YAMAHA DGX660B 88-Key Weighted Digital Piano Instruction Manual

Introducció

The Yamaha DGX660B is an 88-key weighted digital piano designed to provide an authentic piano experience with extensive features for musical expression and learning. It combines Yamaha's renowned piano touch and tone with versatile functionalities, including vocal effects, a score display for learning, and various acoustic settings.

Què hi ha a la caixa

• Yamaha DGX660B Digital Piano Unit
• Furniture Stand
• Descans musical
• Pedal de peu
• PA150 Power Adapter

Configuració

Follow these steps to set up your Yamaha DGX660B digital piano:

1. Assemble the Furniture Stand: Carefully attach the digital piano unit to the included furniture stand. Ensure all screws are tightened securely to provide a stable playing surface.
2. Connecteu l'adaptador de corrent: Plug the PA150 Power Adapter into the DC IN jack on the rear of the piano and then into a standard electrical outlet.
3. Connect the Footswitch: Insert the included footswitch cable into the SUSTAIN PEDAL jack on the rear of the piano.
4. Attach the Music Rest: Slide the music rest into the designated slots on the top panel of the piano.
5. Auriculars (opcionals): For private practice, connect 3.5mm headphones to the HEADPHONES jack.
6. Connectivitat USB (opcional): For connecting to a computer or iOS device, use the appropriate USB cables with the USB TO HOST or USB TO DEVICE ports.

Image: Yamaha DGX660B Digital Piano with its furniture stand, showing dimensions of 55.06 inches width, 17.5 inches depth, and 5.75 inches height for the piano unit itself.

Instruccions de funcionament

This section details the primary functions and features of your DGX660B digital piano.

1. Funcionament bàsic

• Encès/apagat: Press the [POWER] button to turn the instrument on or off.
• Control de volum: Use the [MASTER VOLUME] knob to adjust the overall sound level.

2. Keyboard Action

The DGX660B features a Estàndard de martell graduat (GHS) weighted action. This replicates the feel of an acoustic piano, with a heavier touch in the low keys and a lighter touch in the high keys, providing a realistic playing experience.

3. Pure CF Sound Engine

The piano's core sound is generated by the Motor de so Pure CF, which faithfully reproduces the tone of a meticulously sampled Yamaha CFIIIS concert grand piano. This ensures rich, expressive, and authentic piano sounds.

4. Piano Room

The Piano Room feature allows you to customize your piano playing environment. You can select different piano types (e.g., Grand Piano, Pop Grand, Warm Grand, Honky Tonk) and acoustic settings (e.g., Concert Hall, Recital Hall, Stage, Room). You can also adjust the piano's lid position (Full, Half, Closed) and the keyboard's touch sensitivity to match your preference.

5. Instrument Voices

Beyond the grand piano, the DGX660B offers 554 realistic instrument voices, including electric pianos, organs, strings, choirs, saxophones, trumpets, guitars, basses, flutes, synth leads, synth pads, percussion, and drum kits. These can be selected and layered to create diverse musical textures.

6. Backing Styles

Explore over 200 built-in backing styles across various genres like R&B, Waltz, Children, Country, Latin, Disco, Swing & Jazz, and Traditional. The Style Recommender feature can suggest appropriate accompaniments based on your playing. These styles provide a virtual band to play along with.

7. Entrada de micròfon

The instrument includes a microphone input with high-quality vocal effects, allowing you to sing along with your performance or practice vocals with accompaniment.

8. Funcions d'enregistrament

• Six-Track Recorder: Capture your performances and song ideas by recording up to six tracks. This allows for multi-layered musical arrangements.
• Gravadora d'àudio: Record your entire performance, including vocals, directly to a USB memory device in high-quality audio format. This is ideal for sharing your music or transferring it to a computer for further editing.
• Emmagatzematge USB: Utilize the USB TO DEVICE port to store recorded MIDI or audio files en una unitat flaix.

9. Opcions de connectivitat

• USB A HOST: Connect the piano to a computer for MIDI data transfer, allowing use with DAWs and music software.
• Compatibilitat amb dispositius iOS: Connect to iOS devices to use a range of exciting apps, including Note Star (digital sheet music with backing tracks) and Chord Tracker (identifies chords in audio files). An optional UD-WL01 Wireless Adaptor is available for wireless connection.

10. Monitor Speakers

The DGX660B features built-in monitor speakers for clear sound reproduction. It can also be connected to an external sound system for larger venues or enhanced audio output. The internal speakers can be set to 'Always On' even when an external output is connected, which is useful for monitoring.

Manteniment

Proper maintenance ensures the longevity and optimal performance of your digital piano.

• Neteja: Use a soft, dry cloth to wipe the surface of the instrument. For stubborn dirt, slightly dampen the cloth with water and a mild detergent, then wipe dry immediately. Avoid abrasive cleaners, solvents, or polishes.
• Atenció clau: Keep the keys clean. Wipe them gently with a soft cloth. Do not use chemical cleaners on the keys.
• Emmagatzematge: Store the instrument in a location free from extreme temperatures, direct sunlight, excessive dust, or high humidity.
• Apagar: Always turn off the power when the instrument is not in use to prevent unnecessary wear and tear.

Resolució de problemes

If you encounter any issues with your DGX660B, refer to the following common troubleshooting tips:

• Sense energia: Ensure the power adapter is securely connected to both the instrument and the electrical outlet. Verify the outlet is functioning.
• Sense so: Check the [MASTER VOLUME] knob and ensure it is not set to minimum. If headphones are connected, disconnect them to check speaker output. Verify that the correct voice is selected and not set to a silent option.
• So distorsionat: Reduce the volume. Check for loose connections in cables.
• Les tecles no responen: Ensure the instrument is powered on. If specific keys are unresponsive, contact customer support.
• Dispositiu USB no reconegut: Ensure the USB device is properly inserted and formatted correctly (FAT32 is commonly supported).

For persistent issues, consult the full owner's manual or contact Yamaha customer support.

Especificacions

Garantia i suport

For detailed warranty information, please refer to the warranty card included with your product or visit the official Yamaha website. For technical support, product registration, or service inquiries, please contact Yamaha customer service through their official channels.
