1. Introducció
Thank you for choosing the BOOTECH BG-Core Deep Tissue Massage Gun. This device is designed to provide effective percussive massage for muscle recovery, pain relief, and improved mobility. With its powerful motor, quiet operation, and versatile attachments, the BG-Core is suitable for athletes, office workers, and anyone seeking to alleviate muscle soreness and tension. Please read this manual thoroughly before use to ensure safe and optimal operation.
2. Informació de seguretat
ADVERTÈNCIA: Per reduir el risc de descàrrega elèctrica, incendi i lesions, aquest producte s'ha d'utilitzar d'acord amb les instruccions següents.
- Consulteu el vostre metge abans d'utilitzar aquest dispositiu, especialment si teniu afeccions mèdiques preexistents, esteu embarassada o porteu un marcapassos.
- No utilitzar sobre ferides obertes, zones inflamades o zones amb danys a la pell.
- Avoid using the device directly on bones, joints, or the head.
- Keep fingers, hair, or any other body parts away from the shaft and back of the massage head to prevent pinching.
- No submergiu el dispositiu en aigua ni l'exposeu a una humitat excessiva.
- Utilitzeu només el cable de càrrega subministrat.
- No modifiqueu ni intenteu reparar el dispositiu vosaltres mateixos. Poseu-vos en contacte amb el servei d'atenció al client per obtenir ajuda.
- Mantenir fora de l'abast dels nens.
3. Contingut del paquet
The BOOTECH BG-Core Deep Tissue Massage Gun package includes:
- BOOTECH BG-Core Massage Gun
- Maletí de transport dur
- Cable de càrrega USB-C
- 5 Interchangeable Massage Heads:
- Cap Rodona
- Cap Pla
- Point Head
- Cap en forma d'U
- Soft Head
- Manual d'usuari (aquest document)
The image above displays the complete set of items you should find in your BOOTECH BG-Core package. Please verify all components are present upon unboxing.
4. Característiques del producte
- Percussió de teixits profunds: 10 mm ampamplitud per a una penetració muscular eficaç.
- 5 nivells de velocitat: Adjustable intensity up to 3000 RPM for varied massage needs.
- Funcionament silenciós: Operates at ≤55dB, allowing for discreet use.
- Bateria de llarga durada: 2000mAh Lithium-Ion battery provides hours of use.
- Càrrega USB-C: Convenient and fast charging, reaching 50% in approximately 30 minutes.
- Disseny ergonòmic: Lightweight (0.65kg) with a non-slip silicone handle for comfortable and fatigue-free use.
- Motor sense escombretes: Durable and efficient motor for consistent performance.
- Portàtil: Includes a rigid carrying case for easy transport and storage.
This image illustrates the core features that make the BG-Core an effective tool for muscle therapy.
5. Configuració
5.1 Càrrega inicial
Before first use, fully charge the massage gun. Connect the USB-C charging cable to the device and a compatible USB power adapter (not included). The battery indicator will show charging status. A full charge typically takes about 3 hours.
5.2 Fixació dels capçals de massatge
To attach a massage head, simply align the head with the opening on the front of the gun and push it firmly into place. To remove, pull the head straight out. Ensure the device is powered off before changing attachments.
6. Instruccions de funcionament
6.1 Encès/Apagat
- Per encendre: Press and hold the power button for approximately 2 seconds until the device vibrates and the indicator lights illuminate.
- Per apagar: Press and hold the power button for approximately 2 seconds until the device stops.
6.2 Adjusting Speed Levels
Once powered on, short press the power button to cycle through the 5 available speed levels. The indicator lights will show the current speed setting.
- Nivell 1: Escalfament
- Nivell 2: Fascia Relief
- Nivell 3: Lactic Acid Decomposition
- Nivell 4: Muscle Mobility
- Nivell 5: Professional Impact
This image provides a visual guide to the different speed settings and their recommended applications.
