Introducció
This instruction manual provides essential information for the safe and efficient operation, installation, and maintenance of your Gree LIVO Gen 3 Mini Split A/C Heat Pump. Please read this manual thoroughly before installation and use, and retain it for future reference.
The Gree LIVO Gen 3 system offers powerful 18,000 BTU cooling and heating capacity, suitable for spaces up to 1,000 sq. ft., featuring 16 SEER efficiency and built-in Wi-Fi for convenient control.
Informació de seguretat
Always adhere to local and national electrical codes. Installation and servicing should only be performed by qualified personnel. Failure to do so may result in electric shock, fire, serious injury, or death.
- Assegureu-vos que el subministrament elèctric estigui desconnectat abans de realitzar qualsevol manteniment o servei.
- Do not block air inlets or outlets of the indoor or outdoor units.
- Mantingueu els nens i les mascotes allunyats de la unitat durant el funcionament.
- Use only specified refrigerant (R410A) and ensure proper ventilation during installation.
Components del producte
Figura 1: Acabatview of the Gree Mini Split System, including the outdoor condenser unit, indoor air handler, and basic installation kit components.
Figura 2: Detallada view of typical installation kit components, which may include line set conduit, surge protective device (Intermatic AG3000 shown), and a condenser pad.
Your Gree LIVO Gen 3 system includes the following main components:
- Indoor Unit (Air Handler): Responsible for circulating conditioned air within the space.
- Unitat exterior (condensador): Houses the compressor and heat exchanger for refrigerant circulation.
- Comandament a distància: For convenient operation and setting adjustments.
- Kit d'instal·lació: Includes necessary components for connecting the indoor and outdoor units.
Configuració i instal·lació
The Gree LIVO Gen 3 system is designed for straightforward split system installation. However, due to the nature of refrigerant handling and electrical connections, professional installation is highly recommended to ensure safety, optimal performance, and warranty validity.
Llista de verificació prèvia a la instal·lació:
- Verify power supply (208/230V) matches unit requirements.
- Ensure adequate space for both indoor and outdoor units, allowing for proper airflow and maintenance access.
- Confirm all components from the packing list are present and undamaged.
Passos d'instal·lació (més enllà)view):
- Munteu la unitat interior de manera segura a la paret, assegurant-vos que estigui anivellada.
- Install the outdoor unit on a stable, level surface (e.g., a condenser pad) with sufficient clearance.
- Connect the refrigerant lines between the indoor and outdoor units. Proper vacuuming and charging are critical.
- Complete electrical wiring connections, adhering to all safety standards.
- Install the condensate drain line to ensure proper water removal.
- Perform a leak check and test run to verify proper operation.
Refer to the detailed installation guide provided with your unit for specific instructions and diagrams.
Instruccions de funcionament
Your Gree LIVO Gen 3 system can be operated via the included remote control or through the GREE app using its built-in Wi-Fi capability.
Operació de control remot:
- Encès/apagat: Premeu el botó ON/OFF botó.
- Selecció del mode: Utilitza el MODE button to cycle through Cooling, Heating, Fan, Dry, and Auto modes.
- Ajust de temperatura: Utilitza el TEMPERATURA PUJAR/BAIXAR botons per configurar la temperatura desitjada.
- Velocitat del ventilador: Ajusteu la velocitat del ventilador amb el FAN botó.
- Funció de swing: Activate horizontal or vertical louver swing for even air distribution.
Control per Wi-Fi i aplicacions:
The built-in Wi-Fi allows you to control your unit remotely using the GREE app on your smartphone or tablet. Download the GREE app from your device's app store and follow the in-app instructions to connect your unit to your home Wi-Fi network.
- Remote temperature adjustment and mode selection.
- Scheduling and timer functions.
- Monitoring unit status and energy consumption (if supported by app version).
Manteniment
Regular maintenance ensures optimal performance and longevity of your Gree Mini Split system. Always disconnect power before performing any maintenance.
Neteja del filtre d'aire:
- Netegeu els filtres d'aire cada dues setmanes o amb més freqüència, depenent de l'ús i la qualitat de l'aire.
- Obriu el panell frontal de la unitat interior i traieu els filtres.
- Wash filters with lukewarm water and mild detergent, rinse thoroughly, and allow to air dry completely before reinserting.
Manteniment de la unitat exterior:
- Mantingueu la zona al voltant de la unitat exterior neta de deixalles, fulles i neu.
- Netegeu periòdicament les aletes de la serpentina exterior amb un raspall suau o una mànega d'aigua. Aneu amb compte de no doblegar les aletes.
- Ensure the condensate drain line is not clogged.
For detailed cleaning procedures and professional servicing recommendations, consult your full user manual.
Resolució de problemes
Abans de contactar amb l'atenció al client, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| La unitat no s'encén. | No hi ha alimentació; interruptor automàtic saltat; piles del comandament a distància esgotades. | Check power connection; reset circuit breaker; replace remote batteries. |
| Refrigeració/calefacció insuficient. | Dirty air filters; blocked outdoor unit; wrong mode selected; low refrigerant. | Clean filters; clear obstructions; select correct mode; contact professional for refrigerant check. |
| Fuita d'aigua de la unitat interior. | Clogged drain line; improper installation. | Clear drain line; contact installer for inspection. |
| Soroll inusual. | Loose parts; foreign object; compressor issue. | Inspect for loose parts; remove foreign objects; contact professional if noise persists. |
For error codes or persistent issues, consult the comprehensive troubleshooting section in your full user manual or contact Gree customer support.
Especificacions
Figura 3: LIVO Gen 3 Indoor and Outdoor Unit Measurement Guide. Note that measurements may vary slightly by BTU capacity.
Figura 4: Visual representation of the efficiency scale, indicating the high efficiency of this 16 SEER unit.
| Característica | Detall |
|---|---|
| Número de model | LIVV18HP230V1AK25 |
| Capacitat de refrigeració | 18,000 BTU (1.5 tones) |
| Valoració SEER | 16 |
| Voltage | 208/230 volts |
| Tipus de refrigerant | R410A |
| Característiques especials | Built-in Wi-Fi, G10 Inverter Technology |
| Factor de forma | Mini-Split Wall Mount |
| Color | Blanc |
Garantia i Suport
Figura 5: Key features and certifications including 5-year parts warranty, Wi-Fi readiness, heating capability down to -13°F, AHRI certification, ETL listing, and G10 Inverter Technology.
Your Gree LIVO Gen 3 Mini Split system comes with a Garantia limitada de peces d'5 any. Please refer to the warranty card included with your product for full terms and conditions, including registration requirements.
For technical support, warranty claims, or service inquiries, please contact Gree customer service. Have your model number (LIVV18HP230V1AK25) and purchase date ready when contacting support.
You can find contact information on the Gree official weblloc web o a l'embalatge del producte.
