Introducció
The Victrix Pro AF headset is engineered for professional esports, streamers, and core gamers, offering a lightweight design and immersive audio experience. It is officially licensed for PlayStation consoles and compatible with PS4, PS5, and PC. This manual provides essential information for setup, operation, maintenance, and troubleshooting to ensure optimal performance of your headset.
Les característiques clau inclouen:
- Professional Esports Headset: Officially licensed by PlayStation, compatible with PS4, PS5, and PC.
- Protective Earcups: Vegan leather memory foam ear pads provide sound isolation and enhance audio from 50mm speaker drivers.
- Military Grade Mic: Removable boom mic, designed for clear communication in loud environments.
- Next Gen Ventilation: Mechanical levers on earcups release heat and humidity for extended comfort.
- Construït resistent: Constructed with aircraft-grade aluminum and stainless-steel for durability.
Figure 1: Victrix Pro AF Premium Wired Esports Gaming Headset (Black/Purple).
Producte acabatview Vídeo
Vídeo 1: Un general acabatview of PDP Licensed Gaming Accessories, including controllers and headsets. This video showcases the brand's commitment to gaming peripherals.
Què hi ha a la caixa
The Victrix Pro AF headset package includes the following components:
- Victrix Pro AF Headset with fixed 1.2M cable and 3.5mm headset connector
- 1M Audio Extension Cable
- Cable divisor de PC
- Tela de neteja de microfibra
- Quick-Start Guide (this manual serves as a comprehensive guide)
Figure 2: The Victrix Pro AF headset shown with its packaging, indicating included components.
Configuració
Connecting to PlayStation (PS4/PS5)
- Locate the 3.5mm audio jack on your PlayStation controller (DualShock 4 or DualSense).
- Plug the 3.5mm connector from the Victrix Pro AF headset's fixed cable directly into the controller's audio jack.
- Ensure the microphone boom is securely attached to the headset.
- Adjust headset volume and microphone levels through your PlayStation system settings.
Connexió al PC
- For PCs with separate audio input (microphone) and output (headphone) jacks, use the included PC splitter cable.
- Connect the headset's 3.5mm connector to the female end of the PC splitter cable.
- Plug the green-coded male end of the splitter into your PC's headphone jack and the pink-coded male end into your PC's microphone jack.
- For PCs with a single combined 3.5mm audio jack, you can plug the headset directly into the jack.
- Adjust audio settings within your PC's operating system (e.g., Sound settings in Windows) to select the headset as the default playback and recording device.
Figura 3: Frontal view of the Victrix Pro AF Headset, showing the microphone attachment point.
Instruccions de funcionament
Controls d'àudio
The Victrix Pro AF headset features on-ear controls for convenient audio management.
- Marcador de volum: Located on the earcup, rotate to increase or decrease audio volume.
- Interruptor de silenci del micròfon: A physical switch on the microphone boom or earcup allows for quick muting and unmuting of the microphone.
Figure 4: Close-up of the Victrix Pro AF Headset showing the on-ear controls for audio adjustment.
Mecanisme de refrigeració
The headset incorporates a unique cooling mechanism to enhance comfort during extended use.
- Ventilation Levers: Locate the mechanical levers on the earcups.
- Activate Ventilation: Move the levers to open the earcup vents, allowing heat and humidity to dissipate.
- Close Vents: Move the levers back to close the vents for maximum sound isolation.
Figure 5: The Victrix Pro AF Headset demonstrating its cooling mechanism with open earcup vents.
Ús del micròfon
The military-grade microphone ensures clear voice communication.
- Attaching/Detaching: The microphone boom is removable. Align the connector and gently push to attach, or pull to detach.
- Posicionament: For optimal voice clarity, position the microphone approximately 1-2 inches from your mouth.
- Cancel·lació de soroll: The 6.0mm bi-directional mic is designed to reduce background noise.
Figure 6: The Victrix Pro AF Headset highlighting its active noise-canceling microphone.
Manteniment
Proper care will extend the life and performance of your Victrix Pro AF headset.
- Cleaning Earcups: Use the included microfiber cleaning cloth to gently wipe the vegan leather memory foam ear pads. For deeper cleaning, a slightly damp cloth with mild soap can be used, but ensure no moisture enters the speaker grilles.
- Cleaning Headset Body: Wipe the aircraft-grade aluminum and stainless-steel frame with a dry or slightly damp tela. Eviteu els netejadors abrasius.
- Cura del cable: Avoid sharp bends or excessive pulling on the cables. Store the headset in a way that prevents tangling or crimping of the cables.
- Emmagatzematge: Guardeu els auriculars en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| No hi ha àudio dels auriculars. |
|
|
| El micròfon no funciona. |
|
|
| La qualitat del so és deficient o distorsionada. |
|
|
| Earcups feel hot or humid. |
|
|
Especificacions
| Característica | Detall |
|---|---|
| Nom del model | Victrix Headset |
| Número de model | 051-095-NA |
| Tecnologia de connectivitat | Amb cable |
| Conector d'auriculars | 3.5 mm Jack |
| Resposta de freqüència | 20 Hz - 20,000 Hz |
| Tipus de controlador d'àudio | Controlador dinàmic (50 mm) |
| Tipus de micròfon | Removable Boom Microphone (6.0mm Bi-Directional) |
| Forma de l'auricular | Sobre l'orella |
| Material | Faux Leather, Plastic, Polyurethane (PU), Aircraft-grade Aluminum, Stainless-steel |
| Pes de l'article | 1.7 lliures (aprox. 771 grams) |
| Dimensions del producte | 1.1 x 1.06 x 0.39 polzades |
| Dispositius compatibles | PlayStation 4, PlayStation 5, PC |
| UPC | 708056066376 |
Garantia i Suport
Per obtenir informació sobre la garantia i assistència tècnica, consulteu el PDP oficial. weblloc web o contacteu directament amb el seu servei d'atenció al client.
- Assistència en línia: Visita el Botiga PDP a Amazon or the official PDP weblloc per a preguntes freqüents, guies de resolució de problemes i informació de contacte.
- Atenció al client: Contact PDP customer support for assistance with product issues, warranty claims, or replacement parts.
Si us plau, conserveu el comprovant de compra per a qualsevol reclamació de garantia.
