Gree LIVO+ 24,000 BTU 16 SEER Ductless Mini Split Air Conditioner Heat Pump User Manual

1. Informació important de seguretat

Please read all instructions carefully before installation and operation. Failure to follow these instructions may result in property damage, personal injury, or death. Keep this manual for future reference.

• Instal·lació professional necessària: Installation, maintenance, and repair of this unit must be performed by a qualified, licensed HVAC technician. Improper installation can void the warranty and create safety hazards.
• Seguretat elèctrica: This unit operates on 208/230V. Ensure proper grounding and electrical connections are made by a qualified electrician to prevent electric shock. Disconnect power before servicing.
• Refrigerant: This system uses R410A refrigerant. Handling of refrigerant must be done by certified personnel only.
• Liquidacions: Mantingueu una distància adequada al voltant de les unitats interiors i exteriors per a un flux d'aire i un accés adequats al servei.
• Nens i animals de companyia: Mantingueu els nens i les mascotes allunyats de la unitat durant el funcionament i el manteniment.

2. Producte acabatview

The Gree LIVO+ Ductless Mini Split Air Conditioner Heat Pump system provides efficient heating and cooling for single zones. It consists of an indoor wall-mounted air handler, an outdoor condenser unit, and a wireless remote control. The system utilizes Gree's G10 Inverter and variable compressor technology with R410A refrigerant for optimal performance.

Figura 2.1: Acabatview of the Gree LIVO+ Mini Split system, showing the indoor unit, outdoor condenser, and the wireless remote control.

Figura 2.2: The indoor wall-mounted air handler unit, designed for quiet and efficient air distribution.

Figura 2.3: The outdoor condenser unit, featuring a large fan for heat exchange and the Gree logo.

3. Configuració i instal·lació

Installation of the Gree LIVO+ Mini Split system requires specialized tools and knowledge. To ensure proper function, safety, and warranty validity, installation must be performed by a state-licensed HVAC contractor.

3.1 Components Required (Not Included)

• Lineset: Refrigerant lines connecting the indoor and outdoor units are required and must be sized appropriately for the unit's capacity and installation distance.
• Cablejat elèctric: Appropriate gauge wiring and a dedicated circuit breaker are necessary for the 208/230V power supply.
• Desguàs de condensats: Tubing for draining condensate from the indoor unit.
• Wi-Fi Kit (Optional): For smartphone control, the Universal Wi-Fi Technology Kit (WSBEC02) must be purchased separately and installed by a qualified technician.

3.2 Finalització de la instal·lacióview

El procés d'instal·lació normalment implica:

1. Mounting the indoor unit on an interior wall.
2. Muntatge de la unitat exterior sobre una superfície estable i plana.
3. Connecting the refrigerant lines between the indoor and outdoor units.
4. Making electrical connections to both units.
5. Evacuating the refrigerant lines and charging the system.
6. Connecting the condensate drain.
7. Testing the system for proper operation.

Figura 3.1: Example of a Gree LIVO+ indoor unit properly installed on a wall in a residential living space.

4. Instruccions de funcionament

The Gree LIVO+ system is controlled primarily via the wireless remote control. Ensure the remote has fresh batteries and is pointed towards the indoor unit during operation.

4.1 Funcions de control remot

Figura 4.1: The wireless remote control for the Gree LIVO+ system, showing its display and various function buttons.

• Botó ON/OFF: Encén o apaga la unitat.
• Botó MODE: Canvia pels modes de funcionament: Automàtic, Refrigeració, Deshidratació, Calor i Ventilador.
• Botó FAN: Ajusta la velocitat del ventilador (Automàtic, Baixa, Mitjana, Alta).
• Botons TEMP ▲/▼: Augmenta o disminueix el valor de temperatura desitjat.
• Botó SWING: Controls the vertical louver movement for air direction.
• Botó SLEEP: Activates sleep mode for reduced noise and energy consumption during sleep.
• Botó TIMER: Sets the unit to turn on or off automatically after a set period.
• Botó LLUM: Turns the display light on the indoor unit on or off.

4.2 Funcionament bàsic

1. Premeu el botó ON/OFF per iniciar la unitat.
2. Premeu el botó MODE button to select your desired operating mode (e.g., Cool for cooling, Heat for heating).
3. Utilitza el TEMP ▲/▼ buttons to set the desired room temperature.
4. Ajusteu la velocitat del ventilador amb el FAN botó si cal.

4.3 Wi-Fi Control (with optional WSBEC02 kit)

If the optional Wi-Fi kit (WSBEC02) is installed, you can control your Gree LIVO+ unit from your smartphone or tablet via a dedicated app. Refer to the Wi-Fi kit's instructions for pairing and app usage. This allows for remote control and scheduling from anywhere with internet access.

5. Manteniment

Regular maintenance ensures optimal performance and longevity of your Gree LIVO+ system. Always turn off the power to the unit before performing any maintenance.

5.1 Indoor Unit Filter Cleaning

The air filters in the indoor unit should be cleaned every 2-4 weeks, or more frequently depending on usage and air quality.

1. Obriu el panell frontal de la unitat interior.
2. Traieu els filtres d'aire.
3. Clean the filters using a vacuum cleaner or by washing them with lukewarm water and a mild detergent.
4. Deixeu que els filtres s'assequin completament abans de tornar-los a instal·lar.
5. Tanqueu el panell frontal.

5.2 Manteniment de la unitat exterior

The outdoor unit should be inspected periodically for debris accumulation on the coil and fan blades. Clean the coil gently with a soft brush or water hose. Ensure the area around the outdoor unit is clear of obstructions.

5.3 Manteniment professional

It is recommended to have a licensed HVAC technician perform professional maintenance annually. This includes checking refrigerant levels, electrical connections, drain lines, and overall system performance.

6. Solució De Problemes

Abans de contactar amb el servei tècnic, torneu aview els següents problemes i solucions habituals.

For issues not listed or if troubleshooting steps do not resolve the problem, contact a licensed HVAC professional for assistance.

7. Especificacions

Key technical specifications for the Gree LIVO+ 24,000 BTU Mini Split Heat Pump (Model: LIVS24HP230V1B).

Figura 7.1: U.S. Government EnergyGuide label for the Gree LIVS24HP230V1B, indicating a Cooling Efficiency Rating (SEER) of 16.0 and a Heating Efficiency Rating (HSPF) of 9.0.

Figura 7.2: Visual representation of key features including 5-year parts warranty, optional WiFi, heating and cooling functionality, AHRI and ETL certifications, and G10 Inverter Technology.

8. Garantia i Suport

8.1 Garantia del fabricant

The Gree LIVO+ system comes with a manufacturer's warranty:

• Parts: 5 anys de garantia limitada
• Compressor: 7 anys de garantia limitada

Important: To be eligible for this warranty, installation must be performed by a state-licensed HVAC contractor. Proof of professional installation may be required for warranty claims.

8.2 Atenció al client

For technical support, warranty claims, or service inquiries, please contact your installing HVAC contractor or the retailer from whom you purchased the unit. For general product information, you may visit the official GREE weblloc.

This product was supplied by Furnace Factory Outlet. For purchase-related inquiries, please contact them directly.