6.3 Ús general
Apply the massage gun to the desired muscle area. Move the device slowly and gently across the muscle. Do not apply excessive pressure or hold the device in one spot for too long (more than 60 seconds). Focus on muscle knots and tight areas. For best results, use before and after workouts, or for general muscle relaxation.
7. Massage Head Attachments
The BOOTECH BG-Core comes with 5 specialized massage heads, each designed for different muscle groups and massage intensities:
- Cap rodona: Ideal for large muscle groups like the back, glutes, and legs. Provides a general, all-purpose massage.
- Cap pla: Suitable for all body parts, especially for the neck and lower back. Offers a broader, more even pressure.
- Point Head: Designed for deep tissue and trigger point massage on smaller areas like arms and calves.
- Cap en forma d'U: Perfect for massaging around tendons, such as the ankles and elbows, and along the spine (avoid direct contact with bones).
- Soft Head: For sensitive skin and delicate muscle areas, providing a gentler massage experience.
8. Càrrega
The BOOTECH BG-Core is equipped with a 2000mAh Lithium-Ion battery and charges via USB-C. The battery provides extended usage time on a single charge.
- Connecteu el cable USB-C proporcionat al port de càrrega del dispositiu.
- Plug the other end of the cable into a standard USB power adapter (e.g., phone charger, computer USB port).
- The indicator lights will show the charging status. When fully charged, all lights will be solid.
- Una càrrega completa triga aproximadament 3 hores.
This image highlights the convenience of USB-C charging and the extended battery life.
9. Manteniment
9.1 Neteja
- Assegureu-vos que el dispositiu estigui apagat i desconnectat abans de netejar-lo.
- Netegeu el dispositiu amb una mica damp tela. No utilitzeu netejadors abrasius ni productes químics durs.
- For massage heads, they can be gently wiped with a damp cloth and mild soap, then air-dried completely before reattaching.
9.2 Emmagatzematge
Store the massage gun and its accessories in the provided hard carrying case in a cool, dry place, away from direct sunlight and extreme temperatures.
10. Solució De Problemes
If you encounter any issues with your BOOTECH BG-Core Massage Gun, please refer to the following common solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| El dispositiu no s'encén | Low battery; Not powered on correctly | Charge the device fully; Press and hold the power button for 2 seconds. |
| Intensitat de massatge feble | Bateria baixa; Configuració de velocitat incorrecta | Charge the device; Increase the speed level. |
| El cap de massatge cau | No ben fixat | Assegureu-vos que el capçal de massatge estigui ben col·locat al seu lloc. |
| Sorolls o vibracions inusuals | Loose attachment; Internal issue | Check if the attachment is secure; If issue persists, discontinue use and contact support. |
If the problem persists after trying these solutions, please contact BOOTECH customer support for further assistance.
11. Especificacions
| Característica | Especificació |
|---|---|
| Model | BG-Core |
| Marca | BOOTECH |
| Ampla latitud | 10 mm |
| Nivells de velocitat | 5 (fins a 3000 rpm) |
| Nivell de soroll | ≤55 dB |
| Tipus de bateria | 1 bateria de liti-ió (inclosa) |
| Capacitat de la bateria | 2000 mAh |
| Port de càrrega | USB-C |
| Temps de càrrega | Aprox. 3 hores |
| Pes del producte | 0.65 kg (1.43 lliures) |
| Dimensions del producte (L x A x A) | 31 x 21 x 9.6 cm (12.2 x 8.3 x 3.8 polzades) |
| Material | Acrilonitril butadiè estirè (ABS) |
| Tècnica de massatge | Kneading, Percussion |
| Sense fil | Sí |
12. Garantia i Suport
12.1 Garantia
The BOOTECH BG-Core Deep Tissue Massage Gun comes with a 3 any de garantia des de la data de compra, que cobreix els defectes de fabricació. Conserveu el comprovant de compra per a reclamacions de garantia.
This image confirms the 3-year warranty period for the product.
12.2 Atenció al client
For any questions, concerns, or warranty claims, please contact BOOTECH customer support through the retailer where you purchased the product or visit the official BOOTECH weblloc per obtenir informació de contacte.
