Introducció
Thank you for choosing the Teka Classic 1C 1E 50 cm Sink. This high-quality 18/10 stainless steel sink features a single bucket and drainer, designed for built-in and reversible installation. Its soundproofing properties reduce noise and vibration, ensuring a comfortable user experience. The 190 mm deep bucket accommodates large kitchen items, making it ideal for various culinary tasks. This manual provides essential information for the proper installation, operation, and maintenance of your new sink.
Descripció de la imatge: Un de dalt a baix view of the Teka Classic 1C 1E sink, illustrating its built-in design and soundproofing capabilities. Text on the image indicates 'Fregadero encastrado' (Built-in sink) and 'Insonorización' (Soundproofing).
Descripció de la imatge: Un de dalt a baix view of the Teka Classic 1C 1E sink, emphasizing its depth and stainless steel construction. Text on the image indicates 'Profundidad' (Depth) and 'Acero inoxidable' (Stainless Steel).
Informació de seguretat
- Always ensure the water supply is turned off before beginning any installation or maintenance.
- Utilitzeu l'equip de protecció individual (EPI) adequat, com ara guants i ulleres de protecció durant la instal·lació.
- Handle the sink with care to avoid scratches or damage to the stainless steel finish.
- Assegureu-vos que totes les connexions siguin estanques per evitar fuites.
- Si no esteu segurs de cap pas, consulteu un professional qualificat.
Contingut del paquet
Verifiqueu que tots els components siguin presents abans de començar la instal·lació.
- Teka Classic 1C 1E 50 cm Sink
- Valve basket 3 ½"
- Installation clips/staples
- Soundproofing material (pre-applied)
Configuració i instal·lació
The Teka Classic 1C 1E sink is designed for built-in (recessed) installation and is reversible, allowing for flexible placement of the drainer.
1. Prepare the Countertop
Ensure your countertop has a cutout that matches the sink's dimensions. The sink is designed for a 50 cm furniture base. Refer to the dimension diagram for precise measurements.
Descripció de la imatge: A technical drawing showing the top-down dimensions of the Teka Classic 1C 1E sink. Key measurements include overall length (860mm), width (500mm), bowl dimensions (406mm x 406mm), and drainer dimensions. It also indicates a 35mm diameter hole for the faucet.
2. Col·loqueu la pica
Place the sink into the prepared cutout. The sink is reversible, allowing you to choose whether the drainer is on the left or right side.
Descripció de la imatge: Un angle view of the Teka Classic 1C 1E stainless steel sink, showing the single bowl and integrated drainer. The sink is shown installed flush with a light-colored countertop, highlighting its built-in design.
3. Secure the Sink
Use the provided installation clips or staples to secure the sink firmly to the underside of the countertop. Ensure an even seal around the perimeter to prevent water ingress.
4. Install Faucet and Drain Assembly
- Install your chosen faucet into the pre-drilled tap hole (35mm diameter).
- Assemble the 3 ½" valve basket and connect it to your plumbing system. Ensure all connections are tight and sealed to prevent leaks.
Descripció de la imatge: Un de dalt a baix view of the Teka Classic 1C 1E sink with a modern chrome faucet installed in the designated tap hole. The image shows the sink's clean lines and the integration of the faucet.
Instruccions de funcionament
The Teka Classic 1C 1E sink is designed for everyday kitchen use.
- Flux d'aigua: Use the installed faucet to control water flow and temperature.
- Drenatge: The 3 ½" valve basket effectively collects debris and allows for efficient water drainage. Ensure it is clear of large food particles to prevent blockages.
- Soundproofing: The integrated soundproofing material reduces noise during use, providing a quieter kitchen environment.
Manteniment i cura
Proper care will ensure the longevity and appearance of your stainless steel sink.
- Neteja diària: Netegeu la pica amb un drap sec després de cada ús per evitar taques d'aigua i acumulació de minerals.
- Neteja regular: For a deeper clean, use a mild soap or a specialized stainless steel cleaner with a soft cloth or sponge. Always rub in the direction of the grain.
- Eviteu els abrasius: Do not use abrasive cleaners, steel wool, or harsh chemicals (e.g., bleach, strong acids) as these can scratch or damage the stainless steel finish.
- Prevenir les taques: Avoid leaving acidic foods (e.g., citrus, tomatoes) or corrosive substances in the sink for extended periods. Rinse thoroughly after contact.
- Manteniment del desguàs: Periodically remove and clean the valve basket to prevent clogs and odors.
Resolució de problemes
Aquesta secció tracta els problemes habituals que podeu trobar amb la vostra pica.
- Drenatge lent:
Causa: Blockage in the drain or valve basket.Solució: Remove the valve basket and clean any accumulated food particles or debris. If the issue persists, a plumbing snake or drain cleaner may be required for the P-trap.
- Taques/taques d'aigua:
Causa: Dipòsits d'aigua dura o assecat inadequat.Solució: Wipe the sink dry after each use. For existing spots, use a mixture of vinegar and water, or a specialized stainless steel cleaner, and buff with a soft cloth.
- Esgarrapades a la superfície:
Causa: Abrasive materials or harsh scrubbing.Solució: Stainless steel can scratch. Minor scratches can sometimes be blended with a fine abrasive pad (like Scotch-Brite) rubbed in the direction of the grain, but this should be done with caution. Prevent future scratches by avoiding abrasive cleaners and sharp objects.
- Leaks Around Sink Edge:
Causa: Improper sealing during installation or loose clips.Solució: Check the installation clips and tighten if necessary. Reapply silicone sealant around the sink's perimeter if the seal is compromised.
Especificacions
| Característica | Detall |
|---|---|
| Marca | Teka |
| Número de model | TEK-10119013 |
| Material | Acer inoxidable 18/10 |
| Color | Plata |
| Tipus d'instal·lació | Built-in (Recessed) |
| Tipus de pica | Single Bowl with Drainer, Reversible |
| Dimensions totals (L x P x A) | 86 cm x 50 cm x 19 cm (approx. 33.86"W x 19.69"D x 7.48"H) |
| Profunditat del bol | 190 mm |
| Tipus de drenatge | Grid (3 ½" Valve Basket) |
| Tap Hole Count | 1 (Ø35mm) |
| Amplada mínima de l'armari base | 50 cm |
| Pes de l'article | 4.06 kg (8.93 lliures) |
| Insonorització | Sí |
Garantia i Suport
Teka products are manufactured to high-quality standards. For specific warranty details, please refer to the warranty card included with your purchase or visit the official Teka weblloc.
If you require technical assistance, have questions about installation, or need to report a defect, please contact Teka customer support through their official channels.
- Teka Official Weblloc: www.teka.com
- Atenció al client: Refer to your regional Teka weblloc per obtenir informació de contacte local.
