat de la fusta.
• Humitat: Protect the dresser from excessive moisture and humidity. Wipe up spills immediately.

Resolució de problemes

• Els calaixos no tanquen bé: Check if the drawer slides are properly aligned and free of obstructions. Ensure all assembly hardware for the drawers and frame is tightened.
• El tocador sembla inestable: Verify that the dresser is on a level surface. Re-tighten all cam locks and screws in the main frame. Ensure the anti-toppling device is securely installed.
• L'estació de càrrega no funciona: Check if the dresser's main power cord is securely plugged into a functional wall outlet. Test the charging station with different devices to rule out device-specific issues.
• Peces que falten: If any parts are missing upon arrival, please contact chartustriable customer support for assistance.

Especificacions

Garantia i Suport

For any questions, missing parts, or warranty claims, please contact chartustriable customer support directly. Please have your purchase information and model number ready for faster service.

Producte acabatview Imatges
