Magefesa Qualix 6 Liter Super Fast Pressure Cooker User Manual

1. Introducció

Thank you for choosing the Magefesa Qualix 6 Liter Super Fast Pressure Cooker. This appliance is designed to provide efficient and healthy cooking results, significantly reducing cooking times while preserving nutrients. Crafted from durable 18/10 stainless steel with a 5-layer thermodiffuser base, it is compatible with all types of cooktops, including induction. Please read this manual thoroughly before first use to ensure safe and optimal operation.

2. Instruccions de seguretat importants

ADVERTIMENT: Si no seguiu aquestes instruccions, podreu provocar lesions greus o danys materials.

• Llegiu atentament totes les instruccions abans d'utilitzar l'olla a pressió.
• No toqueu superfícies calentes. Utilitzeu nanses o poms.
• És necessària una supervisió estreta quan l’olla a pressió s’utilitza a prop de nens.
• No col·loqueu l'olla a pressió en un forn calent.
• Aneu amb extrema precaució quan moveu una olla a pressió que contingui líquids calents.
• No utilitzeu l'olla a pressió per a altres finalitats que no siguin per a les quals està prevista.
• This appliance cooks under pressure. Improper use may result in scalding injury. Make certain unit is properly closed before operating. See "Closing the Lid" section.
• Do not fill the unit over 2/3 full. When cooking foods that expand during cooking, such as rice or dried vegetables, do not fill the unit over 1/2 full. Overfilling may cause a risk of clogging the vent pipe and developing excess pressure. See "Filling the Cooker" section.
• Tingueu en compte que certs aliments, com ara la compota de poma, els nabius, l'ordi perlat, la farina de civada o altres cereals, els pèsols partits, els fideus, els macarrons, el ruibarbre o els espaguetis poden fer escuma, esquitxar i obstruir el dispositiu d'alliberament de pressió. Aquests aliments no s'han de cuinar en una olla a pressió.
• Comproveu sempre que els dispositius d'alliberament de pressió estiguin obstruïts abans d'utilitzar-los.
• Do not open the pressure cooker until the unit has cooled and all internal pressure has been released. If the handles are difficult to push apart, this indicates that the cooker is still under pressure. Do not force it open. Any pressure in the cooker can be dangerous. See "Releasing Pressure" section.
• Never use the pressure cooker without adding water, as this could severely damage the appliance.
• Use only original Magefesa spare parts.

3. Producte acabatview i Components

The Magefesa Qualix pressure cooker consists of several key components designed for safe and efficient operation.

• Cos de l'olla: The main container, made of 18/10 stainless steel.
• Tapa: Features the pressure regulation and safety mechanisms.
• Mànec principal: Ergonomic handle on the lid for opening and closing.
• Nansa auxiliar: Handle on the pot body for easier lifting and carrying.
• Pressure Regulator Valve: Controls the cooking pressure.
• Vàlvula de seguretat: Un mecanisme de seguretat addicional per alliberar l'excés de pressió.
• Indicador de pressió: Visually indicates when pressure is built inside.
• Gasket/Sealing Ring: Assegura un segellat hermètic entre la tapa i l'olla.
• Thermodiffuser Base: 5-layer encapsulated base for even heat distribution, suitable for all cooktops including induction.

4. Configuració i primer ús

4.1. Desembalatge i neteja inicial

1. Traieu tots els materials d'embalatge i les etiquetes de l'olla a pressió.
2. Wash the pot body, lid, and sealing ring with warm soapy water. Rinse thoroughly and dry completely.
3. Inspect the sealing ring and valves for any damage or obstructions. Ensure they are clean and properly seated.

4.2. Checking Capacity

The Magefesa Qualix pressure cooker has a 6-liter capacity, suitable for 5-6 servings. Always adhere to the maximum fill lines to ensure safe operation.

5. Instruccions de funcionament

5.1. Omplir l'olla

1. Add ingredients and liquid to the pot.
2. Do not fill the cooker more than 2/3 full with food and liquid. For foods that expand (e.g., rice, beans), do not fill more than 1/2 full.
3. Ensure there is always a minimum amount of liquid (e.g., 1 cup) as specified in your recipe or the cooker's guidelines to generate steam.

5.2. Tancament de la tapa

1. Place the lid on the pot, aligning the arrows or indicators on the lid and pot handles.
2. Engage the patented opening system to securely lock the lid. Ensure the lid is fully closed and sealed with minimal effort.
3. Verify that the pressure regulator valve is correctly positioned according to your desired pressure level (60 kPa or 100 kPa).

5.3. Cuinar sota pressió

1. Place the sealed pressure cooker on a suitable heat source (gas, electric, ceramic, or induction).
2. Set the heat to high. The pressure indicator will rise, and steam will begin to escape from the pressure regulator valve once the desired pressure is reached.
3. Reduce the heat to maintain a steady, gentle release of steam. Start timing your recipe from this point.
4. The Magefesa Qualix offers two working pressure levels: 60 kPa (low pressure) and 100 kPa (high pressure), allowing for versatile cooking.

5.4. Releuasing Pressure and Opening

Once cooking is complete, there are two primary methods for releasinpressió g:

• Alliberament natural: Remove the cooker from the heat source and allow it to cool down naturally. The pressure indicator will drop on its own. This method is ideal for foods that benefit from a longer cooking time or that might foam.
• Llançament ràpid: For faster pressure release, carefully move the pressure regulator valve to the steam release position (if available on your model) or place the cooker under cold running water (avoiding the lid mechanisms) until the pressure indicator drops. Use extreme caution to avoid steam burns.

Important: Never attempt to open the lid until the pressure indicator has fully dropped and no steam is escaping. Forcing the lid open while under pressure can cause severe injury.

6. Manteniment i Neteja

6.1. Neteja diària

1. After each use, allow the cooker to cool completely.
2. Wash the pot body and lid with warm soapy water. For stubborn food residues, soak the pot before cleaning.
3. Remove the sealing ring from the lid and wash it separately. Ensure it is clean and flexible.
4. Clean the pressure regulator valve and safety valve openings to ensure they are free from food particles. Use a small brush if necessary.
5. Rinse all parts thoroughly and dry completely before storage.

6.2. Inspecció periòdica

• Regularly inspect the sealing ring for cracks, hardening, or deformation. Replace it if any damage is observed, typically every 1-2 years depending on usage.
• Check the pressure valves for any blockages or wear. Ensure they move freely and are not corroded.
• Ensure the handles are securely fastened.

Nota: While the stainless steel pot body may be dishwasher safe, hand washing is recommended for the lid and sealing ring to prolong their lifespan and maintain optimal performance.

7. Solució De Problemes

8. Especificacions

• Marca: MAGEFESA
• Model: Qualix
• Número de model: 01OPQUALX06
• Capacitat: 6 litres
• Material: 18/10 Stainless Steel (Pot Body), Metal (General)
• Color: Acer inoxidable
• Pes: 3.34 kg
• Compatibilitat amb fonts de calor: All cooktops, including Induction (Thermodiffuser Base)
• Working Pressure Levels: 60 kPa, 100 kPa
• Sistemes de seguretat: 5 (Pressure Sensor, Closure Safety, Opening Safety, Working Valve, Safety Valve, Safety Window)

9. Garantia i Suport

For warranty information, product support, or to purchase replacement parts, please refer to the documentation included with your purchase or contact Magefesa customer service directly. You can also visit the official Magefesa brand store for more information: Magefesa Brand Store.
