Tamiya Mercedes Benz 1850L RC Model Instruction Manual

Introducció

Gràcies per la compraasing the Tamiya Mercedes Benz 1850L 1:14 scale remote-controlled truck kit. This manual provides essential information for the assembly, operation, and maintenance of your RC model. Please read this manual thoroughly before beginning assembly or operation to ensure safe and correct use.

This model is a highly detailed replica designed for enthusiasts and requires careful assembly. It does not include a battery, transmitter, receiver, or servo, which must be purchased separately.

Informació de seguretat

Always operate your RC model in a safe and responsible manner. Failure to follow these safety guidelines may result in injury or damage to property.

• Keep hands, face, and loose clothing away from moving parts.
• Do not operate the model in public streets, near people, or in crowded areas.
• Ensure batteries are charged correctly and installed with correct polarity.
• Always turn off the model and transmitter when not in use.
• Store the model and components in a dry, safe place away from direct sunlight and extreme temperatures.
• This product is recommended for ages 14 years and older, and adult supervision is advised during assembly and operation.

Contingut del paquet

The Tamiya Mercedes Benz 1850L RC model kit includes:

• 1:14 scale Mercedes Benz 1850L truck kit components
• Instruccions de muntatge detallades

Nota: Els elements següents són no inclòs and must be purchased separately for operation:

• RC Transmitter (Radio)
• Receptor RC
• Servo de direcció
• Bateria de la unitat
• Carregador de bateria
• Paints and adhesives (for finishing the body)
• Eines per al muntatge

Muntatge i muntatge

This Tamiya RC model is a kit that requires complete assembly. Follow the included detailed assembly instructions carefully. It is recommended to organize all parts before starting and to use appropriate tools.

El muntatge s'acabaview:

1. Desembaleu tots els components i verifiqueu-los amb la llista de peces.
2. Assemble the chassis frame and suspension components.
3. Install the motor and gearbox.
4. Mount the steering servo and link it to the steering mechanism.
5. Assemble and paint the truck cab and body parts according to your desired finish.
6. Install the electronic speed controller (ESC), receiver, and battery tray.
7. Connect all wiring as per the wiring diagram.
8. Perform initial function checks before final body mounting.

For detailed step-by-step instructions, refer to the separate assembly manual provided in the kit.

Instruccions de funcionament

Once assembled and equipped with the necessary electronics (transmitter, receiver, servo, battery), your Tamiya Mercedes Benz 1850L RC truck is ready for operation.

Llista de comprovació prèvia a l'operació:

• Ensure the drive battery is fully charged.
• Comproveu que tots els cargols i les connexions estiguin ben ajustats.
• Verify that the steering and throttle respond correctly to transmitter inputs.
• Confirm that the transmitter and receiver are properly bound and on the correct frequency.

Starting the Model:

1. Turn on your RC transmitter first.
2. Connect the battery to the model's electronic speed controller (ESC).
3. Place the model on a flat surface and ensure no obstacles are nearby.
4. Gently apply throttle and steering inputs to control the truck.

Stopping the Model:

1. Bring the model to a complete stop.
2. Disconnect the battery from the model.
3. Turn off your RC transmitter.

Manteniment

Regular maintenance will extend the life and performance of your Tamiya RC truck.

• Neteja: After each use, especially if operated outdoors, clean the model to remove dirt, dust, and debris. Use a soft brush or compressed air.
• Inspecció: Periodically inspect all screws, nuts, and bolts for tightness. Check for any damaged or worn parts.
• Lubricació: Apply appropriate lubricants to moving parts like gears and bearings as recommended in the assembly manual.
• Cura de la bateria: Follow the manufacturer's instructions for charging and storing your drive battery. Never overcharge or completely discharge batteries.
• Emmagatzematge: Guardeu el model en un lloc fresc i sec, allunyat de la llum solar directa.

Resolució de problemes

If you encounter issues with your RC truck, refer to the following common problems and solutions:

If the problem persists, consult the detailed troubleshooting section in your assembly manual or contact Tamiya customer support.

Especificacions

Garantia i Suport

For warranty information and technical support, please refer to the documentation included with your product or visit the official Tamiya weblloc web. Conserveu el comprovant de compra per a qualsevol reclamació de garantia.

Tamiya Official Weblloc: www.tamiya.com
