Dremel PC10-01 Versa Cleaning Tool Instruction Manual

Model: PC10-01

Producte acabatview

The Dremel Versa PC10-01 is a powerful and versatile cleaning tool designed to simplify tough cleaning jobs. Its high-speed scrubbing action is ideal for tackling soap scum, baked-on food, difficult grease, dirt, and more. Featuring a compact and ergonomic design, it's comfortable for single-hand use and effective in hard-to-reach places. The tool is powered by a lithium-ion battery, making it suitable for both indoor and outdoor, wet and dry applications.

Característiques clau

Dremel Versa PC10-01 Cleaning Tool with various accessories including brushes, pads, and charger.
The Dremel Versa PC10-01 Cleaning Tool, shown with its included accessories: a bristle brush, heavy-duty pad, non-scratch pad, eraser pad, backing pad, splash guard, and charger.

Muntatge i muntatge

Càrrega de l'eina

The Dremel Versa PC10-01 is powered by a 4VMax Lithium-Ion battery. Before first use, fully charge the tool using the provided charger. The charging port is typically located on the handle. A full charge ensures optimal performance and run time.

Accessoris de fixació

The Dremel Versa utilizes a hook and loop interface for quick and easy accessory changes. To attach a cleaning pad or brush, simply align it with the backing pad on the tool and press firmly until it adheres securely. To remove, peel it off. Ensure the accessory is centered for balanced rotation.

Dremel Versa PC10-01 with a blue cleaning pad attached.
The Dremel Versa PC10-01 with a blue cleaning pad securely attached, ready for use.

Instruccions de funcionament

Consells generals d'ús

For best results and to prevent the tool from stopping due to excessive friction, always ensure the cleaning pad or brush is adequately wet, especially when using abrasive pads. Apply light pressure and allow the high-speed scrubbing action of the Dremel Versa to do the work. Using appropriate cleaning solutions with water can enhance cleaning effectiveness and reduce strain on the tool.

Aplicacions recomanades

The Dremel Versa is designed for a variety of cleaning tasks. Here are some common applications:

Vídeos oficials de productes

Versa Oven Cleaning

This video demonstrates the Dremel Versa's effectiveness in cleaning tough, baked-on grime from oven surfaces.

Versa Pot Cleaning

Watch how the Dremel Versa makes quick work of cleaning pots and pans, restoring their shine.

Versa Stovetop Cleaning

This video illustrates the Dremel Versa's efficiency in cleaning stovetops, removing spills and stains with ease.

Cura i Manteniment

Cleaning the Tool and Accessories

After each use, it is important to clean your Dremel Versa tool and its accessories to maintain performance and longevity. The Dremel Versa is designed to be waterproof, allowing for easy rinsing under a faucet. Remove and rinse cleaning pads and brushes thoroughly to remove any residue. Allow all components to air dry completely before storage. Store the tool and accessories in a clean, dry place, away from direct sunlight or extreme temperatures.

Resolució de problemes

Problemes comuns

Especificacions del producte

EspecificacióDetall
MarcaDremel
Número de modelPC10-01
Pes de l'article1.6 lliures
Dimensions del producte10 cm de llargada x 3.5 cm d'amplada x 10.25 cm d'alçada
Font d'alimentacióFunciona amb bateria
Voltage4 Volts
Tipus de bateriaIó de liti (inclòs)
Velocitat2.2E+3 RPM
Característica especialImpermeable
Recomanació de superfícieGlass, Tile, Grout
Components inclosos(1) PC361 Power Cleaner Heavy-Duty Pad, 4VMax Dremel Power Cleaner Tool, (1) PC363 Power Cleaner Non-Scratch Pad, Backing Pad, (1) PC364 Power Cleaner Bristle Brush, Splash Guard, Charger, (1) PC362 Power Cleaner Eraser Pad
Dremel Versa PC10-01 with dimensions labeled: 10.25 inches high, 3.5 inches wide, 10 inches long.
Dimensions of the Dremel Versa PC10-01 Cleaning Tool.

Garantia i Suport

Informació de la garantia

The Dremel PC10-01 Versa Cleaning Tool comes with a limited 2-year warranty. Please retain your proof of purchase for warranty claims.

Guia d'usuari i suport

For detailed instructions, safety information, and further assistance, please refer to the official Guia de l'usuari (PDF). You can also contact Dremel's USA-based customer service team for support via chat, email, or phone, or visit their facility in Racine, WI.
