1. Introducció
This instruction manual provides essential information for the safe and efficient installation, operation, and maintenance of your HENDI K40 Glass Washer. This appliance is designed exclusively for commercial use in professional catering and hospitality environments. Read this manual thoroughly before operating the machine to ensure proper function and to prevent injury or damage.
2. Instruccions de seguretat
Always adhere to the following safety guidelines to prevent accidents and ensure the longevity of your appliance:
- Seguretat elèctrica: Ensure the appliance is connected to a properly grounded 230 Volt power supply. Do not operate with damaged cords or plugs. Disconnect power before any maintenance or cleaning.
- Seguretat de l'aigua: Ensure water connections are secure to prevent leaks. Do not operate the machine without adequate water supply.
- Superfícies calentes: The machine's interior and water can reach high temperatures. Exercise caution when opening the door or handling washed items immediately after a cycle.
- Manipulació de productes químics: Use only commercial-grade detergents and rinse aids suitable for glass washers. Follow manufacturer's instructions for chemical dosage and handling. Wear appropriate personal protective equipment (PPE) when handling chemicals.
- Ús previst: This appliance is for washing glassware in commercial settings only. Do not use it for purposes other than its intended function.
- Supervisió: Do not allow untrained personnel to operate the machine. Keep children and unauthorized individuals away from the appliance.
3. Producte acabatview
The HENDI K40 Glass Washer is a compact and robust appliance designed for efficient glass cleaning. It features a stainless steel construction for durability and hygiene.
Figura 1: Frontal view of the HENDI K40 Glass Washer, showing the main door and control panel.
Figura 2: lateral view of the HENDI K40 Glass Washer, illustrating its compact design.
Figura 3: Interior view of the HENDI K40 Glass Washer, showing the wash basket in place.
Figure 4: Detail of a component or control area of the HENDI K40 Glass Washer.
4. Configuració
Proper installation is crucial for the performance and safety of your glass washer. It is recommended that installation be performed by a qualified technician.
4.1 Desembalatge
- Traieu amb cura l'aparell del seu embalatge.
- Inspect for any shipping damage. Report any damage to your supplier immediately.
- Remove all packing materials, including any internal protective elements.
4.2 Col·locació
- Place the glass washer on a stable, level surface capable of supporting its weight (36 kg when empty, more when filled).
- Assegureu-vos que hi hagi una ventilació adequada al voltant de la màquina. No bloquegeu les reixetes d'aire.
- Position the machine near suitable water supply, drain, and electrical connections.
4.3 Connexió elèctrica
- Connect the appliance to a dedicated 230 Volt, 50/60 Hz, grounded electrical outlet.
- Ensure the electrical circuit can handle the machine's power requirements.
- No utilitzeu cables d'extensió ni adaptadors.
4.4 Connexió de subministrament d'aigua
- Connect the machine to a cold or hot water supply using the provided hoses.
- Assegureu-vos que totes les connexions estiguin ajustades per evitar fuites.
- An external water softener may be required depending on local water hardness to prevent limescale buildup.
4.5 Connexió de desguàs
- Connect the drain hose to a suitable waste water outlet.
- Ensure the drain hose is properly sloped to allow for gravity drainage and is not kinked.
5. Instruccions de funcionament
Follow these steps for routine operation of your HENDI K40 Glass Washer.
5.1 Comprovacions prèvies a l'operació
- Ensure the machine is connected to power and water.
- Check that the drain is clear and properly connected.
- Verify detergent and rinse aid levels in their respective dispensers. Refill if necessary.
- Ensure the internal filters are clean and correctly positioned.
5.2 Loading Glassware
- Scrape off any large food particles from glassware before loading.
- Place glasses in the designated baskets, ensuring they are not overcrowded and water can reach all surfaces.
- Avoid placing delicate items directly under spray arms.
5.3 Selecting and Starting a Wash Cycle
- Close the machine door securely.
- Enceneu l'interruptor principal.
- Select the desired wash cycle (refer to the control panel for options).
- Press the START button to begin the cycle. The machine will fill with water and begin washing.
5.4 Unloading and Shutting Down
- Once the cycle is complete, wait a few minutes for items to cool and dry slightly before opening the door.
- Carefully remove the clean glassware.
- At the end of the day, turn off the machine, disconnect power, and perform daily cleaning procedures.
6. Manteniment
Regular maintenance ensures optimal performance and extends the lifespan of your glass washer.
6.1 Neteja diària
- Drain and Clean Filters: After the last cycle, drain the machine. Remove and clean all filters under running water to remove food debris.
- Neteja l'interior: Wipe down the interior of the machine, including the door and seals, with a damp tela.
- Clean Spray Arms: Check spray arm nozzles for blockages and clean if necessary.
6.2 Neteja setmanal/mensual
- Descalcificació: Depending on water hardness, periodically descale the machine using a commercial descaling agent. Follow the descaler manufacturer's instructions carefully.
- Neteja profunda: Perform a more thorough cleaning of the interior, including spray arms and racks.
6.3 Detergent i abrillantador
- Regularly check and refill the detergent and rinse aid reservoirs.
- Use only recommended commercial products.
Note on Spare Parts: Information regarding the availability of spare parts for this model is currently unavailable. Please contact HENDI customer support for assistance with specific part inquiries.
7. Solució De Problemes
This section addresses common issues you might encounter with your glass washer. For problems not listed here, contact qualified service personnel.
| Problema | Causa possible | Solució |
|---|---|---|
| La màquina no arrenca | No power; Door not closed; Water supply off | Check power connection and circuit breaker; Ensure door is latched; Check water tap. |
| Poor wash results (streaks, residue) | Detergent/rinse aid low or incorrect dosage; Clogged spray arms/filters; Water hardness issue | Refill dispensers, adjust dosage; Clean spray arms and filters; Consider water softener or descaling. |
| L'aigua no drena | Drain hose kinked or blocked; Drain pump issue | Check and clear drain hose; Contact service technician if pump is faulty. |
| Fuites | Loose hose connections; Damaged door seal | Tighten connections; Inspect and replace door seal if damaged. |
8. Especificacions
Technical data for the HENDI K40 Glass Washer (Model: 230299).
| Característica | Especificació |
|---|---|
| Marca | HENDI |
| Número de model | 230299 |
| Dimensions (L x A x A) | 77 x 59 x 49 cm |
| Pes | 36 quilos |
| Capacitat | 17 litres |
| Voltage | 230 Volts |
| Material | Acer inoxidable |
| Components inclosos | Glass washer unit |
9. Garantia i Suport
This HENDI K40 Glass Washer is a commercial product not intended for domestic use. Warranty terms and conditions apply as per commercial product standards. For detailed warranty information, technical support, or service requests, please contact your HENDI supplier or visit the official HENDI website. Always provide the model number (230299) and serial number when contacting support.
