Soundmaster UR 2006 Portable Radio User Manual

Introducció

This user manual provides detailed instructions for the operation, setup, maintenance, and troubleshooting of your Soundmaster UR 2006 Portable Radio. Please read this manual thoroughly before using the device to ensure proper functionality and to maximize your listening experience.

Producte acabatview

The Soundmaster UR 2006 is a versatile portable radio designed for convenience and quality audio. Its compact design and advanced features make it an ideal addition to any kitchen or living space.

Característiques principals:

• FM PLL Radio with 30 preset stations.
• LCD clock with radio reception.
• Fully automatic time setting via DCF-77 radio signal.
• Power reserve for inserted batteries (1 x CR2032, to be ordered separately).
• Exclusive aluminum front panel.
• Blue backlit LCD display.
• Bass support for enhanced audio.
• Electronic volume control.
• Alarm function with radio or buzzer.
• Two alarm time settings.
• Temporitzador de 120 minuts.
• Disseny portàtil.

Figura 1: Frontal view of the Soundmaster UR 2006 Portable Radio, displaying the frequency and controls.

Configuració

1. Desembalatge i inspecció inicial

Carefully remove the radio from its packaging. Inspect the unit for any signs of damage. The package should contain the Soundmaster UR 2006 radio unit.

2. Connexió d'alimentació

Connect the radio to a standard AC power outlet using the provided power adapter. The radio also supports battery backup for time retention (requires 1 x CR2032 battery, not included).

3. Battery Installation (for time backup)

1. Locate the battery compartment, usually on the bottom or rear of the unit.
2. Obriu la coberta del compartiment.
3. Inseriu una pila CR2032, assegurant-vos de la polaritat correcta (+/-).
4. Tanqueu bé la tapa del compartiment de la bateria.

4. Col·locació i muntatge

The Soundmaster UR 2006 is designed as a portable or under-cabinet radio. For optimal radio reception, place the unit away from large metal objects or other electronic devices that may cause interference. If mounting under a cabinet:

• Identify a suitable flat surface under a cabinet.
• Use appropriate screws and mounting brackets (not explicitly mentioned as included, but implied by "Unterbauradio" and review comments about mounting) to secure the radio. Ensure the mounting is stable and safe.
• Avoid placing near heat sources or in areas with excessive moisture.

Figure 2: The Soundmaster UR 2006 Portable Radio shown mounted under a kitchen cabinet.

Instruccions de funcionament

1. Encendre/apagar

Premeu el botó On/Off botó per encendre o apagar la ràdio.

2. Radio Tuning (FM/AM/PLL)

The radio supports FM, AM, and PLL bands. Use the Mode button to switch between radio bands. Use the Up i Avall buttons to manually tune to desired frequencies. For automatic station search, press and hold the Up or Avall botó.

3. Setting Presets

The radio can store up to 30 preset stations.

1. Sintonitza l'emissora desitjada.
2. Premeu el botó Memòria botó. El número preestablert parpellejarà a la pantalla.
3. Utilitza el Up or Avall botons per seleccionar el número preestablert desitjat.
4. Premeu Memòria de nou per confirmar i desar l'emissora.

To recall a preset station, press the Preestablert botó repetidament o utilitzeu Up i Avall buttons after pressing Preestablert una vegada.

4. Control de volum

Ajusteu el volum d'escolta amb el botó Vol+ i tornar buttons. The electronic volume control ensures smooth adjustments.

5. Clock and Time Setting

The LCD clock features fully automatic time setting via the DCF-77 radio signal. Ensure the radio is placed in an area with good reception for the time signal. Manual time adjustment may be available if automatic synchronization fails (refer to specific button combinations on the device, typically involving a "Time Set" or "Clock" button).

6. Funció d'alarma

The radio supports two alarm time settings.

1. Premeu el botó Conjunt d'alarma botó.
2. Utilitza el Up i Avall buttons to set the desired alarm time (Alarm 1 or Alarm 2).
3. Premeu Conjunt d'alarma de nou per confirmar.
4. Select the alarm source (radio or buzzer) using the Mode or Conjunt d'alarma botó.
5. Per activar/desactivar l'alarma, premeu el botó Conjunt d'alarma button until the alarm icon appears/disappears.

Per posposar l'alarma, premeu el botó ADT/Snooze button when the alarm sounds. To turn off the alarm, press the On/Off botó.

7. Funció de temporitzador

The radio includes a 120-minute timer (sleep timer).

Premeu el botó Temporitzador button repeatedly to cycle through available timer settings (e.g., 120, 90, 60, 30, 15 minutes, or Off). The radio will automatically turn off after the selected time duration.

8. Bass Support

Premeu el botó Baix button to activate or deactivate the bass enhancement feature for richer sound.

Manteniment

1. Neteja

Wipe the exterior of the radio with a soft, dry cloth. For stubborn marks, a slightly damp cloth can be used, followed by a dry cloth. Do not use abrasive cleaners, waxes, or solvents as they may damage the finish.

2. Substitució de la bateria

If the time backup function is not working, replace the CR2032 battery in the battery compartment. Dispose of old batteries responsibly.

3. Emmagatzematge

If storing the radio for an extended period, disconnect it from the power outlet and remove the CR2032 battery to prevent leakage.

Resolució de problemes

Especificacions

Garantia i Suport

For warranty information and technical support, please refer to the documentation provided with your purchase or visit the official Soundmaster weblloc web. Conserveu el comprovant de compra per a qualsevol reclamació de garantia.

If you encounter issues not covered in this manual, please contact Soundmaster customer service for assistance.
