1. Introducció
Thank you for choosing the Vacmaster Orson Lite 24V Max Cordless Vacuum Cleaner. This manual provides essential information for the safe and efficient use, maintenance, and troubleshooting of your new appliance. Please read these instructions carefully before use and retain them for future reference.
Instruccions importants de seguretat
- Always ensure the vacuum is switched off and unplugged before cleaning or performing maintenance.
- No feu servir l'aspiradora per recollir aigua o materials humits.
- Mantingueu els cabells, la roba solta, els dits i totes les parts del cos lluny de les obertures i les parts mòbils.
- No l'utilitzeu sense el contenidor de pols i els filtres al seu lloc.
- Store the vacuum in a dry, indoor area.
2. Contingut del paquet
Carefully unpack your Vacmaster Orson Lite and check that all items are present and in good condition. If any items are missing or damaged, please contact customer support.
- Main Vacuum Unit (with integrated battery)
- Vareta d’extensió
- Powered Floor Head
- 2-in-1 Crevice Tool and Dusting Brush
- Wall Mount / Charging Dock
- Charging Adapter (UK)
- 2 Washable HEPA 13 Filters
- Manual d'usuari
Imatge: Més deview of the Vacmaster Orson Lite cordless vacuum cleaner and its included accessories, such as the main unit, extension wand, floor head, and various attachments.
3. Muntatge
Follow these steps to assemble your Vacmaster Orson Lite vacuum cleaner.
- Connecteu la vareta d'extensió: Introduïu la vareta d'extensió a la unitat principal d'aspiradora fins que encaixi fermament al seu lloc.
- Connecteu el capçal del terra: Attach the powered floor head to the other end of the extension wand, ensuring it clicks firmly.
- Instal·leu el suport de paret: Choose a suitable location near a power outlet. Secure the wall mount/charging dock to the wall using appropriate screws and anchors (not included). Ensure it is mounted at a height that allows the vacuum to hang freely.
Image: The Vacmaster Orson Lite cordless vacuum cleaner securely stored on its wall-mounted charging dock, ready for use.
4. Carregant la bateria
The Vacmaster Orson Lite is powered by a 24V Max lithium-ion battery. For optimal performance, fully charge the battery before first use.
- Connecta el carregador: Plug the charging adapter into a wall outlet and connect the other end to the charging port on the wall mount or directly to the vacuum unit.
- Indicador de càrrega: The LED battery display on the vacuum will show the charging status. It will illuminate progressively as the battery charges and indicate a full charge when all segments are lit.
- Temps de càrrega: Una càrrega completa sol trigar aproximadament 4-5 hores.
Image: Close-up of the Vacmaster Orson Lite's control panel, showing the LED battery display indicating the current charge level.
5. Funcionament
The Vacmaster Orson Lite offers versatile 3-in-1 cleaning for various surfaces.
Power On/Off and Speed Selection
- Premeu el botó d'engegada del mànec per encendre o apagar l'aspiradora.
- Press the speed selection button to switch between standard and Turbo modes. Turbo mode provides increased suction for stubborn dirt and pet hair, but reduces runtime.
- The LED battery display indicates remaining power during use.
Modes de neteja
- Upright Stick Vacuum: For cleaning hard floors and carpets. The powered floor head features LED task lights to illuminate dust and debris.
- Aspiradora de mà: Detach the extension wand and floor head to use the main unit as a handheld vacuum for furniture, car interiors, or small spills.
- With 2-in-1 Tool: Attach the crevice tool and dusting brush directly to the main unit or the extension wand for cleaning tight spaces, upholstery, or delicate surfaces.
Image: A user operating the Vacmaster Orson Lite in handheld mode, effectively cleaning stairs with its compact design.
Image: Close-up of the Vacmaster Orson Lite's powered floor head, showcasing its integrated LED task lights illuminating debris on a hard floor.
Image: A man using the lightweight Vacmaster Orson Lite with its extension wand to easily clean dust from a high corner of a room.
6. Manteniment
Regular maintenance ensures your Vacmaster Orson Lite operates efficiently and prolongs its lifespan.
Buidatge de la paperera
- Assegureu-vos que l'aspiradora estigui apagada.
- Press the dust bin release button to detach the dust bin from the main unit.
- Position the dust bin over a trash receptacle and press the bottom release button to open the flap and empty the contents.
- Close the flap and reattach the dust bin to the main unit until it clicks securely.
Image: A hand demonstrating the easy-to-empty dust bin feature of the Vacmaster Orson Lite, showing debris being released into a trash can.
Neteja dels filtres
The Vacmaster Orson Lite includes 2 washable HEPA 13 filters. Clean them regularly to maintain suction power.
- Traieu el contenidor de pols tal com s'ha descrit anteriorment.
- Gireu i traieu el conjunt del filtre del dipòsit de pols.
- Tap the filters gently to remove loose dust. For a deeper clean, rinse the filters under cold running water until the water runs clear.
- Deixeu que els filtres s'assequin completament a l'aire durant almenys 24 hores abans de tornar-los a muntar. No utilitzeu un assecador ni una font de calor.
- Reinsert the dry filters into the dust bin and reattach the dust bin to the vacuum.
Neteja del rotllo del raspall
Periodically check the brush roll in the powered floor head for tangled hair or debris. Use scissors to cut away any tangled material and remove it by hand.
7. Solució De Problemes
If you encounter issues with your Vacmaster Orson Lite, refer to the following common problems and solutions.
| Problema | Causa possible | Solució |
|---|---|---|
| El buit no s'encén | La bateria s’ha esgotat La bateria no està ben connectada | Carregueu la bateria completament Assegureu-vos que la bateria estigui ben inserida |
| Pèrdua de succió | El contenidor de pols està ple Els filtres estan obstruïts Blockage in nozzle, wand, or hose | Buidar el contenidor de pols Netegeu o substituïu els filtres Comproveu i elimineu qualsevol bloqueig |
| El rotllo de pinzell no gira | Tangled debris Floor head not properly connected | Clean brush roll of hair and debris Ensure floor head is securely attached |
| Temps d'execució curt | La bateria no està completament carregada Ús excessiu del mode Turbo Degradació de la bateria | Carregueu la bateria completament Use standard mode for general cleaning Contact customer support if battery life significantly decreases |
8. Especificacions
| Característica | Especificació |
|---|---|
| Marca | Vacmaster |
| Número de model | VSE2101EU |
| Dimensions del producte (L x A x A) | 23.5 x 22.5 x 116 cm |
| Pes de l'article | 2.55 quilos |
| Poder | 450 watts |
| Voltage | 24 Volts |
| Nombre de velocitats | 2 |
| Nivell de so | 70 decibels |
| Temps d'execució | Fins a 40 minuts |
| Tipus de bateria | 1 bateria de liti-ió (inclosa) |
| Característiques especials | Lightweight, Cordless, Bagless |
| Tipus de filtre | Washable HEPA 13 |
| Fabricant | Cleva |
| País d'origen | Xina |
9. Garantia i Suport
Informació de la garantia
The Vacmaster Orson Lite VSE2101EU comes with a 2 any de garantia on spare parts, covering defects in materials and workmanship from the date of purchase. This warranty does not cover damage caused by misuse, neglect, accident, or unauthorized modification. Please retain your proof of purchase for warranty claims.
Atenció al client
For technical assistance, warranty claims, or to order replacement parts, please visit the official Vacmaster weblloc web o poseu-vos en contacte amb el seu departament d'atenció al client. La informació de contacte normalment es pot trobar a l'embalatge del producte o a la fitxa oficial de la marca. weblloc.
