Introducció
The Dolphin BoxParty 212 is a powerful and versatile portable Bluetooth party speaker designed to deliver loud sound with deep bass, vibrant LED lights, and a comprehensive PA system. Featuring dual 12-inch woofers, a 5-band equalizer, and an expandable battery, this speaker is ideal for various indoor and outdoor events. This manual provides essential information for setting up, operating, maintaining, and troubleshooting your speaker to ensure optimal performance and longevity.
Image: The Dolphin BoxParty 212 speaker, showcasing its dual 12-inch woofers, along with the included wired microphone and remote control.
Configuració
Desembalatge i inspecció inicial
Carefully remove all components from the packaging. Verify that all items listed in the 'What's in the Box' section are present and undamaged. Retain the packaging for future storage or transport.
Carregant la bateria
The speaker comes with a large 7000 mAH rechargeable battery. Before first use, fully charge the speaker for optimal battery life. Connect the power cable to the speaker's power input and plug it into a standard electrical outlet. The charging indicator light will show the charging status.
Image: Close-up of the Dolphin BoxParty 212 speaker highlighting its built-in rechargeable battery for portable use.
Connexió d'una bateria externa
For extended playtime, the speaker includes an expandable battery cable, allowing connection to any 12V battery, such as a car battery. Connect the red clip to the positive (+) terminal and the black clip to the negative (-) terminal of the external 12V battery. Ensure correct polarity to prevent damage.
Image: The rear panel of the Dolphin BoxParty 212 speaker, demonstrating how to connect an external 12V battery using the provided cable for extended operation.
Portabilitat
The speaker is equipped with wheels for easy portability. Tilt the speaker and use the integrated handle to move it conveniently.
Image: The underside of the Dolphin BoxParty 212 speaker, clearly showing the integrated wheels designed for easy transport.
Instruccions de funcionament
Encès/Apagat
Locate the power switch on the control panel. Press and hold to turn the speaker on or off.
Connectivitat Bluetooth
The speaker features Bluetooth 4.2+EDR for stable wireless connection up to 30 feet. To pair:
- Turn on the speaker and ensure it is in Bluetooth mode (indicated on the display).
- Activa el Bluetooth al teu dispositiu mòbil o ordinador.
- Cerca "Dolphin BoxParty 212" or similar on your device's Bluetooth list.
- Seleccioneu l'altaveu que voleu emparellar. Un so de confirmació indicarà que l'emparellament s'ha realitzat correctament.
Once paired, your device will automatically connect when in range and Bluetooth is active.
Image: A user enjoying karaoke with the Dolphin BoxParty 212 speaker, demonstrating the stable Bluetooth connection from over 30 feet away.
Entrades i controls d'àudio
The speaker supports multiple audio sources:
- USB/SD/TF: Insert a USB drive, SD card, or TF card into the respective slot for direct playback of MP3 files.
- Ràdio FM: Switch to FM mode. Use the control panel or remote to scan for and select radio stations.
- Entrada AUX: Connect external audio devices (e.g., smartphones, MP3 players) using a 3.5mm AUX cable to the AUX jack.
- Microphone/Guitar Jacks: Two 1/4" jacks are available for connecting a microphone and a guitar. Dedicated controls for microphone treble, bass, and echo are provided for sound customization.
Image: The comprehensive rear control panel of the Dolphin BoxParty 212, illustrating the various input options including USB, SD, TF, FM, AUX, microphone, and guitar jacks.
Control de so
Adjust the audio output using the following controls:
- Control de volum: Master volume knob to adjust overall sound level.
- X-Bass Control: Dedicated knob for enhancing bass frequencies.
- Equalitzador de 5 bandes: Fine-tune the audio frequencies (200Hz, 500Hz, 1KHz, 10KHz, 12KHz) to match your preference or environment.
- Three Channel Sound Board: Provides additional control over audio mixing.
Image: A visual representation of the 5-band equalizer and 3-channel sound board, illustrating the extensive sound customization options available on the Dolphin BoxParty 212 speaker.
