EUGAD 0651BY-1 Bar Stool Instruction Manual

1. Introducció

Thank you for choosing the EUGAD 0651BY-1 Bar Stool. This manual provides essential information for the safe assembly, operation, and maintenance of your new bar stool. Please read these instructions carefully before use and retain them for future reference.

Figura 1.1: EUGAD 0651BY-1 Bar Stool, showcasing el seu disseny i les seves característiques.

2. Instruccions de seguretat

• Assegureu-vos que tots els components siguin presents i no estiguin danyats abans del muntatge. No utilitzeu el producte si hi falta alguna peça o si està trencada.
• Assemble the stool on a soft, clean surface to prevent scratches.
• Tighten all screws and bolts securely, but do not overtighten. Periodically check and retighten fasteners.
• Do not stand on the stool. Use it only for sitting.
• Do not exceed the maximum weight capacity (not specified, but generally assume 100-120 kg for standard bar stools).
• Mantingueu els nens allunyats de la zona de muntatge. Les peces petites poden ser un perill d'asfíxia.
• Avoid sudden movements or leaning excessively while seated, especially when adjusting height or swiveling.

3. Contingut del paquet

Verifiqueu que tots els components següents estiguin inclosos al paquet:

Figura 3.1: Explotat view of the EUGAD 0651BY-1 Bar Stool components.

1. Seat with Backrest (1x)
2. Gas Lift Cylinder (1x)
3. Base Plate (1x)
4. Anell del reposapeus (1x)
5. Mounting Plate (pre-attached to seat or separate)
6. Paquet de ferramenta (cargols, volanderes, clau Allen)
7. Anti-slip Rubber Ring for Base (1x)

4. Instruccions de muntatge

Follow these steps to assemble your EUGAD 0651BY-1 Bar Stool:

1. Attach the Anti-slip Ring: Carefully place the anti-slip rubber ring onto the bottom edge of the base plate. Ensure it is seated evenly and securely.
2. Insert the Gas Lift: Place the base plate on a flat, stable surface. Insert the wider end of the gas lift cylinder into the central hole of the base plate.
3. Fixeu el reposapeus: Slide the footrest ring over the top of the gas lift cylinder. Ensure it rests on the designated support on the gas lift.
4. Prepare the Seat: If the mounting plate is not pre-attached, secure it to the underside of the seat using the provided screws. Ensure the lever mechanism is facing the back of the seat.
5. Connecteu el seient a l'elevador de gas: Carefully align the central hole of the seat's mounting plate with the top of the gas lift cylinder. Press down firmly until the seat is securely seated on the gas lift.
6. Estabilitat de prova: Once assembled, gently sit on the stool to ensure all connections are stable and the gas lift functions correctly.

5. Instruccions de funcionament

Figura 5.1: Illustration of the 360° swivel and height adjustment features.

5.1. Ajust d'alçada

Per ajustar l'alçada del seient:

• Per aixecar el seient: Stand up and pull the lever located under the seat upwards. The seat will automatically rise. Release the lever when the desired height is reached.
• Per baixar el seient: Sit on the stool and pull the lever located under the seat upwards. The seat will lower under your weight. Release the lever when the desired height is reached.

5.2. Funció de gir de 360°

The seat of the EUGAD 0651BY-1 Bar Stool can freely swivel 360 degrees. Simply rotate the seat in any direction while seated or standing.
