Introducció
Thank you for choosing the Blow JS-19 16800 mAh Powerbank Jump Starter. This versatile device is designed to provide emergency jump-starting for vehicles, act as a portable power bank for electronic devices, and offer an integrated LED flashlight for various situations. Please read this manual carefully before using the product to ensure safe and optimal performance.
Instruccions importants de seguretat
- Always ensure the jump starter is fully charged before use, especially for jump-starting a vehicle.
- Do not attempt to jump-start a vehicle if the battery indicator shows less than 50% charge.
- Connecteu el cl vermellamp al terminal positiu (+) de la bateria del vehicle i al cl negreamp al terminal negatiu (-) o a un punt de terra adequat al xassís del vehicle.
- Eviteu curtcircuitar el cl d'arrencador de bateriaamps tocant-los junts.
- No exposeu el dispositiu a temperatures extremes, llum solar directa ni humitat.
- Mantenir fora de l'abast dels nens.
- If the device becomes excessively hot during use, disconnect it immediately and allow it to cool down.
- Do not disassemble or modify the device. This will void the warranty and may cause damage or injury.
Contingut del paquet
Desembaleu la caixa amb cura i assegureu-vos que tots els articles hi siguin presents i en bon estat. Si hi ha algun article que falti o que estigui malmès, poseu-vos en contacte amb el vostre distribuïdor.
Included accessories for the Blow JS-19 Powerbank Jump Starter, featuring smart jump cables, various charging adapters (wall, car), and a multi-device USB charging cable.
- Blow JS-19 Powerbank Jump Starter Unit
- Smart Jump Cables (Red/Black)
- Carregador de paret de CA.
- Carregador de cotxe
- Multi-device USB Charging Cable
- Various DC Adapter Tips
- Manual d'usuari (aquest document)
Producte acabatview
Familiarize yourself with the different parts and functions of your Blow JS-19 Powerbank Jump Starter.
Davant view of the Blow JS-19 Powerbank Jump Starter, displaying the digital charge indicator, 'ENGINE START' button, and an integrated compass.
posterior view of the Blow JS-19 Powerbank Jump Starter, showing the multiple USB output ports, the main ON/OFF switch, and the dedicated jump start cable connection ports.
Components:
- Port d'arrencada ràpida: Connection point for the smart jump cables.
- Ports de sortida USB: Per carregar telèfons intel·ligents, tauletes i altres dispositius alimentats per USB.
- Pantalla LED: Shows battery charge percentage and operational status.
- Interruptor ON / OFF: Encén o apaga la unitat.
- Llanterna LED: Proporciona il·luminació.
- Brúixola: Integrat per a l'assistència a la navegació.
- Safety Hammer/Glass Breaker: Located on the side for emergency situations.
- Port d'entrada de CC: Per carregar la unitat d'arrencada.
Configuració i càrrega inicial
Before first use, it is recommended to fully charge the Blow JS-19 Powerbank Jump Starter. This ensures maximum performance and extends battery life.
- Connect the AC wall charger to the DC Input Port on the jump starter.
- Plug the AC wall charger into a standard electrical outlet.
- La pantalla LED mostrarà el progrés de la càrrega. Carregueu fins que la pantalla indiqui el 100%.
- Un cop estigui completament carregat, desconnecteu el carregador.
Nota: For optimal battery health, recharge the unit every 3-6 months if not in regular use.
Instruccions de funcionament
1. Arrencada d'un vehicle amb ajuda d'un cable
Ensure the jump starter has at least 50% charge before attempting to jump-start a vehicle.
- Apagueu el contacte del vehicle i tots els accessoris (llums, ràdio, etc.).
- Connect the smart jump cables to the jump start port on the Blow JS-19 unit. Ensure a secure connection.
- Connecteu el vermell (+) clamp al terminal positiu de la bateria del vehicle.
- Connecteu el negre (-) clamp to the negative terminal of the vehicle's battery or a solid, unpainted metal part of the engine block/chassis.
- Assegureu-vos que el clamps are securely attached and not touching any moving parts.
- Press the 'ENGINE START' button on the jump starter (if applicable, or ensure the unit is powered on).
- Engegueu el motor del vehicle. Si no arrenca immediatament, espereu 30 segons abans de tornar-ho a intentar. No feu girar el motor durant més de 3 segons per intent.
- Un cop arrencat el vehicle, retireu immediatament el clau negre (-).amp primer, després el cl vermell (+)amp de la bateria del vehicle.
- Disconnect the smart jump cables from the Blow JS-19 unit.
2. Ús com a bateria externa
The Blow JS-19 can charge various electronic devices via its USB output ports.
- Turn on the Blow JS-19 unit using the ON/OFF switch.
- Connecteu el cable de càrrega USB del dispositiu a un dels ports de sortida USB de l'arrencador de bateria.
- Connecteu l'altre extrem del cable al vostre dispositiu electrònic.
- Charging will begin automatically. The LED display will show the remaining charge of the power bank.
- Once your device is charged, disconnect it from the power bank. Turn off the power bank to conserve battery.
3. Ús de la llanterna LED
The integrated LED flashlight provides illumination in low-light conditions.
- Turn on the Blow JS-19 unit using the ON/OFF switch.
- Locate the flashlight button (refer to Product Overview for exact location).
- Press the button once to turn on the flashlight.
- Press again to cycle through different modes (e.g., steady light, strobe, SOS).
- Press and hold, or cycle through all modes, to turn off the flashlight.
Manteniment
- Recàrrega: Recharge the unit after each jump-start or heavy use. For long-term storage, recharge every 3-6 months to maintain battery health.
- Emmagatzematge: Store the jump starter in a cool, dry place, away from direct sunlight and extreme temperatures. Keep it in its protective carrying case when not in use.
- Neteja: Feu servir un drap suau i sec per netejar l'exterior de la unitat. No utilitzeu productes químics agressius ni netejadors abrasius.
- Cura del cable: Inspect jump cables and clamps for any damage before each use. Replace if frayed or damaged.
The Blow JS-19 Powerbank Jump Starter and its complete set of accessories organized within its protective carrying case.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| Vehicle does not start after jump-start attempt. | Jump starter battery is low; clamps are not properly connected; vehicle battery is severely damaged; other vehicle issues. | Ensure jump starter is fully charged (>50%). Check clamp connections for proper contact. Consult a mechanic if vehicle still won't start. |
| L'arrencador de bateria no carrega. | Charger not connected properly; faulty charger or cable; unit malfunction. | Check all connections. Try a different outlet. If issue persists, contact customer support. |
| Els dispositius USB no es carreguen. | Jump starter is off; USB cable is faulty; device is incompatible. | Ensure jump starter is powered on. Try a different USB cable. Check device compatibility. |
| La llanterna LED no funciona. | Jump starter is off; low battery. | Ensure jump starter is powered on. Recharge the unit. |
Especificacions
| Característica | Valor |
|---|---|
| Marca | Cop |
| Número de model | JS-19 (5900800000000) |
| Capacitat de la bateria | 16800 mAh |
| Tipus de bateria | Ió de liti |
| Voltage | 5 Volts (USB Output) |
| Tipus de servei del vehicle | Cotxe |
| Pes de l'article | 5 quilos |
| Dimensions del producte (L x A x A) | 2.79 x 24.64 x 16.51 cm |
Garantia i Suport
This product is covered by a standard manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical support, troubleshooting assistance, or warranty claims, please contact your retailer or the Blow customer service department.
Please have your model number (JS-19) and proof of purchase ready when contacting support.
