CLATINA Swivel Executive Computer Chair User Manual

1. Introducció

Thank you for choosing the CLATINA Swivel Executive Computer Chair. This manual provides detailed instructions for assembly, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your chair. Please read this manual thoroughly before assembly and use.

This ergonomic office chair is designed for comfort and support during long hours of work, featuring adjustable components to suit individual needs.

Per obtenir més ajuda i recursos, visiteu el CLATINA Store.

2. Components mésview

Before beginning assembly, ensure all parts are present and undamaged. Refer to the diagram below for component identification.

Figura 2.1: Explotat view of CLATINA Swivel Executive Computer Chair components.

This image shows the individual parts of the chair, including the seat cushion, backrest, chair pole, chair legs, PA universal wheels, and tool kit, laid out for assembly.

• Coixí del seient: The main seating area with integrated armrests.
• Respaldo: The back support component.
• Chair Pole: The central gas lift mechanism.
• Chair Legs: The five-star base with wheel inserts.
• PA Universal Wheels: Casters for mobility (5 pieces).
• Kit d'eines: Includes necessary tools and fasteners for assembly.

3. Muntatge i muntatge

Assembly of the CLATINA Executive Chair is designed to be straightforward. Follow these steps carefully:

1. Attach Wheels to Chair Legs:

   Insert each of the five PA Universal Wheels into the designated holes at the end of each chair leg. Push firmly until they click into place.



   Figure 3.1: A hand inserting a wheel into the chair's five-star base.

   This image demonstrates the process of attaching the casters to the chair's leg base.

2. Insert Chair Pole:

   Place the assembled chair legs on a flat surface. Insert the wider end of the Chair Pole into the central hole of the chair legs. Ensure it is seated firmly.
3. Attach Seat Cushion to Chair Pole:

   Carefully align the central hole on the underside of the Seat Cushion with the top (narrower) end of the Chair Pole. Lower the seat onto the pole, applying gentle pressure until it is securely in place.



   Figure 3.2: The seat cushion being lowered onto the chair pole.

   This image illustrates the connection of the seat assembly to the gas lift and wheeled base.
4. Attach Backrest to Seat Cushion:

   Align the backrest with the mounting points on the rear of the seat cushion. Use the provided screws and hex key from the Tool Kit to secure the backrest firmly. Ensure all screws are tightened evenly.



   Figure 3.3: A close-up of the backrest attachment point, showing screws being tightened.

   This image details the final step of attaching the backrest to the seat using the provided hardware.

For a visual guide, please refer to the official assembly video:

4. Instruccions de funcionament

The CLATINA Executive Chair offers multiple adjustment features to customize your seating experience for optimal comfort and ergonomic support.

• Ajust de l'alçada del seient:

  To raise the seat, lift the lever located on the right side of the seat while taking your weight off the chair. To lower the seat, lift the lever while seated.
• Ajust de profunditat del seient:

  Pull the lever on the left side of the seat to slide the seat cushion forward or backward, adjusting the depth to fit your leg length. Release the lever to lock the position.



  Figure 4.1: Diagram illustrating seat depth adjustment and seat/back synchronization.

  This image highlights the ergonomic design that allows the seat and back to synchronize movements, dispersing pressure and fitting the hip curve.
• Ajust del recolzabraços:

  The 3D armrests can be adjusted in multiple ways:

  • Alçada: Press the button on the side of the armrest and slide it up or down (2.8" range).
  • Moviment horitzontal: Slide the armrest pad forward or backward (1.2" range).
  • Rotació: Rotate the armrest pad up to 40 degrees inward or outward.


  Figure 4.2: Visual guide to 3D adjustable armrests.

  This image demonstrates the various adjustments available for the armrests, including height, horizontal movement, and rotation, to adapt to different arm placement postures.

• Ajust del suport lumbar:

  The lumbar support can be adjusted vertically by 1.57" to provide tailored support for your lower back. Gently push or pull the lumbar support pad to your desired height.



  Figure 4.3: Illustration of adjustable lumbar support.

  This image demonstrates how to adjust the height of the lumbar support to adapt to different users and provide optimal spinal alignment.

• Backrest Tilt and Tension:

  The backrest reclines from 90 to 135 degrees with 4-level locking tilt. Use the tilt tension knob (located on the right side, under the seat) to adjust the resistance when reclining. Turn right to tighten (more resistance) and left to loosen (less resistance).



  Figure 4.4: Diagram showing reclining angles and tilt tension knob.

  This image illustrates the chair's deep reclining angle (95-135 degrees) and the 5-position tilt tension knob for customized comfort.

For a visual guide on chair functions, please refer to the official functions video:

5. Manteniment

Regular maintenance will help preserve the appearance and functionality of your CLATINA chair.

• Neteja: Netegeu amb un anunciamp cloth. Avoid harsh chemicals or abrasive cleaners that may damage the fabric or frame.
• Rodes: Periodically check the wheels for any accumulated debris (hair, dust, etc.) and clean them to ensure smooth rolling.
• Elements de fixació: Occasionally check all screws and bolts to ensure they are tight. Re-tighten if necessary to maintain stability.

6. Solució De Problemes

If you encounter any issues with your CLATINA chair, refer to the following common problems and solutions:

For more complex issues or if troubleshooting steps do not resolve the problem, please contact CLATINA customer support.

7. Especificacions

• Marca: CLATINA
• Nom del model: MELLET (Item model number: 247)
• Color: Black-fabric
• Dimensions del producte: 27.8 "P x 27.8" W x 43.3" H
• Pes de l'article: 47.3 lliures
• Pes màxim recomanat: 275 lliures
• Material: High elastic molded urethane foam (seat), Fabric (backrest)
• Característica especial: Adjustable (3D armrest, lumbar support, seat height/depth, tilt tension)
• Factor de forma: 360, Ergonomic, Tilt
• Certificacions: BIFMA/SGS certified Class 4 gas lift cylinder
• Components inclosos: Manual d'usuari, Roda giratòria

8. Garantia i Suport

CLATINA is committed to providing high-quality products and excellent customer service.

• Garantia: This product is backed by a manufacturer's warranty. Please refer to the warranty card included in your packaging for specific terms and conditions.
• Atenció al client: For any inquiries, assistance with assembly, or troubleshooting not covered in this manual, please contact CLATINA Office Supply customer support.
• Devolucions: Aquest producte té dret a devolucions fàcils de 30 dies.
