HBN Countdown Timer Plug User Manual

1. Introducció

The HBN Countdown Timer Plug is designed to automate the power supply to your household appliances, helping to save energy and enhance home safety. This device allows you to set specific countdown durations after which connected appliances will automatically power off. It features a repeat function and manual override capabilities.

2. Informació de seguretat

Si us plau, llegiu i comprengui totes les instruccions de seguretat abans d'utilitzar aquest producte. Si no segueix aquestes instruccions, pot provocar descàrregues elèctriques, incendis o lesions greus.

• Només per a ús interior. No exposeu a la humitat ni a temperatures extremes.
• No supereu la càrrega màxima de 13 Amps (3120W at 240V).
• Assegureu-vos que el temporitzador estigui ben connectat a una presa de corrent amb connexió a terra.
• No desmunteu ni modifiqueu el dispositiu.
• Keep out of reach of children. This product includes child protection features, but supervision is always recommended.
• Unplug the timer from the wall outlet before cleaning.

Image: The HBN Countdown Timer Plug features child safety outlet covers, indicated by a hand pointing to the covered socket openings, with a baby crawling in the background.

3. Característiques del producte

• Countdown Timer Options: Select from 15 minutes, 30 minutes, 1 hour, 2 hours, 4 hours, or 6 hours.
• Funció de repetició: Automatically repeats the set countdown cycle daily.
• Encès/apagat manual: Override timer settings for immediate control.
• Protecció infantil: Integrated safety features to prevent accidental access to live parts.
• Ground Pins: Equipped with ground pins for safe operation.
• Estalvi d'energia: Helps reduce electricity consumption by automatically turning off devices.
• Seguretat domèstica: Can be used to randomly turn lights on/off to simulate occupancy.

Image: Two HBN Countdown Timer Plugs, white in color, with a black control panel featuring green buttons for 'REPEAT', 'TOGGLE', and 'ON/OFF', and LED indicators for various countdown durations (15min, 30min, 1Hour, 2Hour, 4Hour, 6Hour).

Image: Four icons illustrating key features: a battery for "Backup Battery", circular arrows for "Daily Repeat", a clock for "Countdown", and a hand pointing for "Auto & Manual" control.

4. Configuració

1. Desembalar: Carefully remove the HBN Countdown Timer Plug from its packaging.
2. Inspeccionar: Comproveu si el dispositiu està danyat. No l'utilitzeu si està malmès.
3. Connectar: Insert the timer plug firmly into a standard 240V, 50Hz wall outlet. Ensure the wall outlet is switched on if it has an individual switch.
4. Connecteu l'aparell: Plug the appliance you wish to control into the socket on the front of the timer plug.

Imatge: Vista de dalt a baix view of the HBN Countdown Timer Plug, highlighting its UK-style three-pin plug for insertion into a wall socket. The control panel with buttons and LED indicators is visible.

5. Instruccions de funcionament

The HBN Countdown Timer Plug features three main buttons: REPETIR, CANVIA, i ON/OFF.

5.1 Setting a Countdown Timer

1. Ensure the timer plug is powered on (the ON/OFF indicator should be lit).
2. Premeu el botó CANVIA button repeatedly to cycle through the available countdown durations: 15 minutes, 30 minutes, 1 hour, 2 hours, 4 hours, and 6 hours.
3. The LED indicator corresponding to the selected duration will illuminate.
4. Once a duration is selected, the countdown begins, and the connected appliance will remain on for that period before automatically switching off.

5.2 Using the Repeat Function

1. First, set your desired countdown duration using the CANVIA botó tal com s'ha descrit anteriorment.
2. Premeu el botó REPETIR button. The REPEAT LED indicator will illuminate.
3. The timer will now automatically repeat the set countdown cycle daily. For example, if you set a 1-hour countdown with repeat at 8:00 AM, the appliance will turn on at 8:00 AM, turn off at 9:00 AM, and then repeat this cycle every day.
4. To deactivate the repeat function, press the REPETIR button again. The REPEAT LED indicator will turn off.

5.3 Manual On/Off Control

1. To manually turn the connected appliance on or off, press the ON/OFF botó.
2. Prement el ON/OFF button will override any active countdown or repeat settings.
3. The ON/OFF LED indicator will show the current power status.

Imatge: Un angle view of the HBN Countdown Timer Plug, clearly displaying the control panel with its 'REPEAT', 'TOGGLE', and 'ON/OFF' buttons, along with the LED indicators for various time settings.

Image: A collage demonstrating the HBN Countdown Timer Plug's versatility, showing it connected to a desk lamp, Christmas tree lights, a humidifier, an aquarium light, and a fan, illustrating its use for saving time and energy.

Image: The HBN Countdown Timer Plug in a home setting, with a Christmas tree in the background, illustrating its use for anti-theft by automatically turning lights on and off to simulate occupancy.

6. Manteniment

• Neteja: Disconnect the timer plug from the wall outlet before cleaning. Wipe the exterior with a dry, soft cloth. Do not use liquid cleaners or abrasive materials.
• Emmagatzematge: Store the timer plug in a cool, dry place when not in use.
• Inspecció: Periodically inspect the plug and cord for any signs of wear or damage.

7. Solució De Problemes

8. Especificacions

• Número de model: BNH-50/SE76
• Voltage & puntuació: 240 volts, 50 Hz, 13 Amps (Max 3120W)
• Countdown Options: 15 min, 30 min, 1 hour, 2 hours, 4 hours, 6 hours
• Material: Plastic Acrylonitrile Butadiene Styrene (ABS)
• Dimensions del producte: 8 x 6.9 x 7.8 cm
• Pes de l'article: 151 grams
• Temperatura de funcionament: -10 °C a +50 °C
• Certificacions: Certificat CE

Image: A diagram showing the dimensions of the HBN Countdown Timer Plug (7.8cm x 7.8cm x 3.7cm) and a close-up of its technical label, indicating model number BNH-50/SE76, voltage, current rating, and certifications like UKCA, CE, and RoHS.

9. Garantia i Suport

The HBN Countdown Timer Plug comes with a 2 any de garantia. For any questions, concerns, or support needs, please refer to your purchase documentation or contact HBN customer service.

This product is CE certified, ensuring compliance with European safety standards.
