Timex TW2P64900 Chronograph Quartz Watch User Manual

Introducció

This manual provides comprehensive instructions for the Timex TW2P64900 Chronograph Quartz Watch. Please read this manual carefully to understand the functions and proper operation of your watch. This classic chronograph watch features a comfortable leather strap, date display, luminous hands, and Indiglo night-light.

Característiques clau

• Funció de cronògraf: Measures elapsed time with precision.
• Visualització de la data: Funció de calendari convenient.
• Mans lluminoses: Enhanced visibility in low light conditions.
• Llum nocturna Indiglo: Electroluminescent backlight for the entire dial.
• Resistència a l'aigua: Classificat per a 50 metres (5 ATM).
• Construcció duradora: Stainless steel case with mineral dial window and genuine leather strap.

Components del rellotge

Imatge 1: Davant view of the Timex TW2P64900 Chronograph Quartz Watch. This image displays the watch's black dial, three sub-dials for the chronograph, date window, and the brown leather strap with a buckle clasp. The crown and pushers are visible on the right side of the case.

1. Corona (A): Used for setting time and date, and activating Indiglo.
2. Pusher (B): Chronograph Start/Stop button.
3. Pusher (C): Chronograph Reset button.
4. Agulla de les hores
5. Minut de la mà
6. Small Second Hand (Sub-dial)
7. Chronograph Second Hand (Large)
8. Chronograph Minute Hand (Sub-dial)
9. Chronograph Hour Hand (Sub-dial)
10. Finestra de dates

Configuració i ajust inicial

Establiment de l'hora

1. Estireu la corona (A) fins a la posició 2.
2. Turn the crown (A) clockwise or counter-clockwise to set the correct time. Ensure AM/PM is correctly set if your watch has a 24-hour indicator or if setting the date.
3. Push the crown (A) back into position 0 to start the watch.

Establiment de la data

1. Estireu la corona (A) fins a la posició 1.
2. Turn the crown (A) clockwise or counter-clockwise to set the correct date.
3. Push the crown (A) back into position 0.
4. Nota: Avoid setting the date between 9 PM and 3 AM, as this may interfere with the automatic date change mechanism. If the date needs to be set during this period, first set the time outside this range, adjust the date, then reset the time.

Funcionament del rellotge

Ús del cronògraf

1. Inici: Press pusher (B) to start the chronograph. The large second hand will begin to move, along with the chronograph minute and hour sub-dials.
2. Atura: Press pusher (B) again to stop the chronograph. The elapsed time will be displayed.
3. Restablir: After stopping, press pusher (C) to reset all chronograph hands to their zero positions.
4. Nota: The large second hand is exclusively for the chronograph function and does not continuously tick for the time display. The small sub-dial second hand indicates the running seconds for the main time.

Using Indiglo Night-Light

To activate the Indiglo night-light, press and hold the crown (A) firmly. The entire dial will illuminate for easy reading in the dark. Release the crown to turn off the light.

Manteniment i cura

Resistència a l'aigua

Your Timex TW2P64900 watch is water-resistant to 50 meters (5 ATM). This means it is suitable for short periods of recreational swimming, showering, or washing hands. It is no suitable for diving, snorkeling, or prolonged water exposure. Always ensure the crown is fully pushed in before any contact with water.

Neteja

Wipe the watch case and crystal with a soft, dry cloth. For the leather strap, avoid excessive moisture and harsh chemicals. If the strap gets wet, allow it to air dry naturally. Regular cleaning helps maintain the watch's appearance.

Canvi de bateria

The watch is powered by a quartz movement requiring a battery. When the battery needs replacement, it is recommended to take your watch to an authorized Timex service center or a reputable watchmaker. This ensures proper battery installation and maintenance of water resistance.

Resolució de problemes

• El rellotge no funciona:
  • Check if the crown (A) is fully pushed into position 0.
  • The battery may need replacement. Refer to the "Battery Replacement" section.
• Les agulles del cronògraf no es reinicien a zero:
  • Ensure the chronograph is stopped (press pusher B if it's running).
  • Press pusher C firmly to reset. If hands are misaligned, consult a service center for adjustment.
• Data sense canvis:
  • Ensure the time is set correctly for AM/PM. The date changes around midnight.
  • Eviteu establir la data entre les 21:00 i les 3:00.

Especificacions

Garantia i Suport

Your Timex TW2P64900 watch comes with a Garantia del fabricant de 2 anys des de la data de compra. Aquesta garantia cobreix els defectes de fabricació en condicions d'ús normal. No cobreix els danys resultants d'una manipulació inadequada, accidents, reparacions no autoritzades o desgast normal.

For warranty claims, service, or further assistance, please contact Timex customer support or visit their official weblloc web. Conserveu el comprovant de compra per validar la garantia.

Timex Oficial Weblloc: www.timex.com
