1. Producte acabatview i Característiques
The ABUS 26/70 Diskus Padlock is engineered for high-security applications, particularly for storage of valuable items. Its unique Diskus design minimizes exposure of the shackle, offering enhanced resistance against common attack methods.
- Dimensions: Lock width: 2.75in (70mm), Height: 2.75in (70mm), Depth: 1.19in (30.2mm), Horizontal Clearance: 0.75in (19.1mm), Vertical Clearance: 0.7in (17.1mm), Shackle Diameter: 0.39in (9.9mm).
- Teclat: Supplied with 2 unique keys (keyed different). The lock features a key-retaining mechanism, meaning the key is required for locking.
- Aplicacions: Suitable for securing storage units, transport containers, and commercial properties. The closed shackle design provides security against prying and tamperrant.
- Durabilitat: Constructed from solid stainless steel, minimizing vulnerabilities and offering protection against environmental elements and tampering. The shackle is made from special alloy hardened steel.
- Security Technology: Features Diskus Deep-Welding Technology for maximum strength and pry resistance. The original Diskus design includes 360-degree drilling and pulling protection, with a welded seam for high break resistance. The cylinder is drill and pull resistant.
2. Imatges del producte
3. Vídeos de productes
4. Configuració
- Desembalatge: Carefully remove the padlock and keys from the packaging. Inspect for any visible damage.
- Identificació de la clau: Each padlock comes with two unique keys. Keep one key in a safe, accessible location and the other as a spare. Note that this padlock is key-retaining, meaning the key must be inserted and turned to lock the shackle.
- Prova inicial: Before deployment, insert a key into the keyway and turn it clockwise to open the shackle. Ensure the shackle moves freely. Close the shackle and turn the key counter-clockwise to lock it. Remove the key.
5. Instruccions de funcionament
- Per desbloquejar:
- Introduïu la clau completament a la ranura.
- Gireu la clau en sentit horari fins que les molles de la grilleta s'obrin.
- Remove the padlock from the hasp or securing point.
- Tancar:
- Position the padlock so the shackle aligns with the locking mechanism (e.g., hasp).
- Close the shackle firmly.
- Insert the key into the keyway.
- Turn the key counter-clockwise until the shackle is securely locked.
- Remove the key. The padlock is now secured.
6. Manteniment
Regular maintenance ensures the longevity and smooth operation of your ABUS Diskus padlock.
- Lubricació: Periodically apply a small amount of graphite powder or a non-oil-based lubricant specifically designed for locks into the keyway. Avoid using oil-based lubricants as they can attract dirt and debris, potentially jamming the mechanism.
- Neteja: Wipe the padlock body with a clean, dry cloth to remove dirt and grime. For stubborn dirt, a mild soap solution can be used, followed by thorough drying.
- Oil Residue: As noted in the product information, new padlocks may have a visible oil residue on the surface. This is a protective layer and does not indicate a defect. It can be wiped off if desired.
- Atenció clau: Keep keys clean and free from bending or damage. Do not force a key if it does not turn smoothly.
7. Solució De Problemes
- La clau s'enganxa o té dificultats per girar:
- Apply a small amount of graphite powder or a specialized lock lubricant into the keyway.
- Ensure the key is fully inserted before attempting to turn.
- Check the key for any bends or damage. Use a different key if available.
- Shackle Does Not Open/Close Smoothly:
- Check for any obstructions around the shackle or within the padlock body.
- Ensure the key is turned completely to the open or closed position.
- Lubricate the shackle mechanism as described in the Maintenance section.
- Padlock is Frozen (in cold climates):
- Use a de-icing spray specifically designed for locks. Avoid using hot water as it can refreeze and cause further issues.
- Regular lubrication with appropriate products can help prevent freezing.
8. Especificacions
| Atribut | Valor |
|---|---|
| Marca | ABUS |
| Nom del model | 26/70 |
| Número de model de l'article | 26/70 KD |
| Tipus de bloqueig | Bloqueig de clau |
| Estil | Clau diferent |
| Material | Alloy Steel, Aluminum, Brass, Stainless Steel |
| Característiques especials | Anti-Corrosion, Anti-Drill, Cut Resistant |
| Dimensions de l'article (L x A x A) | 2.81 x 3.39 x 1.17 polzades |
| Pes de l'article | 0.95 lliures (15.2 unces) |
| Forma | Ronda |
| Nombre de peces | 1 |
| Usos recomanats | Seguretat |
9. Garantia i assistència
Informació de la garantia
If an ABUS product fails to work properly due to a manufacturing defect, return it to ABUS postage prepaid, and it will be repaired or replaced at ABUS's discretion. To obtain warranty service, please call 1-800-352-2287 or simply return the padlock prepaid along with the receipt of purchase and all parts and keys (if applicable) to: ABUS Lock Company, 23910 N 19th Ave., Suite 56, Phoenix, AZ 85085-1850. ABUS products are warranted for a specific period of time from the date of purchase. Specific warranty periods appear on the packaging.
Atenció al client
For further assistance or inquiries, please contact ABUS customer support:
- Telèfon: 1-800-352-2287
- Weblloc: Visit the official ABUS website for product information and FAQs.
