Plantronics CT14 Cordless DECT Headset Telephone User Manual

Producte acabatview

The Plantronics CT14 Cordless DECT Headset Telephone is designed for hands-free communication in home and small office environments. It features DECT 6.0 wireless technology for extended range and clear audio, a noise-canceling microphone, and a versatile headset that can be worn over-the-head or over-the-ear.

This system provides freedom of movement with a wireless range of up to 300 feet and offers essential telephone functions through its compact, wearable dial pad.

Contingut del paquet

Abans de començar, assegureu-vos que tots els components estiguin presents al paquet:

• Dial pad with belt clip
• Auriculars
• Charging station with built-in headset stand
• Cable telefònic
• Adaptador d'alimentació CA
• Guia d'usuari (aquest manual)

Image: The Plantronics CT14 system, showing the headset, the compact dial pad with display, and the charging base unit.

Configuració

1. Connexió de la unitat base

1. Connect one end of the supplied telephone cable to the TEL LINE port on the back of the charging station.
2. Connect the other end of the telephone cable to your telephone wall jack.
3. Plug the AC power adapter into the POWER port on the back of the charging station.
4. Plug the other end of the AC power adapter into a working electrical outlet.

2. Charging the Dial Pad

The dial pad comes with a rechargeable battery. For optimal performance, charge the dial pad for at least 12 hours before initial use.

• Place the dial pad into the charging cradle on the charging station. Ensure it is seated correctly and the charging indicator on the dial pad illuminates.

A fully charged dial pad provides up to 10 hours of talk time or 8 days of standby time.

Operating the CT14

Fer i rebre trucades

• Per fer una trucada: Premeu el botó PARLAR button on the dial pad. Dial the desired phone number.
• Per rebre una trucada: Quan soni el telèfon, premeu la tecla PARLAR button on the dial pad.
• Per finalitzar una trucada: Premeu el botó FINALITZACIÓ button on the dial pad.

Dial Pad Functions

The compact dial pad provides easy access to various call management features:

• Control de volum: Use the dedicated volume buttons on the side of the dial pad to adjust listening volume.
• Silenciar: Premeu el botó MUT botó per silenciar temporalment el micròfon. Premeu-lo de nou per activar el so.
• Correu de veu: A one-touch voicemail button provides quick access to your voicemail service (requires subscription through your telephone service provider).
• Identificador de trucada: The backlit LCD display shows caller ID information for incoming calls (stores up to 30 entries).
• Guia telefònica: Store up to 70 contacts in the built-in phonebook for quick dialing.
• Torna a marcar: Access the last dialed number for quick redialing.

Headset Wearing Styles

The CT14 features a 2-in-1 convertible headset, allowing you to choose the most comfortable wearing style:

• Over-the-Head: Attach the headband for stability and comfort during long calls or conferencing.
• Over-the-Ear: Disconnect the headband and attach the ear loop for a discreet and lightweight fit.

Imatge: Una imatge detallada view of the Plantronics CT14 headset, highlighting its flexible microphone and ear hook design.

Característiques i tecnologia clau

• DECT 6.0 Wireless Technology: Operates on the 1.9 GHz frequency, providing an interference-free wireless range of up to 300 feet. This dedicated frequency minimizes interference from Wi-Fi networks and other home appliances, ensuring clear communication.
• Micròfon amb cancel·lació de soroll: The flexible microphone is designed to transmit your voice clearly while reducing background noise, making it ideal for busy environments.
• Durada de la bateria ampliada: The dial pad offers up to 10 hours of continuous talk time and up to 8 days of standby time on a single charge, supporting all-day use.

Image: A user demonstrating the wireless range of the Plantronics CT14, highlighting the freedom of movement provided by the DECT 6.0 technology.

Manteniment

Cura de la bateria

• Always return the dial pad to the charging cradle when not in use to ensure it is charged for your next call.
• Eviteu esgotar completament la bateria amb freqüència, ja que això pot reduir-ne la vida útil total.
• If the battery performance degrades significantly over time, it may need to be replaced. Refer to the manufacturer's guidelines for replacement batteries.

Neteja

• Wipe the headset and dial pad with a soft, dry cloth.
• No utilitzeu netejadors abrasius ni dissolvents, ja que poden danyar la superfície.

Resolució de problemes

If you experience issues with your Plantronics CT14, try the following solutions:

For more detailed troubleshooting, please refer to the official user manual available for download from the Plantronics support website or the provided PDF link: Plantronics CT14 Installation Manual (PDF) i Plantronics CT14 User Manual (PDF).

Especificacions

Informació de la garantia

The Plantronics CT14 Cordless DECT Headset Telephone is backed by a one-year limited warranty. Please retain your proof of purchase for warranty claims. For specific terms and conditions, refer to the warranty documentation included with your product or visit the official Plantronics (Poly) weblloc.

Atenció al client

For further assistance, technical support, or information on accessories, please visit the official Plantronics (now Poly) support weblloc web o poseu-vos en contacte amb el seu departament d'atenció al client. Normalment, podeu trobar la informació de contacte al fabricant weblloc web o a l'embalatge original del producte.

Online resources often include FAQs, updated manuals, and software downloads.
