1. Instruccions de seguretat importants
Please read all instructions carefully before installation and use to ensure safe operation and prevent damage. Keep this manual for future reference.
- La instal·lació ha de ser realitzada per un professional qualificat d'acord amb les normes locals de fontaneria i construcció.
- Assegureu-vos que el subministrament d'aigua estigui tallat abans de començar qualsevol instal·lació o manteniment.
- Verify all connections are secure and watertight to prevent leaks.
- Do not use abrasive cleaners or harsh chemicals on the chrome finish, as this may cause damage.
- Maintain operating pressure within the specified range (min. 1.5 bar / max. 6 bar).
2. Producte acabatview
The Hansgrohe Axor 3-Jet Wall-Mounted Shower Head (Model 35283000) is a premium shower solution designed for a luxurious showering experience. It features three distinct spray patterns and a durable chrome-plated finish.
Figure 2.1: Hansgrohe Axor 3-Jet Shower Head in an installed setting, showcasing its sleek design and water flow.
Característiques principals:
- 3 patrons de polvorització: Rain, RainFlow, and Mono for varied showering experiences.
- Instal·lació a la paret: Designed for secure and stable wall mounting, compatible with iBox universal basic set.
- Chrome-Plated Finish: Fully chrome-plated metal spray face for durability and aesthetic appeal.
- Tecnologia QuickClean: For easy removal of limescale deposits from the spray disc.
- Adjustable Flow Rates: Optimized flow rates for each spray pattern.
3. Configuració i instal·lació
This shower head is designed for wall-mounted installation and requires an iBox universal basic set (not included) for proper integration into your plumbing system. Professional installation is recommended.
3.1 Tools and Materials Required (Not Supplied):
- Clau ajustable
- Joc de tornavís
- Cinta segelladora (cinta de PTFE)
- Perforar (si calen nous forats de muntatge)
- Nivell
- Cinta mètrica
3.2 Passos d'instal·lació:
- Prepareu l'àrea d'instal·lació: Ensure the water supply to the shower area is completely shut off. Clear the wall area where the shower head will be mounted.
- Install iBox Universal Basic Set: If not already installed, follow the manufacturer's instructions for installing the iBox universal basic set into the wall. This unit provides the necessary connections for the shower head.
- Mount the Shower Head: Attach the shower head unit to the iBox basic set according to the specific instructions provided with the iBox. Ensure all seals are correctly seated and connections are tightened securely to prevent leaks.
- Fixar a la paret: Use appropriate fasteners to secure the shower head mounting plate to the wall, ensuring it is level and stable.
- Prova de connexions: Slowly turn on the water supply and check for any leaks around the connections. If leaks are detected, turn off the water, re-tighten connections, and re-test.
Figure 3.1: Technical drawing illustrating the dimensions and wall mounting details for the shower head. All measurements are in millimeters.
Figure 3.2: Additional technical drawing providing further dimensional details for installation planning. All measurements are in millimeters.
4. Instruccions de funcionament
The Hansgrohe Axor 3-Jet Shower Head offers three distinct spray patterns, which can be selected via the integrated control mechanism (typically part of the iBox or external shower mixer).
4.1 patrons de polvorització:
- Pluja: A full, soft shower rain, ideal for daily showering. Flow rate: 17 l/min at 3 bar.
- RainFlow: A powerful, invigorating cascade, perfect for rinsing or a stimulating shower. Flow rate: 17 l/min at 3 bar (referred to as 'flood jet' in product description).
- Mono: A concentrated, single jet, suitable for targeted rinsing or massage. Flow rate: 20 l/min at 3 bar.
To switch between spray patterns, operate the diverter or selector on your shower mixer or iBox control unit. Refer to your mixer's manual for specific instructions on spray pattern selection.
5. Manteniment
Una neteja i un manteniment regulars garantiran la longevitat i el rendiment òptim del teu capçal de dutxa Hansgrohe.
5.1 Cleaning the Shower Head:
- Neteja diària: Wipe the shower head with a soft, damp drap després de cada ús per evitar taques d'aigua i acumulació de restes de sabó.
- Neteja profunda: For more thorough cleaning, use a mild soap solution or a non-abrasive cleaner specifically designed for chrome finishes. Apply with a soft cloth, then rinse thoroughly with clean water and dry.
- Evitar: Do not use abrasive sponges, brushes, or cleaners containing alcohol, ammonia, or phosphoric acid, as these can damage the chrome finish.
5.2 Limescale Removal (QuickClean Technology):
The Hansgrohe Axor shower head features QuickClean technology, allowing for easy removal of limescale deposits from the flexible silicone nozzles.
- Simply rub your finger across the silicone nozzles on the spray face to dislodge any limescale buildup.
- For stubborn deposits, the metal spray disc is removable for more intensive cleaning. Consult a professional if you are unsure how to remove the spray disc.
6. Solució De Problemes
Si teniu problemes amb el capçal de la dutxa, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| Reducció del cabal d'aigua | Limescale buildup in nozzles; low water pressure; clogged filter. | Clean nozzles using QuickClean. Check household water pressure. Inspect and clean any inline filters. |
| Water dripping after shut-off | Residual water draining from the shower head. | This is normal for overhead showers as water drains from the large spray surface. If dripping persists for an extended period, check for leaks in the mixer or connections. |
| Fuites a les connexions | Connexions soltes; segells danyats. | Turn off water supply. Tighten connections. Inspect and replace any damaged O-rings or seals. |
| Spray patterns not changing | Issue with the diverter/selector on the shower mixer. | Refer to the manual for your shower mixer/iBox control unit. Contact a plumber if the issue persists. |
If the problem persists after attempting these solutions, please contact a qualified plumber or Hansgrohe customer support.
7. Especificacions
| Atribut | Detall |
|---|---|
| Marca | hansgrohe |
| Número de model | 35283000 |
| Estil | Modern |
| Forma | Round (Spray face appears rectangular in diagrams, but product description implies round elements or overall design language) |
| Material | Metall cromat |
| Tipus d'acabat | Polit |
| Tipus d'instal·lació | Wall Mounted (for installation on iBox) |
| Color | Chrome |
| Nombre de paràmetres de polvorització | 3 (Rain, RainFlow, Mono) |
| Flow Rate (Rain) | 17 l/min a 3 bar |
| Flow Rate (RainFlow/Flood Jet) | 17 l/min a 3 bar |
| Flow Rate (Mono) | 20 l/min a 3 bar |
| Pressió de funcionament | Mín. 1.5 bar / Màx. 6 bar |
| Pes de l'article | 27.4 lliures (aprox. 12.4 kg) |
8. Garantia i Suport
Hansgrohe products are manufactured to high-quality standards and come with a manufacturer's warranty. For specific warranty terms and conditions, please refer to the documentation included with your purchase or visit the official Hansgrohe weblloc.
For technical support, spare parts, or service inquiries, please contact Hansgrohe customer service directly. You can find contact information on the official Hansgrohe weblloc web o a través del vostre distribuïdor local.
També podeu visitar el Hansgrohe Store on Amazon per obtenir més informació sobre el producte i recursos d'assistència.