Llums LED
The speaker features sound-activated 7-color LED lights that flash and dance with the music. These lights can be turned off via a dedicated switch on the control panel if not desired.
WaveSync Technology (Pairing Two Speakers)
Utilize WaveSync Technology to wirelessly pair two Dolphin BoxParty 212 speakers for a stereo sound experience and double the power. Refer to the speaker's display and control panel for specific pairing instructions, typically involving a dedicated 'WaveSync' or 'Pair' button.
Image: Two Dolphin BoxParty 212 speakers shown wirelessly connected, demonstrating the WaveSync feature for synchronized audio playback.
Manteniment
Neteja
Wipe the speaker's exterior with a soft, dry cloth. Do not use abrasive cleaners or solvents. Keep the speaker grilles free of dust and debris.
Cura de la bateria
To prolong battery life, avoid fully discharging the battery frequently. Recharge the speaker regularly, even if not in use for extended periods (e.g., once every 3 months).
Emmagatzematge
Store the speaker in a cool, dry place away from direct sunlight and extreme temperatures. If storing for a long time, ensure the battery is partially charged (around 50%).
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| Sense poder | Battery depleted; Power cable not connected; Power switch off. | Charge the battery; Ensure power cable is securely connected; Turn power switch ON. |
| Sense so | Volume too low; Incorrect input mode; Device not connected properly. | Increase volume; Select correct input mode (Bluetooth, AUX, USB, etc.); Reconnect device. |
| Desconnexió Bluetooth | Device out of range; Interference; Other devices connected. | Move device closer to speaker (within 30 ft); Avoid obstacles; Ensure only one device is connected. |
| So distorsionat | Volume too high; Audio source quality; Equalizer settings. | Reduce volume; Use high-quality audio files; Adjust equalizer settings. |
| Microphone/Guitar Not Working | Cable not connected; Volume/gain too low; Incorrect jack used. | Ensure cables are fully inserted; Increase mic/guitar volume/gain; Use correct 1/4" jack. |
Especificacions
- Número de model: SP-212RBT
- Potència de sortidatage: 3600 watts
- Woofers: Doble de 12 polzades
- Font d'alimentació: Battery Powered (Rechargeable 7000 mAH 12V battery included), Expandable via external 12V battery
- Tecnologia de connectivitat: Wireless (Bluetooth 4.2+EDR)
- Entrades d'àudio: Bluetooth, USB, SD, TF, FM, AUX, 1/4" Microphone Jack, 1/4" Guitar Jack
- Nombre de canals: 3
- Equalitzador: 5-Band (200Hz, 500Hz, 1KHz, 10KHz, 12KHz)
- Impedància: 4 ohms
- Resposta de freqüència: 500 Hz
- Material: Plàstic ABS
- Color: Negre
- Dimensions del producte (L x A x A): 14 x 14 x 32 polzades
- Pes de l'article: 40 lliures
- Tipus de muntatge: Terra de peu
- Fabricant: General Sound Co.
Garantia i Suport
Dolphin Audio products are crafted for customer satisfaction. For any issues, technical support, or warranty inquiries, please refer to the contact information provided with your purchase documentation or visit the official Dolphin Audio weblloc web. Conserveu el comprovant de compra per a reclamacions de garantia.
Informació important de seguretat
- No exposeu l'altaveu a l'aigua ni a una humitat excessiva.
- Avoid placing the speaker near heat sources or in direct sunlight for prolonged periods.
- No intenteu desmuntar ni modificar l'altaveu. Encarregueu tot el manteniment a personal qualificat.
- Assegureu-vos d'una ventilació adequada al voltant de l'altaveu durant el funcionament.
- Aquest producte conté substàncies químiques que l'estat de Califòrnia sap que causen càncer i defectes congènits o altres danys reproductius (advertència de la Proposició 65).
Vídeos oficials de productes
No hi havia vídeos oficials de productes del venedor disponibles per incrustar en aquest manual.
