1. Introducció
This manual provides essential information for the safe and efficient operation of your Siruba HSM-2212 Double Needle Sewing Machine. Designed for beginners, this machine features 12 built-in stitch patterns, including basic straight stitch, zigzag stitch, 4-step buttonhole stitch, and zipper stitch. It is equipped with a light for a brighter work area, a bobbin winder, and a thread cutter to enhance your sewing experience. Please read this manual thoroughly before using the machine.
Figura 1.1: Davant view of the Siruba HSM-2212 Double Needle Sewing Machine. This image displays the machine's compact design, stitch selector dial, and the main sewing area.
2. Configuració
2.1 Desembalatge i verificació del contingut
Carefully remove the sewing machine and all accessories from the packaging. Verify that all components listed below are present.
- Multi-purpose foot (pre-installed on machine)
- Peu d'ojal
- Peu de cremallera
- Bobbin (plastic)
- Tornavís
- Needle plate screwdriver
- Feltre
- Buttonhole cutter
- Feed dog cover plate
- Needle set (3 standard needles + 1 twin needle)
- Spool pins (2 additional)
- Low shank adapter (pre-installed on machine)
- English instruction book
2.2 Connexió d'alimentació
Connect the power cord to the machine's power input and then to a suitable electrical outlet. Ensure the power switch is in the "OFF" position before connecting.
2.3 Enrotllament de la bobina
Before sewing, the bobbin must be wound with thread. Place a spool of thread on the spool pin, guide the thread through the tension disc for bobbin winding, and then around the bobbin. Place the bobbin onto the bobbin winder spindle and push it to the right. Start the machine to wind the bobbin evenly.
2.4 Enfilar la màquina
Proper threading is crucial for correct stitch formation. Follow the numbered threading path indicated on the machine. Ensure the presser foot is raised and the needle is in its highest position before threading the upper thread. Insert the bobbin into the bobbin case according to the instructions in the included instruction book.
Figura 2.1: Primer pla view of the needle plate and feed dogs. These components are essential for fabric movement and stitch formation.
3. Instruccions de funcionament
3.1 Selecció de puntades
Your Siruba HSM-2212 machine offers 12 built-in stitch patterns. To select a stitch, turn the stitch selector dial located on the front of the machine until the desired stitch pattern aligns with the indicator mark.
Figura 3.1: Close-up of the stitch selector dial. This dial allows you to choose from the 12 available stitch patterns, indicated by letters and symbols.
Figura 3.2: Examples of various stitch patterns created by the machine on fabric. This demonstrates the versatility of the built-in stitches for different sewing projects.
3.2 Stitch Length and Width Adjustment
The stitch length can be adjusted from 0 to 4.0 mm using the selector dial. The integrated stitch width is 0 to 5.0 mm, also adjustable via the selector dial. Refer to the markings on the dial for precise adjustments.
3.3 Ús de diferents peus de premsatela
The machine comes with several presser feet for different sewing tasks:
- Multi-purpose Foot: Per a tasques generals de costura.
- Peu per a butoneres: Used for creating 4-step buttonholes.
- Peu de cremallera: Ideal for sewing zippers.
Figura 3.3: Example of a zigzag stitch being sewn. This stitch is versatile for finishing seams and decorative purposes.
Figura 3.4: The zipper foot attached to the machine, demonstrating its use for sewing close to zipper teeth.
Figura 3.5: The buttonhole foot in action, creating a precise buttonhole. The markings on the foot assist in achieving the correct length.
3.4 Cosir inversament
To reinforce stitches at the beginning and end of a seam, press and hold the reverse lever or button. The machine will sew backward. Release the lever/button to resume forward sewing. This feature ensures stronger seams.
3.5 Costura amb braç lliure
The removable extension table allows for free arm sewing, which is ideal for sewing cuffs, sleeves, pant hems, and other small, circular items. Simply slide off the extension table to expose the free arm.
4. Manteniment
4.1 Neteja
Regular cleaning helps maintain your machine's performance.
- Feed Dogs and Bobbin Area: Turn off and unplug the machine. Remove the needle plate and bobbin case. Use a small brush to remove lint and dust from the feed dogs and bobbin area.
- Exterior: Netegeu les superfícies exteriors amb un drap suau i sec. No utilitzeu productes químics agressius ni netejadors abrasius.
4.2 Substitució de l'agulla
Replace the needle regularly (after 8-10 hours of sewing or when it becomes dull/bent) to prevent skipped stitches and fabric damage. Ensure the flat side of the needle faces the back of the machine when inserting. Use the needle plate screwdriver for this task.
4.3 Emmagatzematge
When not in use, store the machine in a dry, dust-free environment. It is recommended to cover the machine to protect it from dust.
5. Solució De Problemes
This section addresses common issues you might encounter. For more detailed troubleshooting, refer to the comprehensive instruction book included with your machine.
| Problema | Causa possible | Solució |
|---|---|---|
| Punts saltats | Incorrect needle, bent needle, improper threading, incorrect tension. | Replace needle, re-thread machine, adjust tension. |
| Trenca fil | Incorrect threading, too much tension, dull needle, poor quality thread. | Re-thread machine, reduce tension, replace needle, use quality thread. |
| La màquina no arrenca | Power cord not connected, power switch off, foot pedal issue. | Check power connections, ensure switch is ON, check foot pedal. |
| Punts desiguals | Incorrect tension, wrong needle for fabric, fabric being pulled. | Adjust tension, use appropriate needle, guide fabric gently. |
6. Especificacions
| Característica | Detall |
|---|---|
| Model | HSM-2212 |
| Marca | SIRUBA |
| Patrons de punt | 12 built-in patterns (including straight, zigzag, 4-step buttonhole, zipper) |
| Longitud de la puntada | Ajustable de 0 a 4.0 mm |
| Amplada de puntada | Ajustable de 0 a 5.0 mm |
| Velocitat de costura | 720 ~ 780 stitches per minute (s.p.m) |
| Tipus d'agulla | Standard home sewing machine needles, twin needle compatible |
| Font d'alimentació | Elèctric amb cable |
| Dimensions del producte | 16.51 x 38.1 x 30.48 cm (6.5 x 15 x 12 polzades) |
| Pes de l'article | 6.35 kg (14 lliures) |
| Material | Plàstic |
| Color | Blanc |
| Muntatge obligatori | Yes (minor assembly) |
7. Informació de la garantia
For detailed warranty information, please refer to the warranty card or documentation included with your Siruba HSM-2212 sewing machine. Warranty terms and conditions may vary by region and retailer. Keep your proof of purchase for warranty claims.
8. Atenció al client
If you require further assistance, have questions not covered in this manual, or need technical support, please contact Siruba customer service. Refer to the contact information provided in your product packaging or visit the official Siruba weblloc web per obtenir els detalls d'assistència més actualitzats.
