Schlage F58 ADD 619 Addison Exterior Handleset with Deadbolt, Satin Nickel - Instruction Manual

1. Producte acabatview

The Schlage F58 ADD 619 Addison Exterior Handleset with Deadbolt in Satin Nickel is designed for exterior doors, providing both security and aesthetic appeal. This product includes the exterior half of the handleset, featuring a robust deadbolt and a stylish Addison grip. It is engineered for durability and ease of installation, particularly with its adjustable through-bolt mechanism.

This image displays the complete exterior handleset, featuring the Addison design in a satin nickel finish, including the deadbolt and lower grip.

2. Característiques clau

• Exterior Half Only: This package contains the exterior components of the handleset. An F59 interior component is required to complete the full handleset.
• Adjustable Through-Bolt: Features a patented adjustable bottom through-bolt that moves up and down 1 1/2 inches, allowing for easy installation and compatibility with pre-existing door holes without additional drilling.
• Preparació de la porta: Requires a minimum 4-inch center-to-center door preparation for this two-piece model.
• Construcció duradora: Made from brass and metal for long-lasting performance and security.

3. Guia d'instal·lació

Proper installation is crucial for the security and functionality of your Schlage handleset. This guide provides general steps; always refer to the detailed instructions included with your product for specific installation procedures.

3.1. Comprovacions prèvies a la instal·lació

• Ensure your door has the required minimum 4-inch center-to-center door prep.
• Verify all components are present: exterior handleset, deadbolt cylinder, and keys. Note that interior components (F59) are sold separately.

3.2. Instal·lació pas a pas

1. Prepara la porta: If installing on a new door, ensure all necessary holes are drilled according to the template provided with the full handleset. For existing doors, utilize the adjustable through-bolt feature.
2. Instal·leu el forrellat: Insert the deadbolt mechanism into the door edge. Secure it with screws.
3. Position the Exterior Handleset: Place the exterior handleset onto the door, aligning the deadbolt cylinder with the deadbolt mechanism.
4. Adjust the Through-Bolt: Utilize the patented adjustable bottom through-bolt to align with the existing lower hole in your door. This feature allows for vertical adjustment of up to 1 1/2 inches.
5. Secure the Handleset: Fasten the exterior handleset using the provided screws. Ensure all components are snug but do not overtighten.
6. Install Interior Components: Attach the interior thumbturn/trim for the deadbolt and the interior lever/knob (F59, sold separately) according to their respective instructions.
7. Funcionalitat de prova: After installation, test the deadbolt and handle operation with the key and from the interior to ensure smooth and secure locking/unlocking.

This diagram highlights the patented adjustable bottom through-bolt, which slides up and down 1 1/2 inches to accommodate pre-existing door holes, simplifying installation and eliminating the need for additional drilling or patching.

This diagram provides key dimensions for the Addison handleset, including center-to-center grip range (8-3/8 to 9-7/8 inches), height of top escutcheon (3-1/2 inches), grip height (12-7/16 inches), door prep range (4-5-1/2 inches, 5.5 ideal), total handleset height (18-1/8 inches for 5.5 door prep), projection from door (3-3/16 inches), and width of escutcheon (3 inches).

3.3. Build Your Own Handleset (Video)

This official video from Schlage Lock Company illustrates the process of assembling a custom handleset, showcasing various grip styles and deadbolt options, including mechanical, keypad, and smart deadbolts like Schlage Touch and Schlage Encode.

4. Funcionament

The Schlage Addison Handleset provides secure entry and exit for your home.

4.1. Locking the Deadbolt

• From Exterior: Insert the key into the deadbolt cylinder and turn it to extend the bolt into the door frame. Remove the key.
• Des de l'interior: Rotate the thumbturn on the interior side of the deadbolt to extend the bolt.

4.2. Unlocking the Deadbolt

• From Exterior: Insert the key into the deadbolt cylinder and turn it to retract the bolt.
• Des de l'interior: Rotate the thumbturn on the interior side of the deadbolt to retract the bolt.

4.3. Operating the Handleset Grip

• To open the door, depress the thumb-latch on the exterior grip. This retracts the latch bolt.
• From the interior, use the corresponding interior lever or knob (sold separately) to retract the latch bolt and open the door.

5. Manteniment

Regular maintenance helps ensure the longevity and smooth operation of your handleset.

• Neteja: Netegeu les superfícies exteriors amb un drap suau iamp drap. Eviteu netejadors abrasius, dissolvents o productes químics agressius, ja que poden danyar l'acabat.
• Lubricació: Periodically apply a small amount of graphite lubricant or a silicone-based spray to the keyway and internal mechanisms of the deadbolt to maintain smooth operation. Do not use oil-based lubricants, as they can attract dirt.
• Inspecció: Regularly check all screws and fasteners to ensure they are tight. Inspect for any signs of wear or damage and address them promptly.

6. Solució De Problemes

If you encounter issues with your handleset, try these common troubleshooting steps:

• La clau és rígida o difícil de girar: Apply graphite lubricant to the keyway. Ensure the key is fully inserted and is the correct key for the lock. Check for any obstructions in the keyway.
• Deadbolt Does Not Extend/Retract Fully: Check if the strike plate on the door frame is properly aligned with the deadbolt. Adjust the strike plate if necessary. Ensure the door is properly aligned and not warped.
• Handle Latch is Sticky: Clean the latch mechanism and apply a small amount of silicone spray. Check for any debris obstructing the latch.
• Loose Handleset: Tighten all mounting screws. If the handleset continues to loosen, inspect the door for damage around the mounting holes.

If problems persist after attempting these steps, contact Schlage customer support or a qualified locksmith.

7. Especificacions

7.1. Security Grading

This chart explains the American National Standards Institute (ANSI) security ratings for building hardware. Grade 1 is for commercial use, Grade 2 for home use, and Grade 3 for home use, indicating varying levels of security.

8. Garantia i Suport

Schlage products are backed by a manufacturer's warranty. For specific warranty details, including coverage and duration, please refer to the documentation provided with your product or visit the official Schlage weblloc.

For technical assistance, troubleshooting beyond this manual, or to inquire about replacement parts, please contact Schlage customer support directly. Contact information can typically be found on the manufacturer's weblloc o embalatge del producte.
