Manual d'usuari de la màquina de neu amb control sense fil Antari SW-250

1. Introducció

Thank you for choosing the Antari SW-250 Wireless Control Snow Machine. This manual provides essential information for the safe and efficient operation, setup, and maintenance of your device. Please read this manual thoroughly before operating the machine and retain it for future reference.

The Antari SW-250 is a high-output snow machine designed to produce realistic snow effects for various applications, controlled conveniently via a wireless remote.

2. Instruccions de seguretat

Per garantir un funcionament segur i evitar danys, observeu les precaucions de seguretat següents:

• Seguretat elèctrica: Always connect the machine to a grounded power outlet. Ensure the power supply matches the machine's requirements (AC 100V / AC 120V / AC 230V / AC 240V 50Hz-60Hz). Disconnect power before cleaning or servicing.
• Manipulació de fluids: Use only Antari SL-5A Premium Water Based Snow Fluid. Do not ingest snow fluid. In case of contact with eyes or skin, rinse thoroughly with water. Keep fluid out of reach of children.
• Col·locació: Position the machine on a stable, level surface. Ensure adequate ventilation around the unit. Do not block ventilation openings. Maintain a safe distance from flammable materials and heat sources.
• Funcionament: Do not operate the machine if the power cord is damaged. Do not attempt to modify or repair the unit yourself. Refer all servicing to qualified personnel.
• Condicions ambientals: Do not expose the machine to rain or moisture. Operate within recommended temperature ranges.

3. Producte acabatview

The Antari SW-250 is designed for ease of use and reliable performance. Familiarize yourself with its main components.

Imatge 1: Frontal view of the Antari SW-250 Snow Machine. This image displays the main body of the snow machine, including the output nozzle on the left, ventilation grilles, and the integrated carrying handle. The Antari logo and 'SW-250 SNOW WIRELESS' branding are visible on the side.

Imatge 2: posterior view of the Antari SW-250 Snow Machine. This image shows the back panel of the machine, highlighting the power input, power switch, control inputs (including XLR ports for optional wired control), and the transparent fluid tank with its cap and fluid line visible on the top right.

Imatge 3: The Antari W-1 Wireless Remote Control. This compact, metallic remote features two main buttons, 'A' and 'B', and a blue indicator light. It is used for wireless ON/OFF control of the snow machine.

4. Configuració

1. Desembalatge: Carefully remove the SW-250 from its packaging. Inspect the unit for any signs of damage during transit.
2. Col·locació: Place the snow machine on a flat, stable surface. Ensure there is sufficient space around the unit for proper ventilation. If using the included hanging bracket, securely mount the machine to a suitable truss or support structure, ensuring it is balanced and stable.
3. Fluid Loading: Unscrew the cap of the fluid tank. Carefully pour Antari SL-5A Premium Water Based Snow Fluid into the tank, ensuring not to overfill. Securely replace the cap. The tank capacity is 5 liters.
4. Connexió d'alimentació: Connect the power cord to the machine's power input and then to a grounded electrical outlet that matches the specified voltage (AC 100V / AC 120V / AC 230V / AC 240V 50Hz-60Hz).
5. Configuració remota sense fil: The W-1 Wireless Remote is pre-paired. Ensure the remote has functional batteries.

5. Funcionament

Follow these steps to operate your Antari SW-250 Snow Machine:

1. Encès: Flip the main power switch on the rear of the machine to the 'ON' position. The machine will begin its warm-up cycle.
2. Escalfament: Allow the machine a few minutes to reach its operating temperature. The indicator light on the unit will signal when it is ready for operation.
3. Control sense fil: Use the W-1 Wireless Remote to activate the snow output. Press the 'A' or 'B' button on the remote to turn the snow effect ON or OFF. The remote has a range of up to 164 ft. / 50 m.
4. Snow Output: Once activated, the machine will begin to produce snow at an output rate of approximately 320 ml/min. The fluid consumption rate is approximately 5 minutes per liter.
5. Apagar: To stop operation, press the ON/OFF button on the wireless remote. For complete shutdown, turn off the main power switch on the machine and disconnect it from the power source.

Imatge 4: The Antari SW-250 Snow Machine in operation, demonstrating its capability to produce a wide spread of artificial snow. The machine is positioned on the right, emitting snow particles across a dark background.

6. Manteniment

Regular maintenance ensures the longevity and optimal performance of your SW-250.

• Neteja: Periodically wipe the exterior of the machine with a soft, dry cloth. Do not use abrasive cleaners or solvents. Ensure ventilation grilles are free from dust and debris.
• Dipòsit de fluids: If the machine will not be used for an extended period, empty any remaining snow fluid from the tank. Rinse the tank with distilled water and allow it to air dry before storage.
• Emmagatzematge: Guardeu la màquina en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.

7. Solució De Problemes

If you encounter issues with your Antari SW-250, refer to the following common problems and solutions:

• Sense energia:
  • Check if the power cord is securely connected to both the machine and a live electrical outlet.
  • Ensure the main power switch on the machine is in the 'ON' position.
  • Verify the power outlet is functioning correctly by testing it with another device.
• No Snow Output:
  • Check if the fluid tank contains sufficient Antari SL-5A Premium Water Based Snow Fluid.
  • Ensure the machine has completed its warm-up cycle.
  • Verify the W-1 Wireless Remote is functioning and within range. Replace batteries if necessary.
  • Check for any blockages in the fluid line or nozzle.
• Wireless Remote Not Responding:
  • Ensure the remote's batteries are fresh and correctly inserted.
  • Confirm you are within the operational range (up to 164 ft. / 50 m) and there are no significant obstructions.

If problems persist after attempting these solutions, contact Antari customer support or a qualified service technician.

8. Especificacions

9. Garantia i Suport

For warranty information, technical support, or service inquiries, please refer to the warranty card included with your product or visit the official Antari weblloc web. Conserveu el rebut de compra com a comprovant de compra.
