Gemtop Ihelol Eye Massager with Heat and Bluetooth Music User Manual

1. Introducció

This manual provides detailed instructions for the safe and effective use of your Gemtop Ihelol Eye Massager. Please read this manual thoroughly before first use and retain it for future reference. This device is designed to provide a relaxing eye massage experience with heat, vibration, and air pressure, along with Bluetooth music capabilities.

2. Informació important de seguretat

WARNING: To reduce the risk of electric shock, burns, fire, or injury, please observe the following precautions:

• Do not use this massager if you have cataracts, have undergone eye surgery, or have any retina conditions. Consult a medical professional before use if you have any pre-existing eye conditions.
• No l'utilitzeu mentre conduïu o utilitzeu maquinària pesada.
• Mantenir fora de l'abast dels nens.
• No desmunteu, repareu ni modifiqueu el dispositiu vosaltres mateixos.
• Utilitzeu només el cable de càrrega subministrat.
• Avoid using the device in high temperatures or humid environments.
• If you experience any discomfort during use, discontinue use immediately and consult a medical professional.
• The device is designed for personal use and is not a medical device.

3. Producte acabatview

Descripció de la imatge: Un general view of the Gemtop Ihelol Eye Massager, showcasing its sleek white design with black eye cushions and control panel. The device appears compact and ergonomic.

The Gemtop Ihelol Eye Massager features a foldable design for portability and multiple massage modes to suit various needs. It incorporates heat compression, air pressure massage, and vibration massage.

3.1 Components i controls

Descripció de la imatge: Un primer pla view of the Ihelol Eye Massager showing the control panel and a diagram of five massage modes. The control panel has three buttons: an On/Off/Mode button, an Up key (next track/volume up), and a Down key (previous track/volume down). The diagram illustrates "Integrated Mode" (Hot compress, Air pressure, Vibration, Music), "Vitality Mode" (Vibration, Air pressure, Music), "Clear Mode" (Hot compress, Air pressure, Music), "Smart Mode" (Hot compress), and "Sleeping Mode" (Air pressure).

• On/Off/Mode Key: Long press for 3 seconds to power on/off. Short press to cycle through massage modes. Double click to toggle music on/off.
• Tecla amunt: Short press to skip to the next song. Long press to increase volume.
• Tecla avall: Short press to go to the previous song. Long press to decrease volume.

3.2 Acupoint Massage Areas

Descripció de la imatge: A person wearing the Ihelol Eye Massager. Overlayed on the image are labels pointing to various acupoints around the eyes that the massager targets, including Cuanzhu Acupoint, Yuyao Acupoint, Sizhukong Acupoint, Taiyang Acupoint, Tongziliao Acupoint, Chengqi Acupoint, Sibai Acupoint, and Qingming Acupoint. A text box at the bottom explains that the massager uses a built-in airbag to massage these acupoints.

The massager is designed to target specific acupoints around the eyes, including Cuanzhu, Yuyao, Sizhukong, Taiyang, Tongziliao, Chengqi, Sibai, and Qingming, using air pressure and vibration for a comprehensive massage.

Disseny plegable 3.3

Descripció de la imatge: An image demonstrating the 180-degree foldable design of the Ihelol Eye Massager. One part of the image shows the massager folded and being placed into a bag, highlighting its portability. Another inset image shows the dimensions of the folded device (15cm/5.9in length, 9cm/3.5in width, 8.5cm/3.3in height).

The device features a 180° foldable design, making it compact and easy to carry in a storage bag, ideal for travel or storage.

4. Configuració

4.1 Càrrega del dispositiu

• Connect the provided charging cable to the massager and a suitable USB power source.
• The indicator light will display a llum vermella durant la càrrega.
• Once fully charged, the indicator light will turn blau.
• A full charge typically takes 2-3 hours and provides approximately 90 minutes of massage time.

4.2 Vinculació Bluetooth

Descripció de la imatge: A three-panel image illustrating the Bluetooth pairing process for the Ihelol Eye Massager. The first panel shows the massager with an arrow pointing to "turn on the massager". The second panel shows a smartphone's Bluetooth settings screen with "YBY" listed as an available device, indicating "turn on the Bluetooth search 'YBY'". The third panel shows a music streaming app on the phone, indicating "Connect and play".

1. Ensure the massager is powered on. The device will automatically enter Bluetooth pairing mode.
2. Al dispositiu mòbil, obriu la configuració de Bluetooth i cerqueu els dispositius disponibles.
3. Selecciona "YBY" from the list of devices to connect.
4. Once connected, you can play your preferred music through the massager's built-in speakers.

5. Instruccions de funcionament

5.1 Encès/Apagat

• To turn on the massager, long press the On/Off key for 3 seconds.
• To turn off the massager, long press the On/Off key for 3 seconds de nou.

5.2 Changing Massage Modes

The massager offers 5 different modes. Each massage session lasts 15 minutes.

• While the massager is on, short press the On/Off key per anar ciclant pels modes següents:
  1. Integrated Mode: Hot compress, Air pressure, Vibration, Music.
  2. Mode de vitalitat: Vibration, Air pressure, Music.
  3. Mode de neteja: Hot compress, Air pressure, Music.
  4. Mode intel·ligent: Hot compress only.
  5. Mode de repòs: Air pressure only. (Music can be turned off in this mode if desired by double-clicking the On/Off key).

5.3 Control de música

• To play the next song, short press the Up key.
• To play the previous song, short press the Down key.
• Per augmentar el volum, long press the Up key.
• Per reduir el volum, long press the Down key.
• To toggle music on/off, double click the On/Off key.

5.4 Heat Compression Function

Descripció de la imatge: A person wearing the Ihelol Eye Massager, with a red glow emanating from the eye area of the massager, visually representing the heat compression feature. An icon for 107.6°F is displayed, indicating the temperature. Below the image are icons for Air Pressure Massage, Heat Compression, Vibration Massage, and Time Switching, highlighting the device's main functions.

The massager provides a thermostatic heat compress between 104°F and 107°F (40°C-42°C). This feature is active in Integrated, Clear, and Smart modes, designed to help relieve eye strain and dry eyes.

6. Manteniment

• The massager is made of eco-friendly, skin-friendly soft PU leather, which is easy to clean.
• Netegeu la superfície del dispositiu amb un suau, damp tela. No utilitzeu netejadors abrasius ni submergiu el dispositiu en aigua.
• Assegureu-vos que el dispositiu estigui completament sec abans de guardar-lo o recarregar-lo.
• Guardeu el massatjador en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.

7. Solució De Problemes

8. Especificacions

• Model: B08G84Y7Z3
• Marca: Gemtop (Manufacturer: Ihelol)
• Font d'alimentació: Alimentat per bateria (bateria de liti recarregable)
• Capacitat de la bateria: 1200 mAh
• Temps de càrrega: 2-3 hores
• Temps de funcionament: Aproximadament 90 minuts per càrrega
• Temperatura de calor: 40 °C - 42 °C
• Material: Plastic, Soft PU Leather
• Color: Blanc
• Característiques especials: Heat, Vibration, Air Pressure, Bluetooth Music, Foldable Design
• Dimensions del producte: 21.08 x 13.46 x 9.4 cm (Dimensions del paquet)
• Pes: 635 g (Package weight)
• Primer disponible: 19 d'agost de 2020

9. Garantia i Suport

Gemtop offers a 60-Day Money Back Guarantee for the Ihelol Eye Massager. For any product issues or inquiries, 24/7 customer service is available. If you are not satisfied with your product, please contact customer service for a full refund or replacement.

Please refer to your purchase documentation for specific contact details for customer support.
